Image preview - the first page of the document



>> Download cq_c1321_c1311_c1301ne__192 documenatation <<

Text preview - extract from the document

  cq1321ne.html


Table Of Contents
                                                     Service Manual
  COVER
  1 ABOUT LEAD FREE                                  TOP NEXT
SOLDER (PbF)
  2 LASER PRODUCTS                                   ORDER NO. ACED041284C8
  3 FEATUERS
  4 REPLACING THE FUSE
  5 MAINTENANCE
  6 NOTES
  7 DIMENSIONS
  8 WIRING CONNECTION
  9 TERMINALS
DESCRIPTION
  9.1 Main Block                                     AUTOMOTIVE AFTERMARKET
  9.2 Display Block
  9.3 CD Servo Block
  10 PACKAGE AND IC
BLOCK DIAGRAM
  10.1 Main Block                                          q   CQ-C1321NE
  10.2 Display Block                                           CQ-C1311NE
  10.3 CD Servo Block                                          CQ-C1301NE
  11 REPLACEMENT PARTS
LIST                                                 WMA MP3 CD Player/Receiver
  12 EXPLODED VIEW
(Unit)
  13 CD PLAYER PARTS
LIST
  14 EXPLODED VIEW (CD
Deck)                                                                                                          Specifications*
  15 WIRING DIAGRAM
                                                                                     General
  15.1 Main Block (Top View)
  15.2 Main Block (Bottom                                                            Power Supply              DC 12V (11V - 16V),
                                                                                                               Test Voltage 14.4V
View)                                                                                                          Negative Ground
  15.3 Display Block                                                                 Current Consumption       Less than 2.2A (CD mode ; 0.5W 4-channels)
  15.4 CD Servo Block (Top
                                                                                     Maximum Power Output      50W
