Image preview - the first page of the document
>> Download 7840 - manual de servicio (versión usa) documenatation <<Text preview - extract from the document ORDER NO. MD0702009CE
A6
Speaker System
SB-HW750P
Colour
(K)... Black Type
(S)... Silver Type
Specification
Type 1 way, 1 speaker system (Bass reflex) (7" x 16-23/32" x 10-1/8")
Speaker unit(s) Impedance 6 Mass 4 kg (8.8 lbs)
Subwoofer 16 cm (6-1/2") cone type
Input power (IEC) 250 W (Max) Notes :
Output sound pressure 82 dB/W (1.0 m) 1. Specifications are subject to change without notice.
Frequency range 29 Hz - 220 Hz (-16 dB) Mass and dimensions are approximate.
36 Hz - 180 Hz (-10 dB) 2. Total harmonic distortion is measured by the digital spectrum
Dimensions (W x H x D) 178mm x 425mm x 257 mm analyzer.
CONTENTS
Page Page
1 System Combination 2 2.3. Disassembly of Woofer 4
1.1. System Breakdown 2 3 Connection of the Speaker Cables 5
1.2. Packaging Information 2 4 Connection of the Wiring Diagram 8
2 Assembling and Disassembling 3 5 Exploded view 9
2.1. Disassembly flow chart 3 5.1. Cabinet Parts Location 9
2.2. Disassembly of Net frame assembly 4 6 Replacement Parts List 11
