Image preview - the first page of the document
Panasonic_TH-37PW5_TH-37PWD5_TH-42PW5_TH-42PWD5_TH-42PHD5_TH-42PHW5_TH-50PHD5_TH-50PHW5_distorted_video_repair_tips


>> Download Panasonic_TH-37PW5_TH-37PWD5_TH-42PW5_TH-42PWD5_TH-42PHD5_TH-42PHW5_TH-50PHD5_TH-50PHW5_distorted_video_repair_tips documenatation <<

Text preview - extract from the document
Subject      Color Faulty
Category     Plasma TV
Applicable   TH-37PW5 series, TH-37PWD5 series, TH-42PW5 series, TH-42PWD5 series
Models       TH-42PHD5 series, TH-42PHW5 series, TH-50PHD5 series, TH-50PHW5 series
Symptom
             Panel may show the colour faulty in the part of TV screen.


                                                       EX: Green Color Stop



Cause        Faulty IC(Video Amp ) in lot defect (Problem in IC production process)
             Ref No.: IC9002(G-Ch), IC9003(B-Ch), IC9004(R-Ch) Part No.:C0ABHA000033
Remedy
             Replace IC9002, IC9003, IC9004 by new one. (Those ICs are located on D Board)




Remark       Affected Production Serial.:
              Production from 2003/March(Y*321***) to 2003/June(Y*334***)
