Image preview - the first page of the document
>> Download aa_ma_v2 documenatation <<
Text preview - extract from the document
Ref No. Q500 Q501 Q502 Q503
MODE E C B E C B E C B 1 2 3 4 5 6
CD PLAY 3.3 -3.9 3.2 0 0 0.6 0 3.3 0 -0.1 -7 -0.1 -0.1 -6.9 -0.1
STANDBY 2.2 2.2 1.5 0 0 0.6 0 3.3 0 0 -7 0 0 -7 0
Ref No. Q504 Q505 Q506
MODE 1 2 3 4 5 6 1 2 3 4 5 6 E C B
CD PLAY 0 -3.9 0 0 -3.9 0 0 -3.9 0 0 -3.9 0 0 11.5 0
STANDBY 0 0.4 0 0 0.7 0 0 0.7 0 0 0.7 0 0 11.5 0
Ref No. Q507 Q508 Q509 Q510
MODE E C B E C B E C B E C B
CD PLAY 3.2 -1.1 -0.5 10.8 11.5 11.4 1.2 0 -1.1 0.2 0 -1.1
STANDBY 3.2 -1.1 -0.5 10.8 11.5 11.4 1.2 0 -1.1 0 0 -1.1
Ref No. Q511 Q512 Q513 Q514
MODE 1 2 3 4 5 6 E C B E C B E C B
CD PLAY 4.9 4.9 4.9 0 0 0 0 0 0.6 0 0 0.6 0 0 0.6
STANDBY 4.9 4.9 4.9 0 0 0 0 0 0.6 0 0 0.6 0 0 3.1
Ref No. Q515 Q516 Q517 Q520
MODE E C B E C B E C B 1 2 3 4 5 6
CD PLAY 0.6 0 0 0 0 0.6 0 0 0.6 0 -7.1 0 0 -7.1 0
STANDBY 0 0 0.6 0 0 0.6 0 0 0.6 0 -7.1 0 0 -7.1 0
Ref No. Q521 Q522 Q523 Q550 Q560
MODE E C B E C B E C B E C B E C B
CD PLAY 3.2 3.2 2.5 0 0 0 0 0 0 -0.1 3.1 -0.1 3.2 -0.1 2.8
STANDBY 3.2 3.2 2.5 0 0 0 0 0 0 0 3.2 0 3.3 0 2.9
Ref No. Q561 Q562 Q563
MODE E C B 1 2 3 4 5 6 E C B
CD PLAY 3.2 -3.9 3.2 -0.1 -3.8 -0.1 -0.1 -3.9 -0.1 3.3 -3.9 3.2
STANDBY 3.3 -3.9 3.2 0 -3.9 0 0 -3.9 0 2.2 2.2 1.5
Ref No. Q566 Q567 Q568
MODE 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6
CD PLAY 5 5 0.5 5 5 5 4.9 4.9 0.5 5 4.9 4.9 9 9 0.8 9 9 9
STANDBY 5 5 0.5 5 5 5 5 5 0.5 5 5 5 9 9 0.8 9 9 9
Ref No. Q569
MODE 1 2 3 4 5 6
CD PLAY 2.4 2.4 0.2 2.5 2.4 2.4
STANDBY 2.4 2.4 0.2 2.4 2.4 2.4
Ref No. QR501 QR502 QR503
MODE 1 2 3 4 5 6 1 2 3 4 5 6 E C B
CD PLAY -0.1 -0.1 0 -0.1 4 4 -0.1 -0.1 0 -0.1 4 4 -0.1 4.9 -0.1
STANDBY 0 0 0 0 4.1 4.1 0 0 0 0 4.1 4.1 0 0 3.2
Ref No. QR504 QR505 QR506 QR507 QR508
MODE E C B E C B E C B E C B E C B
CD PLAY 3.3 -7.1 3.3 0 2.6 0 3.3 -7.1 3.3 0 0 3.1 0 0.1 3.3
STANDBY 3.3 -7.1 3.3 0 2.6 0 3.3 -7.1 3.3 0 0 3.1 0 0 3.3
Ref No. QR509 QR510 QR511 QR512 QR513
MODE E C B E C B E C B E C B E C B
CD PLAY 0 11.4 0.1 10.8 10.8 0.1 0 0.1 4.9 0 0 3.1 0 0 3.1
STANDBY 0 11.4 0 10.8 10.8 0.1 0 0.1 4.9 0 0 3.1 0 0 3.1
Ref No. QR514 QR515 QR516
MODE E C B E C B E C B
CD PLAY 0 0 3.1 0 0 3.1 0 0 3.1
STANDBY 0 0 0.6 0 0 3.1 0 0 3.1
SA-PTX7EB/EG MAIN P.C.B.
