Image preview - the first page of the document
>> Download panasonic_th-43d350dx_chassis_6m63a documenatation <<
Text preview - extract from the document
Part No. Description Q'ty 168P-L3L02A-HCW1S (HI) POWER ASS'Y 168P-L3L02A-W1 1 2043-T6M63AX-00 ELE.SCREEN ASS'Y SKY-RGB RDL430FY(LD0-10 1 6M63A-01H43E300-S36M63A-43E300HI)MAIN BOARD ASEMBLE 1 6M63A-18H43E300-046M63A-43E300(HI)RECEIVER BOARD ASSEMBL 1 6M63A-27HA00-06 NON COMMON ASS'Y 6M63A-43E300A SKD 1 AP00-QB3000-W4 ALL MECHANICAL PARTS 43E3000 OVERSEAS EP 1 CM00-QB300B-W4 CABINET COLOUR MATCH #HNB003 6M82T-43E30 1 OP00-QB3000-W7 OTHER PARTS 6M63A-43E300A 1 PP00-QB3000-W0 PACKAGING PARTS 6M63E-43E3000 1 SD00-QB300R-W0 SKD R.CAB PACKING 43E3000 1 SD00-UE390B-W0 SKD BASE PACKING 40E390/50E390CARTON BO 1 ST00-QB3000-W0 STAND PARTS 43E3000 E390 PLASTIC BASE 1 SD00-S43E3000-AIJI SKD BACK PACKING FOR AIJI 43E3000 1 168P-L3L02A-HAW1 (HI) POWER ASS'Y 168P-L3L02A-W1 1 168P-L3L02A-SCW1 (TI) POWER ASS'Y 168P-L3L02A-W1 1 SD00-32E66P-K0 CKD POWER PCB PACKING PARTS 1 5400-3A6451-51C0 HOUSING 51(0.5)+ HOUSING 40(2.0 W/BUCKLE 1 7626-T4300L-Y29034 43" SKY-RGB LCD HNB003 W/Panasonic RDL43 1 3909-03180C00-01 3M - FILAMENT TAPE 18MM*55M 100 6M63A-01A43E300-S36M63A-43E300AI)MAIN BOARD ASEMBLE 1 6M63A-01HA00-03 (HI) MAIN ASS'Y 6M63A-43E300A SKD 1 6M63A-01HB0X-04 (HI) MAIN MATCH SCREEN ASS'Y 6M63A-43E30 1 SD00-CE360M-W0 SKD MAIN PCB PACKING 6M62N-32E360 230*40 1 6M63A-18HA00-04 (HI) RECEIVER BOARD ASS'Y 6M63A-43E300A 1 6M63A-18S43E300-04 6M63A-43E300(TI)RECEIVER BOARD ASSEMBL 1 53ED-37LR60-1000 ZINC-MANGANESE DRY BATTERY LR6-AA 1.5V 2 53HD-260401-W000 HANDSET ASS'Y HS-0401P-00 "PANASONIC" FO 1 5400-221201-0220 HOUSING 02(2.0)+ TERMINAL*2+ 200MM (1=BL 1 5400-221501-0250 HOUSING 02(2.5 W/BUCKLE)+ TERMINAL*2+ 50 1 5400-320501-1480 HOUSING 14(2.5)+ HOUSING 14(2.5)+ 500MM 1 5631-106124-0290 SPEAKER 6 OHM 10W MAX 12W 236*35*45.5MM 2 5900-E15100-0060 AUDIO/VIDEO SIGNAL CABLE 150MM 3.5MM PLU 1 5942-A15208-1020 AC LINE CORD 1500MM 0.75*2 BIS PLUG + IN 1 0301-QB300010-21 EPS(TOP-BOT) FOR 43E3000 SET 1 0301-QB300S00-21 EPS SIDE FOR 43E3000 1 0404-11284105-11 POLY BAG 1160*840*0.05MM WITH PRINTING 1 0404-23133105-31 POLY BAG 230*330*0.05MM WITH PRINTING 1 1305-29F100-02 0APE 560 X 10 X 0.3 MM 1 1320-L2001010-01 ADHESIVED TAPE CUSHION 200*10*1MM 1 26AM-0300602N-B0 SCREW AM3*6 NYLOK BLACK 16 26PM-03008001-NS PM 3 X 8 WITH PLAN WASHER AND SPRING WAS 8 1002-QB300000-21 B.CAB HIPS(94-V0) DG001 QB300000-PA 43E3 1 1007-CE300000-21 F.LENS PC TEA COLOR CE300000-PA 32E3000 1 1023-CE300000-21 CTRL.KEY BKT ABS HNB003 CE300000-PA 32E3 1 1005-QE390B20-21 BTM AV BKT HIPS(94-V0) DG001 QE390B20-PA 1 1005-QE390S20-21 SIDE AV BKT HIPS(94-V0) DG001 QE390S20-P 1 1020-42E59000-21 SUPPORTER PA66 94V0 H10 42E59000-PA 1 1024-QE390100-21 DECO-LOGO ABS+PMMA QE390100-PA SEMICIRCL 1 26B3-03010020-B0 SCREW B3 3*10 BLACK 2 1320R821800-01 ADHESIVED TAPE (TRANSPARENT) (50M/RL) 3 1523R821800-04 STAPLE (GOLD) (ROHS) 6 0100-QE390000-38 CARTON BOX 43E3000 "Panasonic" 1 0601-QB300002-P9 BACK COVER LABEL "Panasonic" TH-43D350DX 1 0773-QB300000-P9 I/B "Panasonic" TH-43D350DX ENG 1 1205-UE390000-17 INLAY-BTM AV #DG001 6M63A W/O MHL FOOLPR 1 1213-UE390000-18 INLAY-SIDE AV #DG001 6M63E FOOLPROOF "Pa 1 0100R00B00181-00 SKD CARTON BOX 42E66 B.CAB 1004*413*606 0.125 0415R000022-00 BUBBLE BAG L1200 X W850 MM 1 3900R000492-00 PACKING PAPER 1200 X 1050MM (29") 0.875 3900R02000028-00 CARTON SHEET.L(620+100)*W100*6MM 0.25 0100-00BB0014-00 SKD CARTON BOX 634*511*367 FOR 40E390 BA 0.056 0102-00B00067-00 CARTON SHEET 606*486*6M 0.168 0102-00B00068-00 CARTON SHEET 616*160*6M 1.112 0102-00B00069-00 CARTON SHEET 496*160*6M 0.334 0404-20138105-11 POLY BAG 200*380*0.05MM WITH PRINTING 2 0404-60080005-31 POLY BAG 60*80*0.05MM WITH PRINTING 1 1020-UE390000-21 BASE ABS+10%GF NB001 UE390000-PA 40E390 2 26PM-04020021-BN SCREW PM4*20 BLACK WITH PLAN WASHER AND 4 1604-12510113-01 WOODEN PALEET 1250*1015*130MM 0.014 0101R3266D003-00 CARTON CONTER 50X50X2200MM THICKNESS=3.5 0.056 0101R3266D000-00 CARTON CONTER50X50X900MM,THICKNESS=3.5MM 0.056 3904RD00000-01 STRETCH FLLM(200M X 45CM/JUA) 0.006 3910-00120000-01 PACKING TAPE PP L2500M*W12MM*T0.6MM YELL 0.5 1505-M0640200-04 HEAT SINK #M76D L64.6*W20*H5.4 1 1505-M0640250-04 HEAT SINK #M76C L64.6*W25*H5.4 1 26BM-030060-N0 BM 3 X 6 0 26PM-030060-N0 PM 3 X 6 3 4134-NJ50A0-AZ00 NTC THERMISTOR RES. 5 OHM +/-20% 5A (P=7 1 4176-L68146-7Q10 VARISTOR INCOMBUSTIBILITY 680V +/-10% I( 1 4300-BD1083-AL00 ELEC. CAP. 1000UF 25V +/-20% 105*C HFLZ 4 4300-BE1083-AL00 ELECTROLYTIC CAPACITOR 1000UF 35V +/-20% 1 4300-BH8263-AL00 ELEC. CAP. 82UF 100V +/-20% 105*C HFLZ 1 2 432C-EP3920-5ZB0 M.P-P.F.CAP. 3900PF 630V +/-5% (P=7.5MM, 1 4338-S54710-7Z20 SAFETY CERAMIC CAP. 470PF AC400V +/-10%( 3 433X-F32240-7ZE0 AC CAPACITOR 220NF AC275V
