Image preview - the first page of the document



>> Download wave4 documenatation <<

Text preview - extract from the document

 WF No. IC5701-4 (PLAY)    WF No. IC5701-5,6 (PLAY)      WF No. IC5701-7 (PLAY)       WF No. IC5799-1,2,3,4 (PLAY)




   0.62Vp-p(5msec/div)        0.25Vp-p(5usec/div)           3.2Vp-p(2usec/div)             130Vp-p(2usec/div)

 WF No. IC6901-5 (PLAY)     WF No. IC8001-9 (PLAY)      WF No. IC8001-10 (PLAY)        WF No. IC8001-11 (PLAY)




   2.15Vp-p(2usec/div)        6.4Vp-p(5usec/div)           6.4Vp-p(5usec/div)              6Vp-p(5usec/div)

WF No. IC8001-12 (PLAY)    WF No. IC8001-13 (PLAY)      WF No. IC8001-14 (PLAY)        WF No. IC8001-17 (PLAY)




    6Vp-p(5usec/div)          6.4Vp-p(5usec/div)           6.4Vp-p(5usec/div)               6Vp-p(5usec/div)

WF No. IC8001-18 (PLAY)    WF No. IC8001-59 (PLAY)    WF No. IC8001-62,63,64 (PLAY)    WF No. IC8001-129 (PLAY)




    6.4Vp-p(5usec/div)        2.4Vp-p(2usec/div)           5.6Vp-p(2usec/div)             0.72Vp-p(20usec/div)

WF No. IC8001-130 (PLAY)   WF No. IC8001-131 (PLAY)    WF No. IC8001-138 (PLAY)        WF No. IC8001-139 (PLAY)




  0.72Vp-p(20usec/div)       0.42Vp-p(20usec/div)         1.05Vp-p(20usec/div)            0.9Vp-p(20usec/div)
