Image preview - the first page of the document
Panasonic_TH-37PW7BX_TH-42PWD7UY_TH-42PWD7BS_TH-37PWD7EK_TH-42PW7EX_TH-42PWD7EK_TH-42PWD7ES_TH-37PWD7UY_TH-37PWD7BK_TH-42PWD7BK_TH-37PW7EX_TH-42PW7BX_[SM]


>> Download Panasonic_TH-37PW7BX_TH-42PWD7UY_TH-42PWD7BS_TH-37PWD7EK_TH-42PW7EX_TH-42PWD7EK_TH-42PWD7ES_TH-37PWD7UY_TH-37PWD7BK_TH-42PWD7BK_TH-37PW7EX_TH-42PW7BX_[SM] documenatation <<

Text preview - extract from the document
                                                                                                          ORDER NO. ITD0408033C0
                                                                                                                 D10 Canada: B07




                                                                   Progressive Wide Plasma Display
                                                                     TH-37PW7BX
                                                                     TH-37PW7EX
                                                                     TH-37PWD7BK
                                                                     TH-37PWD7EK
                                                                     TH-37PWD7UY
                                                                     TH-42PW7EX
                                                                     TH-42PW7BX
                                                                     TH-42PWD7BK
                                                                     TH-42PWD7BS
                                                                     TH-42PWD7EK
                                                                     TH-42PWD7ES
                                                                     TH-42PWD7UY
                                                                     GP7D Chassis

Specifications
Power Source (UY Version)        120 V AC, 50/60 Hz
Power Source (Except UY)         220 - 240 V AC, 50/60 Hz
Power Consumption (UY Version)
   Maximum                       225 W (37 inch)                                  290 W (42 inch)
   Stand-by condition            Save OFF 0.8 W, Save ON 0.5 W
   Power off condition           0.1 W
Power Consumption (Except UY)
   Normal use                    185 W (37 inch)                                  250 W (42 inch)
   Stand-by condition            Save off 1.0 W, Save on 0.7 W
   Power off condition           0.3 W
Plasma Display panel             Drive method: AC type 16:9 aspect ratio
   Contrast Ratio                4000:1
Screen size                      818 mm (W)
