Image preview - the first page of the document
>> Download Panasoni+TH-50C400+Z+Chassis+KM25 documenatation <<
Text preview - extract from the document
ORDER NO. MTV1503373CE
LED TV
Model No. TH-50C400Z
Chassis: KM25
Destination: NEW ZEALAND
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 5.1.7. Hotel Mode----------------------------------------------9
1.1. General Guidelines---------------------------------------- 3 6 Troubleshooting Guide --------------------------------------- 10
1.1.1. Leakage Current Cold Check---------------------- 3 6.1. Check of the IIC bus lines------------------------------ 10
1.1.2. Leakage Current Hot Check (See Figure 6.1.1. How to access --------------------------------------- 10
1.) --------------------------------------------------------- 3 6.1.2. Self-check indication only ------------------------- 10
2 Warning -------------------------------------------------------------- 4 6.1.3. Self-check indication and forced to factory
2.1. Prevention of Electrostatic Discharge (ESD) shipment setting ------------------------------------- 10
to Electrostatically Sensitive (ES) Devices---------- 4 6.1.4. Exit ------------------------------------------------------ 10
2.2. About lead free solder (PbF)---------------------------- 5 6.1.5. Screen display --------------------------------------- 10
3 Service Navigation ----------------------------------------------- 6 6.2. Power LED Blinking timing chart --------------------- 11
3.1. Service Hint ------------------------------------------------- 6 6.3. Method of detecting SOS ------------------------------ 11
4 Specifications ----------------------------------------------------- 7 6.4. LCD Panel test mode ----------------------------------- 12
5 Service Mode ------------------------------------------------------ 8 6.5. No Power--------------------------------------------------- 12
5.1. How to enter into Service Mode ----------------------- 8 7 Disassembly and Assembly Instructions--------------- 13
5.1.1. Purpose ------------------------------------------------- 8 7.1. Speaker Fixing and Assembly ----------------------- 13
5.1.2. Key command ----------------------------------------- 8 7.2. LCD Panel Fixing & Handling Method -------------- 14
5.1.3. How to exit---------------------------------------------- 8 7.3. Metal MTG Fixing --------------------------------------- 15
5.1.4. Contents of adjustment mode --------------------- 8 7.4. Key Button Assembly ----------------------------------- 16
5.1.5. Display of SOS History ------------------------------ 9 7.5. Bracket Fitting--------------------------------------------- 17
5.1.6. Exit-------------------------------------------------------- 9 7.6. Fan Bag Assembly--------------------------------------- 18
