Image preview - the first page of the document



>> Download GPF9D GPF10D TH-103PF9UK TH-103PF10UK Troubleshooting Handbook documenatation <<

Text preview - extract from the document

         Technical Guide
                   103" Plasma
             (GPF9D and GPF10D Chassis)
              Troubleshooting Handbook



Model : TH-103PF9UK
        TH-103PF10UK




          Panasonic Services Company
                   National Training
This page is purposely left blank.




                2
                                        Table of Contents
Subject                                        Page         Subject                                           Page
Introduction                                   4            Power LED blinks 8 times                          42
AC Power Requirement                           5            Power LED blinks 9 times                          43
Rear Cover Removal                             6            Power LED blinks 10 times                         44
Chassis Structure                              7            Power LED blinks 11 times                         45
Chassis Layout                                 8            Power LED blinks 13 times                         46
Board Description                              9            Alignment (Adjustment) Procedure                  47-53
Troubleshooting Display (Distortion) Problem   10-18        Self-check Procedure                              54
Relation of Board and Display Area             11           How to reset the unit                             55
Troubleshooting for No Power                   19-21        How to enter the CAT (Computer Aided Test) Mode   56
Shutdown (SOS) Troubleshooting                 22-46        How to enter the IIC mode                         57
List of LED Blink Codes                        23           How to access the pattern generator               58
Power LED blinks 1 time                        24           How to enter the CD Mode                          59
Power LED blinks 2 times (SS Side)             25           How to enter the MS Mode                          60
Power LED blinks 2 times (SC Side)             26
Power LED blinks 3 times                       27
Power LED blinks 4 times                       28
Power LED blinks 5 times                       29-34
Power LED blinks 6 times                       35-36
Power LED blinks 7 times                       37
