Image preview - the first page of the document
Panasonic_TH-103PF10UK_TH-103PF10EK_[SM]


>> Download Panasonic_TH-103PF10UK_TH-103PF10EK_[SM] documenatation <<

Text preview - extract from the document
                                                                                                                    Order Number ITD0709071CE
                                                                                                                                 B34 Canada: D10




                                                                               High Definition Plasma Display
                                                                              Model No. TH-103PF10UK
                                                                              Model No. TH-103PF10EK
                                                                              GPF10D Chassis




TABLE OF CONTENTS
                                                                    PAGE                                                                     PAGE
 1 Safety Precautions----------------------------------------------- 3           7.5.   Removal of HDMI-Board (UK) ------------------------ 28
     1.1. General Guidelines---------------------------------------- 3           7.6.   Removal of HDD-Board (EK) ------------------------- 28
 2 Warning -------------------------------------------------------------- 4      7.7.   Removal of DS-Board ---------------------------------- 28
     2.1. Prevention of Electrostatic Discharge (ESD)                            7.8.   Removal of HX-Board----------------------------------- 29
          to Electrostatically Sensitive (ES) Devices---------- 4                7.9.   Removal of DN-Board ---------------------------------- 29
     2.2. About lead free solder (PbF)---------------------------- 5            7.10.   Removal of PB-Board----------------------------------- 29
 3 Service Navigation ----------------------------------------------- 6         7.11.   Removal of H5-Board ----------------------------------- 30
     3.1. Service Hint ------------------------------------------------- 6      7.12.   Removal of D-Board ------------------------------------ 30
     3.2. Applicable signals ----------------------------------------- 8        7.13.   Removal of P-Board (MULTI_1), (MULTI_2) ------ 30
 4 Specifications ----------------------------------------------------10        7.14.   Removal of P-Board (SUS_1), (SUS_2) ----------- 31
 5 Service Mode -----------------------------------------------------11         7.15.   Removal of F-Board ------------------------------------ 31
     5.1. CAT (Computer Aided Test) mode ------------------- 11                 7.16.   Removal of PC-Board ---------------------------------- 32
     5.2. IIC mode structure (following items value is                          7.17.   Removal of SU-Board ---------------------------------- 32
          sample data) -----------------------------------------------15        7.18.   Removal of SM-Board ---------------------------------- 33
     5.3. Option Setting ---------------------------------------------16        7.19.   Removal of SD-Board ---------------------------------- 34
 6 Troubleshooting Guide ----------------------------------------18             7.20.   Removal of SC-Board --------------------------------- 34
     6.1. Self Check--------------------------------------------------18        7.21.   Removal of SC2-Board -------------------------------- 35
     6.2. No Power ---------------------------------------------------20        7.22.   Removal of S1-Board and V2-Board---------------- 35
     6.3. No Picture --------------------------------------------------20       7.23.   Removal of SS2-Board -------------------------------- 36
     6.4. Local screen failure --------------------------------------21         7.24.   Removal of SS3-Board -------------------------------- 36
 7 Disassembly and Assembly Instructions ---------------22                      7.25.   Removal of SS-Board ---------------------------------- 37
     7.1. Rear Cover and Board ----------------------------------22             7.26.   Removal of Fan------------------------------------------- 38
     7.2. Location of Rear Cover screws -----------------------23               7.27.   Removal of C1-Board ----------------------------------- 39
     7.3. Removal of Side Angle (L), (R) -----------------------26              7.28.   Removal of C2-Board ----------------------------------- 39
     7.4. Removal of HA-Board -----------------------------------27             7.29.   Removal of C3-Board ----------------------------------- 40
