Image preview - the first page of the document



>> Download PANASONIC M-WAVE H97 FAULT FLOW CHART documenatation <<

Text preview - extract from the document

                                                                                                 NN-ST657S / NN-ST677M / NN-ST667W / NN-ST657W




4.3.      Troubleshooting of inverter circuit (U) and magnetron NEW H.V.
This oven is programmed with a self diagnostics failure code system which will help for troubleshooting. H95, H97, H98 and H99
are the provided failure codes to indicate magnetron and inverter circuit problem areas. This section explains failure codes of H95,
H97, H98 and H99. First, you must program the DPC into TEST MODE, press Timer/Clock pad twice  Press Start pad once
 press Micro Power pad once. Program unit for operation. H95, H97, H98, H99 appears in display window a short time after
start key is pressed and there is no microwave oscillation.




Alternate way to troubleshoot oven with AC Ampere meter used


H95, H97, H98, H99 appears in display window a short time after start key is pressed and no microwave oscillation with AC Ampere
meter used for troubleshooting.




                                                                11
