Image preview - the first page of the document
>> Download aa_dv_v3 documenatation <<
Text preview - extract from the document
Ref No. IC8601 IC8606 IC8611
MODE 1 2 3 4 1 2 3 4 5 1 2 3 4 5 6 7 8
CD PLAY 3.2 1.2 0.1 0 3.3 3.3 0 0 - 0 0 0 0 3.2 3.3 0 3.3
Ref No. IC8651
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 1.2 1.1 1.7 1.4 1.2 1.7 1.6 1.9 1.1 0 3.3 3.3 3.3 3.3 0.7 1.6 0.7 1.5 1.9 1.9
Ref No. IC8651
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 1.5 1.7 2 1.9 2.3 2 0 2.5 2.2 1.2 1 1.5 1.4 1.2 1.6 1.6 3.3 1.8 1.3 1.8
Ref No. IC8651
MODE 41 42 43 44 45 46 47 48
CD PLAY 1.8 1.5 1.6 2.1 1.8 0 3.3 0.8
Ref No. IC8701 IC8901 IC8902
MODE 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
CD PLAY - 1.5 0 1.3 3.3 3.3 3.3 0 3.3 3.3 3.2 3.3 0 3.3 3.3
Ref No. IC9001
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 2.2 1.9 2 1.6 1.5 1.8 1.8 1.3 0 2 1.4 1.9 1.9 1.6 1.7 2 1.9 2.3 3.3
Ref No. IC9002
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 1.8 1.6 0 0 1.4 1.5 1 1.2 0 2.1 1.1 1.2 1.6 1.4 1.2 1.6 1.6 1.9 3.3
Ref No. IC9003 IC9005
MODE 1 2 3 4 5 6 1 2 3 4 5 6 7 8
CD PLAY 1.5 0 1.6 1.7 3.3 1.6 0 4.9 4.9 3.3 3.3 1.4 1.4 1.4
Ref No. IC9006
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 3.3 2.9 3.3 0.1 0.1 0.1 0.1 3.3 0.1 0 - - 0 0 0 0 0 0 3.3
Ref No. Q3211 Q3216 Q3221 Q3231 Q3235
MODE E C B E C B E C B E C B E C B
CD PLAY 1.4 0.1 0.7 1.4 0.1 0.8 1.1 0.1 0.5 1.4 0.1 0.7 1.1 0.1 0.4
Ref No. Q3239 Q3901 Q3902 Q3903 Q3941
MODE E C B E C B E C B E C B E C B
CD PLAY 0.7 0.1 0.1 0 3.3 -0.4 3.3 5 3.3 3.3 5 3.3 3.5 3.5 3.5
Ref No. Q3942 Q8321 Q8325 Q8331 Q8335
MODE E C B E C B E C B E C B E C B
CD PLAY 0 3.3 0 1.1 0 0.4 1.5 0 0.9 1.1 0 0.4 1.5 0 0.9
Ref No. Q8341 Q8551 Q8552 Q8561 Q8562
MODE E C B E C B E C B E C B E C B
CD PLAY 1.5 0 0.9 0 4.9 0.1 4.9 0 4.9 1.3 3.7 1.9 4.3 2.3 3.7
Ref No. QR3261 QR3271 QR8111 QR8420
MODE E C B E C B 1 2 3 4 5 6 E C B
CD PLAY 0.1 4.8 0 0.1 4.8 0 0 0 1.2 0.1 0.1 3.9 0 4.9 0.1
Ref No. QR8571
MODE E C B
CD PLAY 3.3 3.3 0.1
SA-PTX7EB/EG DVD MODULE P.C.B.
