Image preview - the first page of the document



>> Download 7jbhdd1 documenatation <<

Text preview - extract from the document

We recommend backing up the tracks on the HDD regularly using a PC or NAS (Network Attached Storage). In the event that this
unit requires service and the music data is damaged or lost, you can restore music from the last time you backed up.

    The necessary equipment and recommended operating system for creating a backup:
     A PC operating with Windows XP SP2 installed
     A hard disk drive (HDD) with adequate available space, or a NAS device. Other media (DVD-R, etc.) cannot be used for
     creating a backup of your music library.
     When creating a backup, we recommend using a fast network connection such as 100BASE-T LAN.
     For further information about backups visit the following homepage.
     http://panasonic.jp/support/global/cs/audio



                     PC with Windows XP SP2 installed                                       Backup destination

                                                                       PC                              HDD(PC)


                                                                                                   Internal PC HDD
           HDD                    Music data




                                                                                                     NAS


                                                                                             Network Attached Storage



Preparation                                                        Note
1 Connect the unit to a PC network ( OI page 94), or               About backup data
   directly connect it to a PC ( OI page 84).                      The backup data is created with encryption. Therefore, backup
2 To display the picture turn on the television and select the     data cannot be played or copied to another device.
   appropriate video input to suit the connections to this unit.   Furthermore backups can only be restored on the unit from
3 Press [ ].                                                       which it was created.
4 Press [MUSIC COLLECTION] to switch the selector to
   "Music Collection".                                             Tips
                                                                   If you do not have the equipment required for creating a
Settings to check on the PC                                        backup
1     Create a folder using the name below, and set the
                                                                      Make certain to keep the recording source (CD, files, etc.).

      folder to "Shared". (This folder then becomes the             For information about the shared folder settings, see
      save destination for the backup data.)
                                                                    " Importing WMA/MP3 from a PC" ( OI page 44).
        Folder name: ptxbckup


2     Check the PC name.
