Image preview - the first page of the document



>> Download cq-c1300_1400 documenatation <<

Text preview - extract from the document

Table Of Contents
                                  Service Manual
  COVER
  1 ABOUT LEAD FREE SOLDER        TOP NEXT
(PbF)
  2 FEATURES                      ORDER NO. ACED040236C8
  3 REPLACEING THE FUSE
  4 MAINTENANCE
  5 NOTES
  6 DIMENSIONS
  7 LASER PRODUCTS
  8 WIRING CONNECTION
  8.1 CQ-C1400N
  8.2 CQ-C1300AN / C1300GN
  9 BLOCK DIAGRAM                 AUTOMOTIVE AFTERMARKET
  9.1 Main / Display Block
  9.2 CD Servo Block
  10 TERMINALS DESCRIPTION
  10.1 Main Block
  10.2 Display Block
  10.3 CD Servo Block                q   CQ-C1400N
  11 PACKAGE AND IC BLOCK                CQ-C1300AN
DIAGRAM                                  CQ-C1300GN
  11.1 Main Block
  11.2 Display Block              MP3 WMA CD Player/ Receiver with CD Changer Control
  11.3 CD Servo Block
  12 REPLACEMENT PARTS LIST
[CQ-C1400N]
  13 EXPLODED VIEW (Unit) [CQ-
C1400N]
  14 REPLACEMENT PARTS LIST
[CQ-C1300AN / C1300GN]
  15 EXPLODED VIEW (Unit) [CQ-
C1300AN / C1300GN]
  16 CD PLAYER PARTS LIST
  17 EXPLODED VIEW (CD Deck)
  18 WIRING DIAGRAM
  18.1 Display Block
  18.2 Main Block (Top View)                                                      Specifications*
  18.3 Main Block (Bottom View)                         General
  18.4 CD Servo Block (Top View)       Power Supply                DC 12V(11V-16V),
  18.5 CD Servo Block (Bottom View)                                Test Voltage 14.4V
                                                                   Negative Ground
  19 SCHEMATIC DIAGRAM-1
                                       Tone Controls (Bass)
