Image preview - the first page of the document
wave3

>> Download wave3 documenatation <<

Text preview - extract from the document

WF No. IC5000-1 (PLAY)   WF No. IC5000-2 (PLAY)   WF No. IC5000-10,14 (PLAY)   WF No. IC5000-22 (PLAY)




  5.6Vp-p(1usec/div)      0.84Vp-p(200usec/div)        80Vp-p(1usec/div)        0.84Vp-p(200usec/div)

WF No. IC5200-1 (PLAY)   WF No. IC5200-2 (PLAY)   WF No. IC5200-10,14 (PLAY)   WF No. IC5200-22 (PLAY)




   5.6Vp-p(1usec/div)     0.84Vp-p(200usec/div)        80Vp-p(1usec/div)        0.84Vp-p(200usec/div)

WF No. IC5300-1 (PLAY)   WF No. IC5300-2 (PLAY)   WF No. IC5300-10,14 (PLAY)   WF No. IC5300-22 (PLAY)




   5.6Vp-p(1usec/div)     0.84Vp-p(200usec/div)        80Vp-p(1usec/div)        0.84Vp-p(200usec/div)

WF No. IC5400-1 (PLAY)   WF No. IC5400-2 (PLAY)   WF No. IC5400-10,14 (PLAY)   WF No. IC5400-22 (PLAY)




   5.6Vp-p(1usec/div)     0.84Vp-p(200usec/div)        80Vp-p(1usec/div)        0.84Vp-p(200usec/div)

WF No. IC5500-4 (PLAY)   WF No. IC5500-6 (PLAY)     WF No. IC5500-8 (PLAY)     WF No. IC5701-1 (PLAY)




  6.8Vp-p(5msec/div)       5.2Vp-p(500nsec/div)      5.6Vp-p(500nsec/div)        300Vp-p(2usec/div)
