Image preview - the first page of the document
wave1


>> Download wave1 documenatation <<

Text preview - extract from the document
 WF No. IC2001-13 (PLAY)       WF No. IC2101-14 (PLAY)       WF No. IC2101-15,16,17 (PLAY)    WF No. IC2101-18 (PLAY)




     5Vp-p(50nsec/div)            0.32Vp-p(1msec/div)             1.08Vp-p(1msec/div)           1.12Vp-p(1msec/div)

 WF No. IC2101-19 (PLAY)     WF No. IC2101-27,30,41 (PLAY)     WF No. IC2101-44 (PLAY)        WF No. IC2101-77 (PLAY)




   0.34Vp-p(2msec/div)            0.8Vp-p(1msec/div)              10.8Vp-p(5msec/div)            0.8Vp-p(2msec/div)

WF No. IC2101-78,79 (PLAY)     WF No. IC2101-80 (PLAY)        WF No. IC2101-81,82 (PLAY)     WF No. IC2101-91,92 (PLAY)




   1.6Vp-p(200usec/div)          1.8Vp-p(200usec/div)            2.8Vp-p(200usec/div)           1.5Vp-p(500usec/div)

 WF No. IC2101-95 (PLAY)       WF No. IC2101-96 (PLAY)         WF No. IC2101-99 (PLAY)       WF No. IC2101-100 (PLAY)




   2.8Vp-p(200usec/div)          0.4Vp-p(200usec/div)            6.8Vp-p(200usec/div)            1Vp-p(200usec/div)

 WF No. IC2801-4 (PLAY)         WF No. IC2801-8 (PLAY)         WF No. IC2801-11 (PLAY)        WF No. IC2801-13 (PLAY)




    0.7Vp-p(20usec/div)           1.1Vp-p(20usec/div)            1.05Vp-p(20usec/div)           0.48Vp-p(50usec/div)
