Image preview - the first page of the document



>> Download h-x015_training_manual documenatation <<

Text preview - extract from the document

                                 H-X015
                     Component Repair
              Service Training Manual                                                            Ver.1.1
                                                                                 Internal use only




                    -S                                                -K
Specifications
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
"LUMIX DG SUMMILUX 15 mm/F1.7 ASPH."
 Focal length               f=15 mm
                                 (35 mm film camera equivalent: 30 mm)
Aperture type                    7 diaphragm blades/circular aperture diaphragm
Maximum aperture                 F1.7
Minimum aperture value           F16
Lens construction                9 elements in 7 groups (3 aspherical lenses)
Nano surface coating             Yes
In focus distance                0.9 m to  [from the focus distance reference line]
Maximum image magnification      0.1
