Image preview - the first page of the document
Panasonic_CX-WT0260AA_CX-WT0262AA_Car_audio_sm


>> Download Panasonic_CX-WT0260AA_CX-WT0262AA_Car_audio_sm documenatation <<

Text preview - extract from the document
                                                                                                                              I0




                                                       CX-WT0260AA
                                                       CX-WT0262AA
                                                       DVD Player with Display for Rear Seat
                                                       PART No. (CX-WT0260AA) : 86680-45011
                                                                     (CX-WT0262AA) : 86680-45021
                                                       VEHICLE : SIENNA
                                                       DESTINATION : North America
                                                       PRODUCED AFTER : April., 2005
                                                       NOTE: CX-WT0260AA and CX-WT0262AA are
                                                                  remodels of CX-WT0260A and CX-WT0262A.
                                                                  The deck and display PCB have changed.
                                                                  CX-WT0260AA and CX-WT0262AA have
                                                                  different product numbers for the vehicle
                                                                  attachment brackets.



Specifications*
General                                                Display
Power Supply             DC 12V (11V - 16V),           Type                               TFT LCD
                         Test Voltage 13.2V            Size                               7-inch wide type
                         Negative Ground
Current Consumption      Less than 4A                  Dimensions when closed**           323
