Image preview - the first page of the document
>> Download MQM0134DG220316REV4_SCHTB580_680_485_Popping_Noise documenatation <<
Text preview - extract from the document
Confidential
For Authorised Service Agents Only Ref No: MQM0134DG220316REV4
TECHNICAL INFORMATION
A BG CY E FL I LT MD NL S TR Date
AL BIH CZ EST GB IRL LV MK P SK UA 19/11/2015
AND BY D F GR IS M MNE PL SLO Country Reported
B CH DK FIN H L MC N RO SRB UK / Germany
Product Category: Home Theatre / Sound Bar
Subject: Popping Noise
Model(s) Affected: SC-HTB580
SC-HTB680
SC-HTB485
Symptom / Intermittently a popping noise is heard from the subwoofer.
Cause:
Remedy / This modification applies to all units prior to: **6C*******
Method: Order and fit kit part number RFKZHTB580KT consisting of:
Part Number Qty Description
REE1749-J 1 GND wire
F1H1H102B052 1 1000pF/50V chip capacitor
F1H1H100B052 4 10pF/50V chip capacitor
D0GB101JA065 4 100 ohm resistor
The modification consists of:
1. Add 1pc 1000pF/50V chip capacitors to the DAMP PCB
2. Change 4pcs resistors on the DAMP PCB from 0 ohm to 100 ohm
3. Add 4 pcs 10pF/50V chip capacitor to the DAMP PCB
4. Add GND wire between the Digital Receiver Module and the DAMP PCB
Make sure to install the GND wire (REE1749-J) when replacing the PCB (REP4869BA)
Step 1: Add 1pc 1000pF/50V chip capacitors to the DAMP PCB
DAMP PCB
Add 1000pF on C5617
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Code Activity Location Stock Indicator
(UK Only) A M W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
2 5 4 544 2 APD 2 S i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 1 of 3 Rev: 12.00 DG110612
Confidential
For Authorised Service Agents Only Ref No: MQM0134DG220316REV4
TECHNICAL INFORMATION
Step 2: Change 4pcs resistors on the DAMP PCB from 0 ohm to 100 ohm
Change R5776/5777/5778/5779 from
DAMP PCB
0ohm to 100ohm (D0GB101JA065)
IC5201
CN1000
Step 3: Add 4 pcs 10pF/50V chip capacitor to the DAMP PCB
ADD CHIP CAP 10pF/50V DAMP PCB
(F1H1H100B052)
CN1000
Pin24 Pin23 CN1000
Pin24 Pin22
IC5201
CN1000
IC5201 Pin14 GND
Carefully scrape off
W1
the PCB solder resist
surface before W1(short jumper) GND
soldering
Continued ...
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Code Activity Location Stock Indicator
(UK Only) A M W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
2 5 4 544 2 APD 2 S i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 2 of 3 Rev: 12.00 DG110612
Confidential
For Authorised Service Agents Only Ref No: MQM0134DG220316REV4
TECHNICAL INFORMATION
Step 4: Add GND wire between the Digital Receiver Module and the DAMP PCB
Digital Receiver Module
DAMP PCB
ADD GND WIRE (REE1749)
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Code Activity Location Stock Indicator
(UK Only) A M W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
2 5 4 544 2 APD 2 S i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 3 of 3 Rev: 12.00 DG110612
