>> Download PCZ1103041CE documenatation <<Text preview - extract from the document ORDER No. PCZ1103041CE
Service Manual
LCD Television
TX-L32E3B
TX-L37E3B
GLP26 Chassis
Specifications
(Informations in brackets [ ] refers to model 32")
Power Source: 220-240V AC, 50Hz
Rated Power Consumption: 75W [56W]
Stand-by Power Consumption: 0.25W (Without monitor out recording)
10W (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: E3B (UK)
DVB-T/T2 Digital terrestrial services via UHF aerial input (MPEG2 and MPEG4-AVC(H.264))
PAL-I
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
E3B (Ireland)
DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
PAL-I
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: E3B (UK) E3B (Ireland)
UHF E21-E68 VHF A-J UHF E21-E69
CATV S1-S20 CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0
