Image preview - the first page of the document



>> Download dsc1510023ce documenatation <<

Text preview - extract from the document

                                                                                                                   ORDER NO. DSC1510023CE
                                                                                                                                      B26




                                                              Interchangeable Lens for Digital Camera
                                                                             Model No. H-H025PP
                                                                                               H-H025E
                                                                                               H-H025GK
                                                                             Coulor
                                                                             (K)..........Black Type
                                                                             (S)..........Silver Type




TABLE OF CONTENTS
                                                                   PAGE                                                                  PAGE
 1 Safety Precautions----------------------------------------------- 2             7.1. ABOUT THE LENS -------------------------------------- 15
    1.1. Information for Your Safety------------------------------ 2            8 Exploded View and Replacement Parts List ----------- 16
    1.2. Cautions for use ------------------------------------------- 3
 2 Service Navigation ----------------------------------------------- 4
    2.1. Introduction-------------------------------------------------- 4
    2.2. Important Notice ------------------------------------------- 4
 3 Specifications ----------------------------------------------------- 5
    3.1. Specifications (Rated) ------------------------------------ 5
    3.2. Accessories ------------------------------------------------- 5
 4 Location of Controls and Components ------------------- 6
 5 Service Fixture & Tools----------------------------------------- 7
    5.1. Service Fixture and Tools-------------------------------- 7
    5.2. Clean Box --------------------------------------------------- 7
 6 Disassembly and Assembly Instructions ---------------- 8
    6.1. Outline-------------------------------------------------------- 8
    6.2. Disassembly Flow Chart --------------------------------- 8
    6.3. Disassembly procedure ---------------------------------- 9
    6.4. Assembly Flow Chart ------------------------------------ 11
    6.5. Assembly procedure -------------------------------------12
 7 Maintenance-------------------------------------------------------15
