Text preview - extract from the document
Confidential
For Authorised Service Agents Only Ref No: MQM0063DG090811REV2
TECHNICAL INFORMATION
A BY D EST H IS N PL SK UA Date 15/06/2011
AL CH DK F I L NL RO SLO FIN Country Reported
B CZ E GB IRL LT P S TR Switzerland/Japan
Product Category: Plasma TV / Plasma IDTV
Subject: Pink Noise or Cyan Noise problem
Model(s) Affected: Please see list below
Symptom / When the set is warm, either pink noise or cyan noise can be seen, especially in bright
or white areas. (See below for examples of the problem)
Cause:
Remedy / Step 1: Upgrade the PDROM software
Method: Step 2: Upgrade the FPGA software
Step 3: Adjust various voltages inside the set
Models Affected:
Pink Noise problem Cyan Noise problem
TH-42PY700F TH-42PY70P TH-42PZ70E TH-42PY70EYA TH-42PY700PA TH-42PZ700EA
TH-42PY700P TH-42PZ700B TH-R42PY70 TH-42PY70FA TH-42PZ70BA
TH-42PY70EY TH-42PZ700E TH-R42PY700 TH-42PY70PA TH-42PZ70EA
TH-42PY70F TH-42PZ70B TH-42PY700FA TH-42PZ700BA
Examples of the Problem:
Pink Noise Pink Noise Pink Noise Cyan Noise
Preparation:
1. Obtain 2 SD Cards, one for use in step 1, one for use in step 2.
The card capacity must be between 128MB and 2GB and they should be standard speed.
2. Obtain a copy of the two different firmware versions - "pdrom_42fh10_v480Ft3_sddl.lzh" (for Step 1),
and "42FM10_v47.8Ft1_sddl.lzh" (for Step 1b) - from your usual service source.
3. Copy the zip file "pdrom_42fh10_v480Ft3_sddl.lzh" to a computer and unzip the file.
4. Copy the file and folders found in the extracted file and copy them onto the root directory of
SD Card 1 (for Step 1). See Fig. 1
5. Copy the zip file "42FM10_v47.8Ft1_sddl.lzh" to a computer and unzip the file.
6. Copy the file and folders found in the extracted file and copy them onto the root directory of
SD Card 2 (for Step 2). See Fig. 2 Fig. 1 Fig. 2
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Status Repair Type Location Source
(UK Only) A N W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
3 3 4 342 3 VPD 1 A1 i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 1 of 4 Rev: 10.00 DG220710
Confidential
For Authorised Service Agents Only Ref No: MQM0063DG090811REV2
TECHNICAL INFORMATION
Step 1: PDROM Software Upgrade
1. Turn on the Plasma TV
2. Insert SD card 1, with the files prepared in preparation step 4 above, into the SD Card slot.
3. Using the Cursor buttons on the remote control, select YES, then press the OK button to start the software
upgrade - The TV LED will change from green to red.
- Wait until the red LED turns off (about 6 minutes)
- Do NOT turn off the TV until the red LED turns orange or the TV will be broken
4. When the red LED turns orange, this part of the software ugprade is complete.
5. Using the power switch, turn the Plasma TV off.
6. Remove SD Card 1 from the SD Card slot.
Step 2: FPGA Software Upgrade
1. Turn on the Plasma TV
2. Insert SD card 2, with the files prepared in preparation step 6 above, into the SD Card slot.
3. Using the Cursor buttons on the remote control, select YES, then press the OK button to start the software
upgrade - The TV LED will change from green to red.
- Wait until the red LED turns off (about 2 minutes)
- Do NOT turn off the TV until the red LED turns orange or the TV will be broken
4. When the red LED turns orange, this part of the software ugprade is complete.
5. Using the power switch, turn the Plasma TV off.
6. Remove SD Card 2 from the SD Card slot.
Step 3: Voltage Adjustments
Using a digital volt meter, make the following voltage adjustments:
Adjustment Voltage Meter Probe
Item Voltage Ref PCB Component Before After + (Plus) - (Minus)
1 Vad SC VR6600 -140V -145V Chassis Earth TPVAD
2 Vscn SC VR6841 148V 153V TPVSCN TPVAD
3 Vdata P VR401 75V 80V TPVDA Chassis Earth
4 Ve SS VR6000 157V 162V * TPVe Chassis Earth
* Set to as much as possible if 162V cannot be reached
SC PCB P PCB SS PCB
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Status Repair Type Location Source
(UK Only) A N W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
3 3 4 342 3 VPD 1 A1 i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 2 of 4 Rev: 10.00 DG220710
Confidential
For Authorised Service Agents Only Ref No: MQM0063DG090811REV2
TECHNICAL INFORMATION
1. Vad voltage: VR6600 (SC PCB)
to -145V
SC board
+Plus:
Chassis Earth
VR6600
TPVAD
-Minus: Lead of
resistance
2. Vscn voltage: VR6841 (SC PCB)
to 153V
SC board
TPVSCN
+Plus: Lead of
resistance
VR6841
TPVAD
-Minus: Lead of
resistance
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Status Repair Type Location Source
(UK Only) A N W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
3 3 4 342 3 VPD 1 A1 i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 3 of 4 Rev: 10.00 DG220710
Confidential
For Authorised Service Agents Only Ref No: MQM0063DG090811REV2
TECHNICAL INFORMATION
3. Vdata voltage: VR401 (P PCB)
to 80V
P board -Minus:
SS board
Chassis earth
TPVDA
+Plus:Lead of
resistance
4. Ve voltage: VR6000 (SC PCB)
to 162V
VR6000
TPVe
+Plus: Lead of
resistance
-Minus:
Chassis earth
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Status Repair Type Location Source
(UK Only) A N W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
3 3 4 342 3 VPD 1 A1 i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 4 of 4 Rev: 10.00 DG220710
