TH-L32C22T
12.3. P-Board
P-Board (A Side)
TNP4G473
1 2 3 4 5 6 7 8 9 10
A
B
C
D
Parts Location
Ref. No Location Ref. No Location Ref. No Location Ref. No Location
IC800 C5 D800 D1 D809 B7 D817 C10
IC801 C8 D801 D8 D810 C5 D819 D10
IC803 D10 D803 D6 D811 B8 D820 D4
D805 D3 D812 C8 D821 A10
D806 C4 D813 B10 D825 D9
D807 C7 D814 D5 D826 B1
D808 D7 D815 D5 D827 B8
12.4. P-Board
P-Board (B Side)
TNP4G473
1 2 3 4 5 6 7 8 9 10
A
B
C
D
Parts Location
Ref. No Location Ref. No Location Ref. No Location Ref. No Location
IC800 C5 D800 D10 D808 D5 D817 C1
IC801 D3 D801 D3 D809 B5 D820 D8
D803 D5 D810 C6 D826 B10
D805 D8 D811 B3 D827 C3
D806 C8 D812 C3
D807 C5 D813 B1
51
TH-L32C22T
11.3. P Board
11.3.1. P Board (1 / 3)
<1A>
<2A>
<3A>
<4A>
42
TH-L32C22T
11.3.2. P Board (2 / 3)
<1A> <1B>
<2A>
<2B>
<3A>
<3B>
<4B>
<4A> <5B>
43
TH-L32C22T
11.3.3. P Board (3 / 3)
<1B>
TPC8116
<2B>
(3,2)
(3,1)
<3B>
(21v)
(11,9)
(6v)
<4B>
<5B>
44
