Image preview - the first page of the document
>> Download 7347 - manual de servicio -8- lista de piezas documenatation <<
Text preview - extract from the document
EXPLODED VIEWS &
REPLACEMENT PARTS LIST
Model No. : AG-HPX500P/E/MC, AG-HPX502EN
CONTENTS
CASING & FRAME PARTS ASSEMBLY (1) ...................................................................................MPL-1
CASING & FRAME PARTS ASSEMBLY (2) ...................................................................................MPL-3
SIDE CASE (R) PARTS ASSEMBLY...............................................................................................MPL-5
CAMERA PARTS ASSEMBLY (1) ...................................................................................................MPL-7
CAMERA PARTS ASSEMBLY (2) ...................................................................................................MPL-9
TOP CASE & HANDLE PARTS ASSEMBLY ..................................................................................MPL-11
REAR JACK PARTS ASSEMBLY....................................................................................................MPL-13
BACK CASE PARTS ASSEMBLY ...................................................................................................MPL-15
LCD PARTS ASSEMBLY.................................................................................................................MPL-17
VF PARTS ASSEMBLY ...................................................................................................................MPL-19
PACKING PARTS ASSEMBLY........................................................................................................MPL-21
ELECTRICAL REPLACEMENT PARTS LIST .................................................................................EPL-1
ELECTRICAL REPLACEMENT PARTS LIST (VF SECTION) ........................................................EPL-29
CASING & FRAME PARTS ASSEMBLY (1)
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type. 107
109 1
E6
101
E2
107
101
25 3
106 E5
16 107
6
106 107 E1
107
E3
107 2
10 17
7 14 14
107
102 105 E27
9
E8 E17 E4
4 107
101 E7 107
104 107
8 107
E9 12
107 14 18
101
11
108 108 5
101 108
101
19
24
23
110
21
13
20
22
108
26
MPL-1
CASING & FRAME PARTS ASSEMBLY (1)
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VMP8838 INNNDER FRAME TOP 1
2 VMP8839 INNER FRAME BOTTOM 1
3 VEE1D61 L SIDE JACK CABLE 1
4 VGQ9428 SD CARD GUIDE 1
5 VYK2D61 CARD GUIDE U 1
6 K1TYYYY00040 COAXIAL CABLE 1
7 VMP8842 SIDE BNC ANGLE 1
8 VMT1820 SIDE BNC CUSHION 1
9 VMT1858 SOFT HIGH SHIELD GASKET 1
10 VEE1D76 USB CABLE 1
11 VWJ40H2210L0 FFC 2
12 VWJ30G6060L0 FFC 1
13 VWJ00H9 FFC 1
14 VJF1535 COATING CLIP 3
16 VEE1D60 REAR JACK CABLE 1
17 VMZ3735 POWER SUB COVER 1 1
18 VMZ3736 POWER SUB COVER 2 1
19 VYP9230 SIDE CASE L U 1
20 VMG1793 USB CAP 1
21 VMG1796 GUARD 1
22 VMG1802 RCA CAP 1
23 VGB0677 P2HD BADGE 1
24 VGB0625 PANA BADGE 1
25 VGF1076 TOP COVER 1
26 VMG1794 BNC CAP 2
101 XYN26+J6FJ SCREW 8
102 XYN2+J6FJ SCREW 2
104 XTB3+12GFJK SCREW 5
105 XSB3+6FJK SCREW 1
106 XSB3+16FJK SCREW 2
107 XYN26+J6FJ SCREW 18
108 XYN2+J6FJK SCREW 5
109 XSB3+8FJK SCREW 4
110 VHD1774 SCREW 1
E1 VEP23669A CAMERA P.C.BOARD 1
E2 VEP01989A CAMERA POWER P.C.BOARD 1
E3 VEP01988A POWER MAIN P.C.BOARD 1
E4 VEP01990A POWER SUB P.C.BOARD 1
E5 VEP03H11A CODEC MOTHER P.C.BOARD 1
E6 VEP04919A AUDIO MOTHER P.C.BOARD 1
E7 VEP03H12A P2 CARD A P.C.BOARD 1
E8 VEP03H12B P2 CARD B P.C.BOARD 1
E9 VEP001S3A SD CARD P.C.BOARD 1
E17 VEP04920A L SIDE JACK P.C.BOARD 1
E27 VEP001S2A USB CN P.C.BOARD 1
MPL-2
CASING & FRAME PARTS ASSEMBLY (2)
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.
111
111
23
111
111
6
112
20
112 12
22
21
19
107
24
10 104
107
24 104
16 112
15 13 104
104
111 104
2
111 18
9
E23
111 109 17 107
7
108
112 E22 4
111 14
11 8
108 109
1
110
105
106
101
105 5
102
3
103
MPL-3
CASING & FRAME PARTS ASSEMBLY (2)
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VGM2239 BOTTOM CASE 1
2 VMP8835 BOTTOM FRAME 1
3 VYQ2306 FOOT BASE U 1
4 VMP4853 LENS CONNECTOR PLATE 1
5 VKC0560 HINGE 1
6 J0KG00000083 FILTER 1
7 VEE1D67 LENS CABLE 1
8 VLP0123 FERRITE CORE 1 J0KG00000001
9 VSC5989 MIC SHIELD 1 1
10 VSC5969 FRONT FRAME 1
11 VGP6217 SIDE L MIC PLATE 1
12 VJF1564 LOCKING CLAMP 1
13 VEE1D79 FRONT MIC CABLE 1
14 VMT1845 SOFT HIGHT SHIELD GASKET 1
15 VLP0123 FERRITE CORE 1 J0KG00000001
16 VJF1559 CLAMPER 1
17 VWJ10H2065L0 10PIN 65MM FFC 1
18 J0ZZZ0000053 FILTER 2
19 VSC5988 MIC SHIELD 1 1
20 VMT1861 SOFT HIGH SHIELD GASKET 1
21 J0KD00000104 FILTER CORE 1
22 VJF1562 LOCKING CLAMP 1
23 VQL1P53 FCC/DOC LABEL 1 FOR AJ-HPX500P
24 VMZ3356 FPC PROTECT SHEET 2
101 XWE26FJK WASHER 2
102 XYN26+A8FJK SCREW 2
103 XSS3+8FJK SCREW 4
104 XYN26+J6FJ SCREW 6
105 XTN26+8JFJK SCREW 2
106 VHD1774 SCREW 1
107 XYN26+J8FJ SCREW 4
108 XTN26+8JFJK SCREW 2
109 XWE26FJK SCREW 2
110 XSB3+6FJK SCREW 2
111 XSB3+8FJK SCREW 8
112 VHD1952 SCREW 4
E22 VEP04921A F MIC CH1 P.C.BOARD 1
E23 VEP04924A F MIC CH2 P.C.BOARD 1
MPL-4
Components identified with the mark have the special characteristics for safety.
SIDE CASE (R) PARTS ASSEMBLY When replacing any of these components, use only the same type.
39
53
107
52
107
49
33 50
103
26 20
23 20 22
18 21
24
20
112
109 51
112
31 37 55
35 34
11
112
108 15 112
E28
112 14 101
43 19
113
108
108 1
108 13
38 42
16
28 113
27 113
108 102
E16 3
E20 45
111
25
108 48
112
106
113
E15
E21
108 2
111
9
54 108
4 10
105
111
104
105
104
105 29
12 6
105
17 5
36
104 32
E20 104
44
8
40 41 46
103
105 7 47
110
104
111
MPL-5
SIDE CASE (R) PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
E16 VEP001R4A R SIDE 2 P.C.BOARD 1
1 VEE1D62 HEADPHONE CABLE 1 E20 VEP001R5A POWER SW P.C.BOARD 1
2 VEE1D63 R SIDE1 CABLE 1 E21 VEP001R6A TOGGLE SW P.C.BOARD 1
3 VWJ50G6045L0 PREPRO OUT DAT 1 E28 VEP04923A PHONE CN P.C.BOARD 1
4 VYP9233 SIDE CASE R 1 U 1
5 VYF3154 CONTROL DOOR U 1
6 VGH4949 CONTROL PANEL 1
7 VGH4951 INDICATER PLATE A 1
8 VMS7832 SHAFT 1
9 VGH4952 INDICATER PLATE B 1
10 VGH4953 INDICATER PLATE C 1
11 VKN0185 SPEAKER NET 1
12 VMG1638 PHONE JACK COVER 1
13 VGU9660 USER RUBBER BUTTON 2
14 VGP6075 CONTROL PANEL 1
15 VKF3918 SLIDE DOOR 1
16 VGU0B46 MENU BUTTON 1
17 VMG1506 DOOR CUSHION 1
18 VGK3031 TOGGLE SW PLATE 1
19 VGU9695 RUBBER BUTTON (B) 1
20 VMG1096 VR RAIN COVER PACKING 3
21 VMZ0624 BONDING TAPE A 1
22 VZT0625 BONDING TAPE B 1
23 VMS7187 LCD LOCK SHAFT 1
24 VMB3659 MONITOR OPENER SPRING 1
25 VYF2895 OPERATION PANEL (B)U 1
26 VGU9675 MONITOR LOCK KNOB 1
27 VMC1837 SLIDE PLATE SPRING 1
28 VMP8366 GUIDE PLATE 1
29 VMG1804 LCD RUBBER 2
31 VGQ8202 MONITOR POP UP 1
32 VMP8096 DOOR STAND ANGLE 1
33 VMP7331 OPENER HOLDER ANGLE 1
34 VMS7294 POP UP PIN 1
35 VMB3996 POP UP SPRING 1
36 VGU0B30 MODE SW KNOB 1
37 VGQ9489 PANEL LIGHT B 3
38 VGU0B26 RUBBER BUTTON A 1
39 VGU0B27 RUBBER BUTTON B 1
40 VGU9301 VR KNOB FRONT 1
41 VGU9303 VR KNOB 1
42 VGU9304 OPERATION RUBBER BUTTON 1
43 VGU8993 OPERATION BUTTON 1
44 VGH4633 MODE SELECT NAME PLATE 1
45 VMG0646 WATERPROOF SW INSULATION SH 4
46 VGH4680 VR NAME PLATE 1
47 VGH4948 VF LABEL 1
48 VMT1494 WATERPROOF CUSHION 4
49 VEK0L21 SPEAKER U 1
50 VMP7351 SPEAKER HOLD ANGLE 1
51 VMX0531 CLATCH SPACER 1
52 VGL1228 LED PANEL LIGHT 2
53 VYQ4079 FACE PAD U 1
54 VMZ3704 SIDE R BARRIER 1
55 VMZ3692 LCD FFC SHEET 1
101 XTN3+6GFJ SCREW 1
102 XQN2+BJ4FJK SCREW 1
103 XYN2+C4FJ SCREW 4
104 XSB3+10FJK SCREW 5
105 VMX3348 WASHER 5
106 VMX1312 POLY WASHER 4
107 XYN3+C5FJ SCREW 2
108 XYN2+J6FJ SCREW 15
109 VHN0382 NYLON NUT 1
110 XQN2+A2FJK SCREW 1
111 XYN2+J6FJ SCREW 5
112 XTB26+6GFJK SCREW 7
113 XYN2+F5FJ SCREW 8
E15 VEP001T0A R SIDE 1 P.C.BOARD 1
MPL-6
Components identified with the mark have the special characteristics for safety.
CAMERA PARTS ASSEMBLY(1) When replacing any of these components, use only the same type.
103
10
11
103
10
103
E24 9
1
102
6
101
104
7 101
8
104
E10
103
102
2 5
3
4
102
102
102
MPL-7
CAMERA PARTS ASSEMBLY (1)
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VYQ4076 HEAD OPTICAL U 1
2 VMA0V43 HEAT SINK R 1
3 VMA0V44 HEAT SINK G 1
4 VMA0V45 HEAT SINK B 1
5 VMA0V41 HEAT SINK BASE 1
6 VXQ1523 L.P.FILTER U 1
7 VDW1228 LENS MOUNT RING 1
8 VKF2997 CAP 1
9 VSC5996 OPTICAL SHIELD 1
10 VMT1861 SOFT HIGH SHIELD GASKET 2
11 VEE1D66 CABLE 1
101 XQS2+A4FJK SCREW 3
102 XYN26+F6FJ SCREW 6
103 XYN2+J5FJ SCREW 7
104 XSB3+6FJK SCREW 4
E10 VEP22379A CCD FLEX P.C.BOARD 1
E24 VEP80D27A POSITION SENSOR P.C.BOARD 1
MPL-8
Components identified with the mark have the special characteristics for safety.
CAMERA PARTS ASSEMBLY (2) When replacing any of these components, use only the same type.
102
2
104 3
102 1
12
104
2
4
6
101
7 5
E25
8
103
9 11 103
10
E18
9
10
103
11
13
103
MPL-9
CAMERA PARTS ASSEMBLY (2)
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VYK2D52 FRONT CASE 1 U 1
2 VJF1256 CABLE CLAMPER 2
3 VMG0948 EVF RUBBER SHIELD 1
4 VMC1210 FRONT DOOR SPRING 1
5 VMP4850 FRONT DOOR ANGLE 1
6 VMS4088 FRONT DOOR ANGLE PIN 1
7 VKF2485 FRONT DOOR 1
8 VXU1620 RUBBER BUTTON ASS'Y 1
9 VMG1140 RAIN COVER SPONGE 2
10 VMX1312 POLY WASHER 2
11 VMT1432 WATERPROOF CUSHION 2
12 VGU9860 FILTER KNOB 1
13 VEE1D64 CABLE 1
101 XYN2+C4FJ SCREW 1
102 XSB2+4FJK SCREW 2
103 XYN2+J6FJ SCREW 5
104 XXE26W3FP HEX SCREW 2
E18 VEP001R9A FRONT SW P.C.BOARD 1
E25 VEP001S0A REC BUTTON P.C.BOARD 1
MPL-10
TOP CASE & HANDLE PARTS ASSEMBLY
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.
109
109
except
9 , 106 , E19 , E26 12
14
21
104 16
20
18 13 105
17 105 9 E26
105
7
15
E19
107 19
106
23
106
5 22
107 107
107
103
102
103
102 107
3
4 26 26
2 110
103
1
102
111
25
101
108
108
11
108 24
108 10
6
8
MPL-11
TOP CASE & HANDLE PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VGM2211 TOP CASE 1
2 VGM2232 VF MOUNT BLOCK 1
3 VGP5629 VF LOCK RING 1
4 VGM2130 VF BASE 1
5 VQL1P06 VF RING LOCK LABEL 1
6 VLP0186 FERRITE CORE 1 J0KE00000027
7 VJF1319 SHOE 1
8 VEE1D68 CABLE 1
9 VEE1D65 HANDLE CABLE 1
10 VMT1631 VF CORE CUSION 1
11 VJF1535 COATING CLIP 1
12 VYH0375 HANDLE U 1
13 VGL1113 TALLY COVER 1
14 VGH4770 REC LABEL 1
15 VMT1590 HANDLE SPONGE (2) 1
16 VGU9695 RUBBER BUTTON (B) 1
17 VGU9214 SLIDE KNOB 1
18 VMG1460 SLIDE SW RUBBER COVER 1
19 VMG0955 P4 O-RING 1
20 VMG0956 P8 O-RING 1
21 VKF3917 HANDLE COVER 1
22 VQL1D81 GPS LABEL 1
23 VMG1710 GPS BLANK CAP 1
24 VJF1563 PRESS CLAMP 1
25 VMP8834 TOP FRAME 1
26 VJF1531 CABLE CLAMPER 2
101 XSS2+4FJK SCREW 2
102 VHD1793 HEX SCREW 3
103 XWA3BFJK SCREW 3
104 XSN2+6FJK SCREW 4
105 XYN2+F6FN SCREW 5
106 XSB4+8FJK SCREW 2
107 XSB3+8FJK SCREW 12
108 XYN26+J6FJ SCREW 12
109 XSB2+6FJK SCREW 2
110 XSB4+6FJK SCREW 2
111 XVE4A25VW HEX SCREW 2
E19 VEP80D06A HANDLE SW P.C.BOARD 1
E26 VEP80D07A HANDLE TALLY P.C.BOARD 1
MPL-12
Components identified with the mark have the special characteristics for safety.
REAR JACK PARTS ASSEMBLY When replacing any of these components, use only the same type.
13
11
106
2
2 4
106
E29 10
E11
106
12
4
1
105
104
106
6
8
104
103 9
101 14
3
5
15
7
E14
102
MPL-13
REAR JACK PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VEJ2282 REAR JACK 1U 1
2 VGU9300 SLIDE SW BUTTON 2
3 VMG1511 RUBBER CAP C 1
4 VMG1085 RAIN COVER RUBBER 2
5 VEE1D69 ECU CABLE 1
6 VGL1038 BOTTOM TALLY COVER 1
7 VEE1D70 DC OUT CABLE 1
8 K1SYYYYA0002 BNC CONNECTOR 1
9 VMG1792 1394 CONNECTOR CAP 1
10 VMG1801 D-CN CAP 1
11 VYK2E72 BOTTOM COVER U 1
12 VMP8676 BACK LOCK ANGLE 1
13 VMT1591 SHOULDER PAD 1
14 VMG1794 BNC CAP 1
15 VMG1636 XLR CONNECTOR CAP 1
101 XYN26+A6FJK SCREW 4
102 XSN26+6FC SCREW 2
103 XQN2+BJ6FJK SCREW 2
104 XSB2+6FJK SCREW 2
105 XSB3+6FJK SCREW 2
106 XSB3+6FJK SCREW 8
E11 VEP04922A REAR JACK P.C.BOARD 1
E14 VEP01993A DC IN P.C.BOARD 1
E29 VEP001S1A 1394 CN P.C.BOARD 1
MPL-14
Components identified with the mark have the special characteristics for safety.
BACK CASE PARTS ASSEMBLY When replacing any of these components, use only the same type.
104
102
102
6
4
101
105 101
9
106 2
15
105
E13
106
12
8 1
103
14 3 11
8
13
7
10 103
5
MPL-15
BACK CASE PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VEE1D71 ANTON BOX U1 CABLE 1
2 VYK2D58 BACK CASE 1U 1
3 VJF1476 BATTERY ADAPTOR B 1
4 VGF0960 CONNECTOR COVER 1
5 VJF1347S ANTON BRACKET 1
6 VKC0601 HINGE (REAR) 1
7 VJF1498 TERMINAL HOLDER 1
8 VJR0696 CONNECTION TERMINAL 2
9 VGF1057 BACK BLIND SHEET 1
10 VEUC7R090ACF CABLE 1
11 VEUC7B090ACF CABLE 1
12 VLP0123 FERRITE CORE 1 J0KG00000001
13 VGQ9553 AMP BASE 1
14 VJF1559 CLAMPER 1
15 VMZ3723 BACK CASE BARRIER 1
101 VMX2605 WASHER 2
102 XSN26+6FJK SCREW 2
103 XSB3+4FJK SCREW 2
104 VHD1774 SCREW 1
105 XYN26+J6FJ SCREW 2
106 XYN26+J4FJ SCREW 2
E13 VEP001U0A BATTERY IF P.C.BOARD 1
MPL-16
LCD PARTS ASSEMBLY
1
7
8
9
E12
101
6
2 101
3
101
5
101
4
MPL-17
LCD PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VYK2D59 LCD U 1
2 VGQ9474 HINGE COVER (LOWER) 1
3 VGQ9423 HINGE COVER UE 1
4 VXD0465 HINGE 1
5 VMG1286 CUSHION RUBBER 1
6 VGP6209 LCD CASE TOP 1
7 VGP6152 LCD CASE BOTTOM 1
8 VMT1717 WATER PROOF PAD 1
9 VMZ3610 LCD PCB INSULATION SHEET 1
101 XQN16+B4FJK SCREW 6
E12 VEP08346B MONITOR P.C.BOARD 1
MPL-18
Components identified with the mark have the special characteristics for safety.
VF PARTS ASSEMBLY When replacing any of these components, use only the same type.
10
5
106
106
12
8
6
24 105
11
106
28
104
107
23 27
22
include
13 , 14 , 41 , 101 , 105 15
21
107
107 102
26
25 20
31
107
30
26
102 16 18
101 13
2 E4
36 17
14
41
E3
E5
43
34 33 42 44
35 105
19
32 E2
105
38 45 E1
105
40
3 1
39
108
37
4
7
9
8
103
29 6
MPL-19
VF PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VYC0936 MIC HOLDER U 1
2 VQL1P71 CAUTION LABEL 1
3 VQL1K49 HIGH VOLTAGE LABEL 1
4 EVD601 TOP CASE U 1
5 EV0102 BOTTOM CASE U 1
6 VMX3152 SPACER SHEET (A) 2
7 VHD1487 STOPPER SCREW 1
8 VMC1513 PLATE SPRING (A) 2
9 VMP7012 STOPPER PLATE 1
10 VGH4524 FRONT SHEET 1
11 VGF0902 BLIND SHEET 1
12 VMP6993 P.C.B. HOLDER ANGLE (F) 1
13 VGU7688 SLIDE SW COVER 2
14 VMG1085 RAIN COVER RUBBER 2
15 EV7G01 CRT/DY CONNECTOR U 1
16 VMD5727 MASK 1
17 VMD5726 HIGH VOLTAGE BASE 1
18 VMG1805 BASE PACKING 1
19 VEE1D94 GND CON/EARTH PLATE CABLE 1
20 540067F DEFLECTION YOKE 1
21 VGP5615 CRT CASE (UPPER) 1
22 VGP5616 CRT CASE (BOTTOM) 1
23 VMG1410 RUBBER CUSHION 1
24 VMC1741 PLATE SPRING (B) 1
25 VMS7089 SHAFT 1
26 VMX3153 SPACER 2
27 VMT1274 P.C.BOARD CUSHION 1
28 VDL1223 MIRROR 1
29 VMG1414 EYE CAP 1
30 VMX3242 SLIP RING 1
31 VMG1221 LENS LOCK PACKING 1
32 VMC1742 PLATE SPRING (C) 1
33 VGP5617 EYEPEACE HOLDER 1
34 VGU8954 LOCK KNOB 1
35 VMB3567 SPRING 1
36 VMS7075 SPRING PIN 1
37 VGQ6366 MOUNT RING 1
38 VDK0168 LENS HOLDER 1
39 VDL1222 LENS 1
40 VDS0162 LENS HOLDER RING 1
41 VMZ3724 INSULATION SHEET 1
42 VMZ3725 PROTECT TAPE 1
43 VEE1C83 VF CABLE 1
44 VWJ12H2056L0 FFC 1
45 EVQ601 MASK CASE U
101 XWGV3F6G WASHER 2
102 XUC15FP E-RING 2
103 XQN2+B25FJK SCREW 1
104 XQN2+BJ4FJK SCREW 2
105 XYN26+J5FJ SCREW 5
106 XSB26+10FJK SCREW 4
107 XTN26+8GFJK SCREW 4
108 XSB4+12FJK SCREW 2
E1 VEP20C09A MAIN P.C.BOARD 1
E2 VEP20C10A SUB1 P.C.BOARD 1
E3 VEP20C11A SUB2 P.C.BOARD 1
E4 VEP20C12A LED A P.C.BOARD 1
E5 VEP20C13A LED B P.C.BOARD 1
MPL-20
Components identified with the mark have the special characteristics for safety.
PACKING PARTS ASSEMBLY When replacing any of these components, use only the same type.
8
P/E/MC/EN only
5 13
2
P/E/MC/EN only
12
1
6
3
9
11
10
4
7
14 MC only
MPL-21
PACKING PARTS ASSEMBLY
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
1 VQT1G18 OPERATING INSTRUCTIONS 1 FOR AJ-HPX500P
1 VQT1G19 OPERATING INSTRUCTIONS 1 FOR AJ-HPX500E
1 VQT1G20 OPERATING INSTRUCTIONS 1 FOR AJ-HPX500MC
1 VQT1G21 OPERATING INSTRUCTIONS 1 FOR AJ-HPX502EN
2 VFB0203 CAMERA ACCESSORY U 1
3 VPN6613 CUSHION (TOP) 1
4 VPN6614 CUSHION (BOTTOM) 1
5 VFC4148 SHOULDER BELT 1
6 VFC4289 ACCESSORY (1)U 1
7 VPG1N75 PACKING CASE 1 FOR AJ-HPX500P
7 VPG1N77 PACKING CASE 1 FOR AJ-HPX500E
7 VPG1N78 PACKING CASE 1 FOR AJ-HPX500MC
7 VPG1N79 PACKING CASE 1 FOR AJ-HPX502EN
8 VPN6615 PARTITION 1
9 VPF1244 POLYETHYLENE BAG A 1
10 VPF0892 POLYETHYLENE BAG (2) 1
11 VPF1176 POLYETHYLENE BAG 1
12 VYC0968 D TERMINAL CABLE U 1
13 K2RYYYYY0001 ADAPTOR PLUG 1
14 VPG1P51 PACKING CASE 1 FOR AJ-HPX500MC
MPL-22
ELECTRICAL REPLACEMENT PARTS LIST
Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
E1 VEP23669A CAMERA P.C.BOARD 1 (RTL) E1 VEP23669A CAMERA P.C.BOARD 1 (RTL)
E2 VEP01989A CAMERA POWER P.C.BOARD 1 (RTL)
C1-19 ECJ0EC1H101J C.CAPACITOR CH 50V 100P 19
E3 VEP01988A POWER MAIN P.C.BOARD 1 (RTL) C100 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 1
C103 F1H1H104A783 C.CAPACITOR CH 50V 0.1U 1
E4 VEP01990A POWER SUB P.C.BOARD 1 (RTL) C104 ECJ1VB0J225K C.CAPACITOR CH6.3V 2.2U 1
C105-07 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 3
E5 VEP03H11A CODEC MOTHER P.C.BOARD 1 (RTL) C108 ECJ2FB1H104K C.CAPACITOR CH 50V 0.1U 1
C109 F1H1H104A783 C.CAPACITOR CH 50V 0.1U 1
E6 VEP04919A AUDIO MOTHER P.C.BOARD 1 (RTL) C110 ECJ1VB0J225K C.CAPACITOR CH6.3V 2.2U 1
C111-13 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 3
E7 VEP03H12A P2 CARD A P.C.BOARD 1 (RTL) C114 ECJ2FB1H104K C.CAPACITOR CH 50V 0.1U 1
C115-22 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 8
E8 VEP03H12B P2 CARD B P.C.BOARD 1 (RTL) C123 F3F1A106A046 T.CAPACITOR CH 10V 10U 1
C124,25 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 2
E9 VEP001S3A SD CARD P.C.BOARD 1 (RTL) C126 F3F1A106A046 T.CAPACITOR CH 10V 10U 1
C127,28 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 2
E10 VEP22379A CCD FLEX P.C.BOARD 1 (RTL) C129 F3F1A106A046 T.CAPACITOR CH 10V 10U 1
C130 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 1
E11 VEP04922A REAR JACK P.C.BOARD 1 (RTL) C131,32 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
