Image preview - the first page of the document
>> Download 7jueshc1 documenatation <<
Text preview - extract from the document
It is recommended that you use Panasonic s HDMI cable.
VIERA Link "HDAVI Control" Recommended part number:
VIERA Link "HDAVI Control" is a convenient function that offers RP-CDHG15 (1.5 m), RP-CDHG30 (3.0 m),
linked operation of this unit, and a Panasonic TV (VIERA) RP-CDHG50 (5.0 m), etc.
under "HDAVI Control". Non-HDMI-compliant cables cannot be utilized.
You can use this function by connecting the equipment with the
HDMI cable. See the operating instructions for connected
equipment for operational details. Functions made possible with VIERA Link
VIERA Link "HDAVI Control", based on the control functions "HDAVI Control" are...
provided by HDMI which is an industry standard known as
HDMI CEC (Consumer Electronics Control), is a unique One-touch theater playback
function that we have developed and added. As such, its You can turn on this unit and television, and start playing the
operation with other manufacturers' equipment that supports disc with a single press of a button.
HDMI CEC cannot be guaranteed. This operation is for "DVD/CD" only.
This unit supports "HDAVI Control 2" function. The TV with Press [ONE TOUCH PLAY].
"HDAVI Control 2" function enables the following operation: This function also works if you press
VIERA Link Control only with TV s remote control (for "HDAVI [ ] (PLAY) on this unit's remote
Control 2") (OI page 71). control when this unit is in standby
mode.
"HDAVI Control 2" is the newest standard (current as of
February, 2007) for Panasonic s HDAVI Control compatible [Note]
equipment. This standard is compatible with Panasonic's
Playback may not be immediately displayed on the television. If
conventional HDAVI equipment.
you miss the beginning portion of playback, press [ ] or
VIERA Link "HDAVI Control" [ ] to go back to where playback started.
compatible television
Power on link
HDMI IN The television automatically turns on and the corresponding
display appears when the following operations are performed
Audio cable with the television in standby mode. Audio output is also
(not included) automatically switched to this unit's speakers.
When you start playback on this unit.
AUDIO OPTICAL
When using the GUI (display screen) to perform an action.
OUT AUDIO
OUT OUT *
L
[e.g., Start menu screen (IO page 24)]
R Optical digital
L
TV IN
audio cable Power off link
R
(not included) When the television is turned off, this unit goes into standby
TV IN OPTICAL IN (TV) * mode automatically.
This function works only when "Music Collection", "DVD/CD"
or "TV Audio" is selected as the source on this unit.
Main unit When the television is turned on, this unit does not turn on
HDMI AV OUT
automatically.
HDMI cable
(not included) [Note]
Only this unit turns off when you press [ ] for shutting it down.
* Connect this when you want to output TV audio from this Other connected equipment compatible with VIERA Link
unit's speakers as digital audio. "HDAVI Control" stays on.
Preparation
1 Confirm that the HDMI connection (OI page 91) has been
made.
2 Set "VIERA Link" to "On" (OI page 87, HDMI menu).
3 To complete and activate the connection correctly, turn on
all VIERA Link "HDAVI Control" compatible equipment and
set the television to the corresponding HDMI input mode for
this unit.
Whenever the connection or settings are changed, reconfirm
the points above.
