Image preview - the first page of the document
Panasonic_TH-42PX600_TH-50PX600_vibrating_sound_from_speakers_repair_tips


>> Download Panasonic_TH-42PX600_TH-50PX600_vibrating_sound_from_speakers_repair_tips documenatation <<

Text preview - extract from the document
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga ON
L4W 2T3
                                       Technical Bulletin
Products:                            Models                                  Number:
                                     :        TH-42PX600
            Plasma                                                                        TB-06-08
                                              TH-50PX600
Code:                                                                        Date:
            B62                                                                           Dec 12,06
                                     Year:    2006




  Symptom:        Vibration noise from left or right speaker.

  Cause:          Speaker box is making direct contact with cabinet parts.

  Remedy:         Installing mounting screw in the center of speaker box prevents from
                  touching the cabinet parts and minimizes the risk of vibration noise.

  Procedure:      Install screw, part number THEL049 to both speaker boxes as in attached
                  picture.




                                                      Add screw THEL049.

                                                      Please repeat the same for left speaker box.




  Published by Customer and Product Assurance                                                1
