Image preview - the first page of the document
>> Download aa_as_v2 documenatation <<
Text preview - extract from the document
Ref No. IC308
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 3.3 2.7 0.3 0 0.3 0.3 3.3 0.3 0.3 0 0.3 0.3 3.3 2.9 3.3 3.3 3.3 0 3.3 0
STANDBY 3.4 1.3 1.3 0 1.3 1.3 3.4 1.3 1.3 0 1.3 1.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 0
Ref No. IC308
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 0 0 0 0 3.3 0 0 0 0 0 0 0 - 3.3 1.7 3.3 - 3.3 3.3 3.3
STANDBY 0 0 0 0 3.4 0 0 3.4 3.4 3.4 0 0 - 0 0 3.4 - 3.4 1.3 1.4
Ref No. IC308
MODE 41 42 43 44 45 46 47 48 49 50
CD PLAY 0 0 0 3.3 0 0 0 0 0 0
STANDBY 0 1.3 1.4 3.4 1.4 1.4 0 1.4 1.4 0
Ref No. IC310
MODE 1 2 3 4 5
CD PLAY 3.3 0 0 0 3.3
STANDBY 3.3 0 0 0 3.3
Ref No. IC311
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
CD PLAY 4.8 3.3 0.1 0.1 1.6 0 1.6 1.6 - - 4.8 0 2.4 2.3 2.3 4.8
STANDBY 4.8 3.3 0.1 0.1 1.6 0 1.6 1.6 - - 4.8 0 2.4 2.3 2.3 4.8
Ref No. IC312 IC405
MODE 1 2 3 4 5 1 2 3 4 5 6 7 8
CD PLAY - 3.3 0 0 3.3 5 4.5 1.2 1.2 0.8 0 4 5
STANDBY - 3.3 0 0 3.3 5 4.5 1.2 1.2 0.8 0 4 5
Ref No. Q300 Q305 Q405
MODE E C B E C B 1 2 3 4 5 6
CD PLAY 3.3 3.3 2.7 0 0.6 0 1.3 1.3 3.5 5 1.3 1.3
STANDBY 3.3 3.3 2.7 0 0.6 0 1.3 1.3 4 5 1.3 1.3
Ref No. QR305
MODE E C B
CD PLAY 0 3.3 0.2
STANDBY 0 3.3 0.2
SA-PTX7EB/EG AUDIO(DSP) P.C.B.
