Image preview - the first page of the document
MQM0134DG220316REV4_SCHTB580_680_485_Popping_Noise


>> Download MQM0134DG220316REV4_SCHTB580_680_485_Popping_Noise documenatation <<

Text preview - extract from the document
Confidential

                  For Authorised Service Agents Only                                   Ref No: MQM0134DG220316REV4


       TECHNICAL INFORMATION
 A     BG         CY         E        FL            I         LT        MD        NL        S              TR              Date
 AL    BIH        CZ         EST      GB          IRL         LV        MK         P        SK             UA           19/11/2015
AND    BY         D          F        GR           IS         M         MNE       PL        SLO                  Country Reported
 B     CH         DK         FIN       H            L         MC        N         RO        SRB                   UK / Germany
Product Category:            Home Theatre / Sound Bar

Subject:                     Popping Noise


Model(s) Affected:           SC-HTB580
                             SC-HTB680
                             SC-HTB485

Symptom /               Intermittently a popping noise is heard from the subwoofer.
Cause:

Remedy / This modification applies to all units prior to: **6C*******
Method: Order and fit kit part number RFKZHTB580KT consisting of:
                         Part Number           Qty                 Description
                          REE1749-J             1                  GND wire
                        F1H1H102B052            1           1000pF/50V chip capacitor
                        F1H1H100B052            4            10pF/50V chip capacitor
                        D0GB101JA065            4               100 ohm resistor

  The modification consists of:
    1. Add 1pc 1000pF/50V chip capacitors to the DAMP PCB
    2. Change 4pcs resistors on the DAMP PCB from 0 ohm to 100 ohm
    3. Add 4 pcs 10pF/50V chip capacitor to the DAMP PCB
    4. Add GND wire between the Digital Receiver Module and the DAMP PCB
       Make sure to install the GND wire (REE1749-J) when replacing the PCB (REP4869BA)

  Step 1: Add 1pc 1000pF/50V chip capacitors to the DAMP PCB


                                                     DAMP PCB




                        Add 1000pF on C5617


Warranty Claims - Please use the following IRIS and Activity codes
      Activity Codes:       Guarantee Code           Activity          Location   Stock Indicator
            (UK Only)             A                    M                  W              D
                                      Symptom                       Section                Defect
                Condition                                                                                  Repair
IRIS Codes:                    Area     Type         Code       Area       Code    Area             Code
                   2            5          4         544           2       APD         2             S       i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected

                                                                                                                      Document No: MQM_TI
Panasonic                                                       1 of 3                                                 Rev: 12.00 DG110612
Confidential

                  For Authorised Service Agents Only                                Ref No: MQM0134DG220316REV4


       TECHNICAL INFORMATION
  Step 2: Change 4pcs resistors on the DAMP PCB from 0 ohm to 100 ohm


                        Change R5776/5777/5778/5779 from
                                                                                         DAMP PCB
                         0ohm to 100ohm (D0GB101JA065)




                                IC5201




                                                                  CN1000




  Step 3: Add 4 pcs 10pF/50V chip capacitor to the DAMP PCB


                                                    ADD CHIP CAP 10pF/50V                                          DAMP PCB
                                                       (F1H1H100B052)
                                                                     CN1000
                                                                  Pin24  Pin23                               CN1000
                                                                                                          Pin24  Pin22
                                                   IC5201
                                                                                          CN1000




                                      IC5201 Pin14  GND

   Carefully scrape off
                                                                  W1
  the PCB solder resist
     surface before                           W1(short jumper)  GND
        soldering


Continued ...
Warranty Claims - Please use the following IRIS and Activity codes
      Activity Codes:       Guarantee Code        Activity        Location       Stock Indicator
            (UK Only)             A                 M                W                  D
                                       Symptom                   Section                Defect
                Condition                                                                                   Repair
IRIS Codes:                    Area      Type    Code        Area       Code     Area              Code
                   2            5         4      544          2            APD     2                S          i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected


                                                                                                                      Document No: MQM_TI
Panasonic                                                    2 of 3                                                    Rev: 12.00 DG110612
Confidential

                  For Authorised Service Agents Only                               Ref No: MQM0134DG220316REV4


       TECHNICAL INFORMATION
  Step 4: Add GND wire between the Digital Receiver Module and the DAMP PCB




                                                  Digital Receiver Module




                                                                           DAMP PCB

                                      ADD GND WIRE (REE1749)




Warranty Claims - Please use the following IRIS and Activity codes
      Activity Codes:       Guarantee Code       Activity          Location     Stock Indicator
            (UK Only)             A                M                  W                D
                                       Symptom                   Section                Defect
                Condition                                                                            Repair
IRIS Codes:                    Area      Type    Code       Area       Code      Area        Code
                   2            5         4      544         2         APD        2              S     i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected

                                                                                                              Document No: MQM_TI
Panasonic                                                   3 of 3                                             Rev: 12.00 DG110612
