Image preview - the first page of the document
![Panasonic_TH-55FX700G_Chassis_KM39_[X]](/pics/5e81fe494f004.gif)
>> Download Panasonic_TH-55FX700G_Chassis_KM39_[X] documenatation <<
Text preview - extract from the document
ORDER NO. MTV1801210CE
LED TV
Model No. TH-55FX700G
Chassis: KM39
Destination: INDONESIA
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 5.6. Hotel mode ------------------------------------------------ 11
1.1. General Guidelines---------------------------------------- 3 5.6.1. Purpose ------------------------------------------------ 11
1.1.1. Leakage Current Cold Check---------------------- 3 5.6.2. Access command to the Hotel mode setup
1.1.2. Leakage Current Hot Check (See Figure 1.) ---- 3 menu --------------------------------------------------- 11
2 Warning -------------------------------------------------------------- 4 5.6.3. To exit the Hotel mode setup menu------------- 11
2.1. Prevention of Electrostatic Discharge (ESD) 5.6.4. Explain the Hotel mode setup menu ----------- 11
to Electrostatically Sensitive (ES) Devices---------- 4 5.7. Data Copy by USB Memory --------------------------- 12
2.2. About lead free solder (PbF)---------------------------- 4 5.7.1. Purpose ------------------------------------------------ 12
3 Service Navigation ----------------------------------------------- 5 5.7.2. Preparation-------------------------------------------- 12
3.1. Service Hint ------------------------------------------------- 5 5.7.3. Data copy from TV set to USB Memory ------- 13
4 Specifications ----------------------------------------------------- 6 5.7.4. Data copy from USB Memory to TV set ------- 14
5 CS Maintenance Menu ------------------------------------------ 8 6 Troubleshooting Guide --------------------------------------- 15
5.1. How to enter into CS Maintenance Menu ----------- 8 6.1. Check of the IIC bus lines------------------------------ 15
5.1.1. Purpose ------------------------------------------------- 8 6.1.1. How to access --------------------------------------- 15
5.1.2. Key command ----------------------------------------- 8 6.1.2. Screen display --------------------------------------- 15
5.1.3. How to exit---------------------------------------------- 8 6.2. Power LED Blinking timing chart --------------------- 15
5.2. Repack ------------------------------------------------------- 8 6.3. Method of detecting SOS ------------------------------ 16
5.3. EDID Clock-------------------------------------------------- 9 6.4. LCD Panel test mode ----------------------------------- 16
5.4. USB HDD Drive Check----------------------------------- 9 6.5. No Power--------------------------------------------------- 17
5.5. White Balance Adjustment -----------------------------10 7 Disassembly and Assembly Instructions--------------- 18
