Image preview - the first page of the document
MQM0083DG260412REV1


>> Download MQM0083DG260412REV1 documenatation <<

Text preview - extract from the document
Confidential

                     For Authorised Service Agents Only                                 Ref No: MQM0086DG250412REV1


       TECHNICAL INFORMATION
 A     BG            CY         E         FL            I      LT        MD        NL        S              TR              Date
 AL    BIH           CZ         EST       GB          IRL      LV        MK         P        SK             UA           25/04/2012
AND    BY            D          F         GR           IS      M         MNE       PL        SLO                  Country Reported
 B     CH            DK         FIN        H            L      MC        N         RO        SRB                     Germany
Product Category:               LCD IDTV

Subject:                        Backlight/panel failure


Model(s) Affected:              TX-L42E5B                   TX-L42EW5
                                TX-L42E5E                   TX-L42EW5S
                                TX-L42E5Y

Symptom /                 Under certain viewing conditions, the panel/backlight fails but audio is still output.
                          There will be no backlight, no picture, and there may be a whistle from the LD PCB
Cause:

Remedy / This modification applies to all units prior to: N*-2240001
Method:     Step 1: Replace the LD PCB (Part No: LD-42E5)
                   Step 2: Upgrade the PEAKS EEPROM

      Step 1: Replace the LD PCB

      1. Release the 3 connectors on the
         LD PCB, and remove the cables.
      2. Remove the 4 screws holding the
          LD PCB.
      3. Fit the replacement LD PCB.

      4. Replace the screws.
      5. Re-connect the cables.




                                                                                   Fig. 1: Rear of set

               Fig. 2: LD PCB

  Step 2: Upgrade the PEAKS EEPROM

  Obtain the PEAKS EEPROM upgrade files from your usual service source.
  1. Uncompress the file.
  2. Copy the folders, folder contents and files shown in Fig. 3 to the root directory of an SD card.
  3. Turn on the TV and wait for the default screen to appear.
  4. Insert the SD card into the SD card slot.
  5. Follow the on-screen instructions to upgrade the PEAKS EEPROM software.
                                                                                                                          Fig. 3


Warranty Claims - Please use the following IRIS and Activity codes
      Activity Codes:          Guarantee Status       Repair Type       Location   Source
            (UK Only)                 A                    R               W         D
                                          Symptom                    Section                Defect
                   Condition                                                                                Repair
IRIS Codes:                        Area     Type       Code      Area       Code     Area            Code
                      1             3          1       315          3       VPD         2             N       i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected

                                                                                                                       Document No: MQM_TI
Panasonic                                                        1 of 1                                                 Rev: 11.00 DG020410
