Panasonic_TH-42PX60_picture_goes_after_a_few_minutes_sound_OK_repair_tips


>> Download Panasonic_TH-42PX60_picture_goes_after_a_few_minutes_sound_OK_repair_tips documenatation <<

Text preview - extract from the document
 Panasonic Canada Inc.
 5770 Ambler Drive
 Mississauga ON
 L4W 2T3
                                                                            Tech Tips
 Product:                             Models:                                    Number:
            PLASMA TV                                                                      TT-08-14
                                                    TH42PX60
 Code:                                                                           Date:
            B62                                                                            February 26, 2008
                                      Model Year:     2006

PCB Designation: D Board

Part #:      TNPA3810AHS

Symptom:      Picture disappears after few minutes but sound is OK.


Cause:        Low Ldo_5V supply to IC9800 (DC to DC Converter) due to leaky D9801.

Remedy:       Replace D9801 on the D board.




                                                                                 Parts list
                                                                      D9801:
                                                                      Part # - B0JCDD000002


                             D9801




                  Published by Customer & Product Assurance           TT-08-14.doc                    Page 1
