Image preview - the first page of the document
naamloos


>> Download naamloos documenatation <<

Text preview - extract from the document
                                                   CQ-TS7421K
                                                   AM/FM/RDS    MPX     ELECTRONIC
                                                   TUNING RADIO with CD Player
                                                   TOYOTA PART No. 86120-0F010
                                                   ID CODE : W58810
                                                   VEHICLE : Corolla Verso
                                                   DESTINATION : Europe
                                                   PRODUCED AFTER : Feb. 2004




Specifications
General
Power Supply            DC 12V                     CD Changer(YGFD15273)
                        Test Voltage 14.4V         Signal to Noise Ratio              More than 65dB
                        Negative Ground            Total Harmonic Distortion          Less than 0.3%
Current Consumption     Less than 3.0A (at 0.5W)   Channel Separation                 More than 70dB


FM Stereo Radio                                    Dimensions**                       178
