Image preview - the first page of the document
>> Download MD0803016AE_PRINTDB documenatation <<
Text preview - extract from the document
ORDER NO. MD0803016AE
Wireless System and Digital Transmitter
SH-PT467EG
SE-FX65AEG
SH-FX65TEG
Colour
(K)..........Black Type
Please use this manual together with the service manual for Model No. [SH-PT350EG-K, SE-FX65EG-K,
SH-FX65TEG-K, Order No. MD0704032CE].
Specification
I AMPLIFIER SECTION SH-FX65T 65 mm x 52 mm x 8.6 mm
RMS output power SE-FX65A 165 mm x 90 mm x 164 mm
Surround Ch 125 W per channel (3 ), 1 kHz, 10 Mass
% THD SH-FX65T 0.02 kg
Total RMS power 250 W SE-FX65A 0.655 kg
DIN output power Power consumption in off mode approx. 0.3 W
Surround Ch 70 W per channel (3 ), 1 kHz, 1 %
THD
Notes:
Total DIN power 140 W
1. Specifications are subject to change without notice.
Mass and dimensions are approximate
I RF SECTION
2. Total harmonic distortion is measured by a digital spectrum
Wireless module analyzer
Frequency range 2.400 GHz to 2.4835 GHz Power supply:
No. of channels 3 This model uses Switching Mode Power Supply (SMPS) Module for
powering the receiver unit. It is replaceable as an assembly unit.
I GENERAL TX / RX Module P.C.B.:
Power supply AC 230 V to 240 V, 50 Hz It is replaceable as a TX / RX kit assembly.
Power consumption I System : SH-PT467EG-K Wireless Receiver: SE-FX65AEG-K
SH-FX65T 1.5 W Wireless Transmitter: SH-FX65TEG-
SE-FX65A 43 W K
Dimensions (W x H x D)
