Image preview - the first page of the document
>> Download 7jwave1 documenatation <<
Text preview - extract from the document
WF No. IC102-28,31,36,39 (PLAY) WF No. IC103-28,31,36,39 (PLAY) WF No. IC104-28,31,36,39 (PLAY) WF No. IC105-24,25,26 (PLAY)
29Vp-p(200usec/div) 22Vp-p(200usec/div) 26Vp-p(5msec/div) 5.6Vp-p(10usec/div)
WF No. IC105-34,36,37,38 (PLAY) WF No. IC300-9 (PLAY) WF No. IC300-13 (PLAY) WF No. IC300-14 (PLAY)
5.8Vp-p(1usec/div) 4Vp-p(500nsec/div) 0.3Vp-p(200usec/div) 2.1Vp-p(200usec/div)
WF No. IC301-9 (PLAY) WF No. IC301-13,14 (PLAY) WF No. IC302-9 (PLAY) WF No. IC302-13,14 (PLAY)
4Vp-p(500nsec/div) 2.2Vp-p(200usec/div) 4Vp-p(500nsec/div) 2.2Vp-p(200usec/div)
WF No. IC303-9 (PLAY) WF No. IC303-13,14 (PLAY) WF No. IC505-1 (PLAY) WF No. IC505-7 (PLAY)
4Vp-p(500nsec/div) 2.2Vp-p(200usec/div) 0.4Vp-p(200usec/div) 2.5Vp-p(200usec/div)
WF No. IC506-1,7 (PLAY) WF No. IC507-1,7 (PLAY) WF No. IC508-1,7 (PLAY) WF No. IC509-1,7 (PLAY)
2.3Vp-p(200usec/div) 2.3Vp-p(200usec/div) 2.3Vp-p(200usec/div) 12Vp-p(200usec/div)
WF No. IC510-15,20,26 (PLAY) WF No. IC510-16,19,25 (PLAY) WF No. IC514-9 (PLAY) WF No. IC514-11 (PLAY)
0.4Vp-p(200usec/div) 2.4Vp-p(200usec/div) 0.7Vp-p(20usec/div) 1.3Vp-p(20usec/div)
