MQM0094TR021112REV1


>> Download MQM0094TR021112REV1 documenatation <<

Text preview - extract from the document
 Confidential

For NSC's Only      For Authorised Service Agents Only                                Ref No: MQM0094TR021112REV1


        TECHNICAL INFORMATION
 A      BG          CY         E         FL            I      LT    MD           NL        S           TR           Date
 AL     BIH         CZ         EST       GB          IRL      LV    MK            P        SK          UA        02.11.2012
AND     BY          D          F         GR           IS      M     MNE          PL        SLO            Country Reported
 B      CH          DK         FIN       H             L      MC    N            RO        SRB                Europe
Product Category:               Refrigerator-Freezer

Subject:            When the temperature and humidity are high, defrost water will overflow from the
                    evaporating pan onto the floor
Model(s) Affected:             NR-B32SX1, NR-B32SW1, NR-B32SG1
Symptom /           The performance of evaporating the defrosted water is not adequate enough
Cause:              As the heat from the compressor does not directly conduct to the evaporating pan.


Remedy /            Parts Inofrmation
                    Part Number          Part Description
Method:
                    CNRAJ-050070         Rubber Butyl
 Service Countermeasure
      Remove any water from the evaporating pan before applying the Rubber Butyl
      Fixing screws are located in the 3rd hole.
      1. Remove the fixing screws.               Caution : Be careful Not to break the discharge pipe.




      2. While the evaporating pan is slightly moved upwards, place the Rubber Butyl on the top of compressor.




      3.Replace the evaporating pan and fix the screws to the 2nd hole from the top as shown in the picture.




Warranty Claims - Please use the following IRIS ans Activity codes.
         Activity Codes:      Guarantee Status       Repair Type     Location    Source
              (UK Only)              -                    -             -           -
                                         Symptom                   Section                Defect
                  Condition                                                                            Repair
IRIS Codes:                       Area     Type       Code     Area       Code     Area         Code
                                   B          5       B50      152       C15          1         C2       B
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
 Panasonic                                                     1 of 1
