Image preview - the first page of the document
>> Download Panasonic_TH-50AS610K_Chassis_KM26 documenatation <<
Text preview - extract from the document
ORDER NO. MTV1401232CE
LED TV
Model No. TH-50AS610K
Chassis: KM26
Destination: MALAYSIA
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 5.1.7. Hotel Mode-------------------------------------------- 11
1.1. General Guidelines---------------------------------------- 3 6 Troubleshooting Guide --------------------------------------- 12
1.1.1. Leakage Current Cold Check---------------------- 3 6.1. Check of the IIC bus lines------------------------------ 12
1.1.2. Leakage Current Hot Check (See Figure 6.1.1. How to access --------------------------------------- 12
1.) --------------------------------------------------------- 3 6.1.2. Self-check indication only ------------------------- 12
2 Warning -------------------------------------------------------------- 4 6.1.3. Self-check indication and forced to factory
2.1. Prevention of Electrostatic Discharge (ESD) shipment setting ------------------------------------- 12
to Electrostatically Sensitive (ES) Devices---------- 4 6.1.4. Exit ------------------------------------------------------ 12
2.2. About lead free solder (PbF)---------------------------- 5 6.1.5. Screen display --------------------------------------- 12
3 Service Navigation ----------------------------------------------- 6 6.2. Power LED Blinking timing chart --------------------- 13
3.1. Service Hint ------------------------------------------------- 6 6.3. Method of detecting SOS ------------------------------ 13
4 Specifications ----------------------------------------------------- 7 6.4. LCD Panel test mode ----------------------------------- 14
5 Service Mode ------------------------------------------------------ 9 6.5. No Power--------------------------------------------------- 14
5.1. How to enter into Service Mode ----------------------- 9 7 Disassembly and Assembly Instructions--------------- 15
5.1.1. Purpose ------------------------------------------------- 9 7.1. Installation SP Bracket --------------------------------- 15
5.1.2. Key command ----------------------------------------- 9 7.2. LCD Panel Fixing & Handling Method -------------- 16
5.1.3. How to exit---------------------------------------------- 9 7.3. LED Panel Assy ----------------------------------------- 17
5.1.4. Contents of adjustment mode --------------------- 9 7.4. Installing Key Button Bracket ------------------------- 18
5.1.5. Display of SOS History -----------------------------10 7.5. Installation Barrier & WIFI 1 --------------------------- 19
5.1.6. Exit-------------------------------------------------------10 7.6. Installation Barrier & WIFI 2 --------------------------- 20
