Image preview - the first page of the document
>> Download itd0806064be documenatation <<
Text preview - extract from the document
Order No. ITD0806064BE
Plasma Television
TH-50/42PZ800E,
TH-50/42PZ800B
TH-46/42PZ85E,
TH-46/42PZ85B
TH-50/46/42PZ80E,
TH-50/46/42PZ80B
TH-50PZ800E TH-46/42PZ8E,
TH-46/42PZ8B
Troubleshooting Guide - Ver 1.0-
This service hint is published for technicians and engineers for repair.
And it gives you the information how to judge the defective board of PDP.
In the future,we will improve the contents for more easy diagnostic and
trouble shooting.
2008
Contents
1. 2008 PDP Line up & Feature Comparison ---------------------------------------------- P3
2. PCB Location & Function -------------------------------------------------------------------- P5
3. PCB List -------------------------------------------------------------------------------------------- P10
4. Block Diagram ----------------------------------------------------------------------------------- P12
5. Troubleshooting --------------------------------------------------------------------------------- P17
6. Appendix ------------------------------------------------------------------------------------------- P22
1. 2008 PDP Line up & Feature Comparison
3
1. 2008 PDP Line up & Feature Comparison
PZ800 Series PZ85 Series PZ80 Series PZ8 Series
Size 50/42 46/42 50/46/42 46/42
Panel 1080P HD 1080P HD 1080P HD 1080P HD
Gradation 5,120 5,120 5,120 4,096
Contrast Ratio 30,000:1 30,000:1 30,000:1 20,000:1
Intelligent Frame Creation Y Y --- ---
x.v. Colour Y Y Y ---
Picuture
24p Real Cinema Y Y --- ---
24p Playback Y Y Y Y
Digital Cinema Colour Y --- --- ---
Advanced 3D Colour Management Y Y Y Y
Motion Pattern Noise Reduction Y Y Y Y
Sub Pixel Control Y Y Y Y
Super Slim Speaker, Full-range Speaker Full-range Speaker Full-range Speaker
Speaker Woofer Speaker (Bottom) (Bottom) (Bottom)
Sound
BBE VIVA --- Y --- ---
HDMI 4 3 3 2
VIERA Link (HDAVI Control 3) Y Y Y Y
Networking Y
SDHC Card Slot Y(JPEG) Y(JPEG) ---
(AVCHD/MPEG2/JPEG)
PC Input Y Y Y ---
4
2. PCB Location & Function
5
2. PCB Location & Function (1) PZ800 Series
TH-50PZ800 TH-42PZ800
SU P(AC) SU
PA P(MAIN) PA P
SC SS SC SS
A A
SD D SD D
SS2
C1 HC C2 C3 C1 HC C2
GL GS GH G K S GL GS GH G K S
Board Name Function Part Number Board Name Function Part Number
Power Supply MAIN ETX2MM704MGH Power Supply ETX2MM702MFH
P P
Power Supply AC ETX2MM704MGB
DC-DC Converter DC-DC Converter
Speaker out Speaker out
Sound Processor Sound Processor
AV Terminal TXN/A1RHTD (PZ800E) AV Terminal TXN/A1RHTD (PZ800E)
A AV Switch A
TXN/A1RHTB (PZ800B) AV Switch TXN/A1RHTB (PZ800B)
Digital Signal Processor Digital Signal Processor
Micon, HDMI Interface Micon, HDMI Interface
Peaks Pro Peaks Pro
Format Converter Format Converter
D Plasma AI TZTNP02RMTB D Plasma AI TZTNP01RLTB
Sub-Field Processor Sub-Field Processor
Remote receiver Remote receiver
K Power LED TXN/K1RHTB K TXN/K1RHTB
Power LED
S Power Switch TNPA4535AB S Power Switch TNPA4535AB
GS SD Card Slot TXNGS1RHTB GS SD Card Slot TXNGS1RHTB
HC PC in, Audio out TXNHC1RHTB HC PC in, Audio out TXNHC1RHTB
C1 Data Driver (Lower Right) TNPA4440 C1 Data Driver (Lower Right) TNPA4446
C2 Data Driver (Lower Center) TNPA4441 C2 Data Driver (Lower Left) TNPA4447
C3 Data Driver (Lower Left) TNPA4442
SC Scan Drive TNPA4410 SC Scan Drive TNPA4410AC
SU Scan out (Upper) TNPA4406 SU Scan out (Upper) TNPA4412
SD Scan out (Lower) TNPA4407 SD Scan out (Lower) TNPA4413
SS Sustain Drive TNPA4411 SS Sustain Drive TNPA4411AC
SS2 Sustain connector TNPA4405
GH HDMI4 in TXNGH1RHTB GH HDMI4 in TXNGH1RHTB
G Front Terminal, Key Switch TXN/G1RHTB G Front Terminal, Key Switch TXN/G1RHTB
PA Fan control TXNPA1RFTB PA Fan control TXNPA1RHTB
GL SD LED TXNGL1RHTB GL SD LED TXNGL1RHTB
6
2. PCB Location & Function (2) PZ85 Series
TH-46PZ85 TH-42PZ85
SU P(AC) SU
PB P(MAIN) PB P
SC SS SC SS
A A
SD D SD D
GH GH
GS GS
C1 C2 C3 G C1 C2 G
M K S M K S
Board Name Function Part Number Board Name Function Part Number
Power Supply MAIN ETX2MM704MGU Power Supply ETX2MM702MFU
P P
Power Supply AC ETX2MM704MGB
DC-DC Converter DC-DC Converter
Speaker out Speaker out
Sound Processor Sound Processor
AV Terminal TXN/A1RLTB (PZ85E) AV Terminal TXN/A1RLTB (PZ85E)
A AV Switch A AV Switch
TZTNP02RKTB (PZ85B) TZTNP02RKTB (PZ85B)
Digital Signal Processor Digital Signal Processor
Micon, HDMI Interface Micon, HDMI Interface
Peaks Lite 2p Peaks Lite 2p
Format Converter Format Converter
D Plasma AI TZTNP01RKTB D Plasma AI TZTNP01RLTB
Sub-Field Processor Sub-Field Processor
Remote receiver TXN/K1RLTB Remote receiver TXN/K1RLTB
K Power LED K Power LED
S Power Switch TXN/S1RLTB S Power Switch TXN/S1RLTB
GS SD Card Slot ,Key Switch TXNGS1RLTB GS SD Card Slot ,Key Switch TXNGS1RLTB
C1 Data Driver (Lower Right) TNPA4443 C1 Data Driver (Lower Right) TNPA4446
C2 Data Driver (Lower Center) TNPA4444 C2 Data Driver (Lower Left) TNPA4447
C3 Data Driver (Lower Left) TNPA4445
SC Scan Drive TNPA4410AB SC Scan Drive TNPA4410AC
SU Scan out (Upper) TNPA4403 SU Scan out (Upper) TNPA4412
SD Scan out (Lower) TNPA4404 SD Scan out (Lower) TNPA4413
SS Sustain Drive TNPA4411AB SS Sustain Drive TNPA4411AC
GH HDMI3 in TXNGH1RLTB GH HDMI3 in TXNGH1RLTB
G Side Terminal TXN/G1RLTB G Side Terminal TXN/G1RLTB
M AISensor TXN/M1RLTB M AISensor TXN/M1RLTB
PB Fan control TXNPB1RKTB PB Fan control TXNPB1RLTB
7
2. PCB Location & Function (3) PZ80 Series
TH-50PZ80 TH-46PZ80 TH-42PZ80
SU P(AC) SU P(AC) SU
PB P(MAIN) PB P(MAIN) PB P
SC SS SC SS SC SS
A A A
SD D SD D SD D
SS2
C1 C2 C3 C1 C2 C3 C1 C2
GS GH G K S GS GH G K S GS GH G K S
Board Name Function Part Number Board Name Function Part Number Board Name Function Part Number
Power Supply MAIN ETX2MM704MGH Power SupplyMAIN ETX2MM704MGH Power Supply ETX2MM702MFH
P P P
Power Supply AC ETX2MM704MGB Power SupplyAC ETX2MM704MGB
DC-DC Converter DC-DC Converter DC-DC Converter
Speaker out Speaker out Speaker out
Sound Processor Sound Processor Sound Processor
AV Terminal AV Terminal TZTNP01RPTD AV Terminal
A AV Switch TZTNP01RPTD A AV Switch A AV Switch TXN/A1RPTB
Digital Signal Processor Digital Signal Processor Digital Signal Processor
Micon, HDMI Interface Micon, HDMI Interface Micon, HDMI Interface
Peaks Lite 2p Peaks Lite 2p Peaks Lite 2p
Format Converter Format Converter Format Converter
D Plasma AI TZTNP02RMTB D Plasma AI TZTNP01RKTB D Plasma AI TZTNP01RLTB
Sub-Field Processor Sub-Field Processor Sub-Field Processor
Remote receiver Remote receiver Remote receiver
K TXN/K1RPTB K TXN/K1RPTB K TXN/K1RPTB
Power LED Power LED Power LED
S Power Switch TXN/S1SLTD S Power Switch TXN/S1SLTD S Power Switch TXN/S1SLTD
GS SD Card Slot TXNGS1RRTB GS SD Card Slot TXNGS1RRTB GS SD Card Slot TXNGS1RRTB
C1 Data Driver (Lower Right) TNPA4440 C1 Data Driver (Lower Right) TNPA4443 C1 Data Driver (Lower Right) TNPA4446
C2 Data Driver (Lower Center) TNPA4441 C2 Data Driver (Lower Center) TNPA4444 C2 Data Driver (Lower Left) TNPA4447
C3 Data Driver (Lower Left) TNPA4442 C3 Data Driver (Lower Left) TNPA4445
SC Scan Drive TNPA4410 SC Scan Drive TNPA4410AB SC Scan Drive TNPA4410AC
SU Scan out (Upper) TNPA4406 SU Scan out (Upper) TNPA4403 SU Scan out (Upper) TNPA4412
SD Scan out (Lower) TNPA4407 SD Scan out (Lower) TNPA4404 SD Scan out (Lower) TNPA4413
SS Sustain Drive TNPA4411 SS Sustain Drive TNPA4411AB SS Sustain Drive TNPA4411AC
SS2 Sustain out TNPA4405
GH HDMI3 in TXNGH1RPTB GH HDMI3 in TXNGH1RPTB GH HDMI3 in TXNGH1RPTB
Front Terminal Front Terminal Front Terminal
G TXN/G1SLTD G TXN/G1RRTB G TXN/G1RRTB
Key Switch Key Switch Key Switch
PB Fan control TXNPB1RJTM PB Fan control TXNPB1RNTB PB Fan control TXNPB1RPTB
8
2. PCB Location & Function (4) PZ8 Series
TH-46PZ8 TH-42PZ8
SU P(AC) SU
PB P(MAIN) PB P
SC SS SC SS
A A
SD D SD D
GS GS
C1 C2 C3 C1 C2
G K S G K S
Board Name Function Part Number Board Name Function Part Number
Power Supply MAIN ETX2MM704MGH Power Supply ETX2MM702MFH
P P
Power Supply AC ETX2MM704MGB
DC-DC Converter DC-DC Converter
Speaker out Speaker out
Sound Processor Sound Processor
AV Terminal AV Terminal TZTNP01RUTD (PZ80E)
A AV Switch TZTNP01RUTD A AV Switch TZTNP01RUTB (PZ80B)
Digital Signal Processor Digital Signal Processor
Micon, HDMI Interface Micon, HDMI Interface
Peaks Lite 2p Peaks Lite 2p
Format Converter Format Converter
D Plasma AI TZTNP01RKTB D Plasma AI TZTNP01RLTB
Sub-Field Processor Sub-Field Processor
Remote receiver Remote receiver
K TXN/K1RRTB K TXN/K1RRTB
Power LED Power LED
S Power Switch TXN/S1RRTB S Power Switch TXN/S1RRTB
GS SD Card Slot TXNGS1RWTB GS SD Card Slot TXNGS1RWTB
C1 Data Driver (Lower Right) TNPA4443 C1 Data Driver (Lower Right) TNPA4446
C2 Data Driver (Lower Center) TNPA4444 C2 Data Driver (Lower Left) TNPA4447
C3 Data Driver (Lower Left) TNPA4445
SC Scan Drive TNPA4410AB SC Scan Drive TNPA4410AC
SU Scan out (Upper) TNPA4403 SU Scan out (Upper) TNPA4412
SD Scan out (Lower) TNPA4404 SD Scan out (Lower) TNPA4413
SS Sustain Drive TNPA4411AB SS Sustain Drive TNPA4411AC
Front Terminal Front Terminal
G Key Switch TXN/G1RUTB G Key Switch TXN/G1RUTB
PB Fan control TXNPB1RNTB PB Fan control TXNPB1RPTB
9
3. PCB List
10
3. PCB List
PZ800 Series PZ85 Series PZ80 Series PZ8 Series
50 42 46 42 50 46 42 46 42
P(MAIN) ETX2MM704MGH ETX2MM702MFH ETX2MM704MGL ETX2MM702MFU ETX2MM704MGH ETX2MM704MGH ETX2MM702MFH ETX2MM704MGH ETX2MM702MFH
P(AC) ETX2MM704MGB --- ETX2MM704MGU --- ETX2MM704MGB ETX2MM704MGB --- ETX2MM704MGB ---
TXN/A1RHTD TXN/A1RHTD TXN/A1RLTB TXN/A1RLTB TZTNP01RUTD
PZ800E PZ800E (PZ85E) PZ85E (PZ80E)
A TZTNP01RPTD TZTNP01RPTD TXN/A1RPTB TZTNP01RUTD
TXN/A1RHTB TXN/A1RHTB TZTNP02RKTB TZTNP02RKTB TZTNP01RUTB
(PZ800B) (PZ800B) (PZ85B) (PZ85B) (PZ80B)
D TZTNP02RMTB TZTNP01RLTB TZTNP01RKTB TZTNP01RLTB TZTNP02RMTB TZTNP01RKTB TZTNP01RLTB TZTNP01RKTB TZTNP01RLTB
K TXN/K1RHTB TXN/K1RHTB TXN/K1RLTB TXN/K1RLTB TXN/K1RPTB TXN/K1RPTB TXN/K1RPTB TXN/K1RRTB TXN/K1RRTB
S TNPA4535AB TNPA4535AB TXN/S1RLTB TXN/S1RLTB TXN/S1SLTD TXN/S1SLTD TXN/S1SLTD TXN/S1RRTB TXN/S1RRTB
GS TXNGS1RHTB TXNGS1RHTB TXNGS1RLTB TXNGS1RLTB TXNGS1RRTB TXNGS1RRTB TXNGS1RRTB TXNGS1RWTB TXNGS1RWTB
HC TXNHC1RHTB TXNHC1RHTB --- --- --- --- --- --- ---
C1 TNPA4440 TNPA4446 TNPA4443 TNPA4446 TNPA4440 TNPA4443 TNPA4446 TNPA4443 TNPA4446
C2 TNPA4441 TNPA4447 TNPA4444 TNPA4447 TNPA4441 TNPA4444 TNPA4447 TNPA4444 TNPA4447
C3 TNPA4442 --- TNPA4445 --- TNPA4442 TNPA4445 --- TNPA4445 ---
SC TNPA4410 TNPA4410AC TNPA4410AB TNPA4410AC TNPA4410 TNPA4410AB TNPA4410AC TNPA4410AB TNPA4410AC
SU TNPA4406 TNPA4412 TNPA4403 TNPA4412 TNPA4406 TNPA4403 TNPA4412 TNPA4403 TNPA4412
SD TNPA4407 TNPA4413 TNPA4404 TNPA4413 TNPA4407 TNPA4404 TNPA4413 TNPA4404 TNPA4413
SS TNPA4411 TNPA4411AC TNPA4411AB TNPA4411AC TNPA4411 TNPA4411AB TNPA4411AC TNPA4411AB TNPA4411AC
SS2 TNPA4405 --- --- --- TNPA4405 --- --- --- ---
GH TXNGH1RHTB TXNGH1RHTB TXNGH1RLTB TXNGH1RLTB TXNGH1RPTB TXNGH1RPTB TXNGH1RPTB --- ---
G TXN/G1RHTB TXN/G1RHTB TXN/G1RLTB TXN/G1RLTB TXN/G1SLTD TXN/G1RRTB TXN/G1RRTB TXN/G1RUTB TXN/G1RUTB
M --- --- TXN/M1RLTB TXN/M1RLTB --- --- --- --- ---
PA TXNPA1RFTB TXNPA1RHTB --- --- --- --- --- --- ---
PB --- --- TXNPB1RKTB TXNPB1RLTB TXNPB1RJTM TXNPB1RNTB TXNPB1RPTB TXNPB1RNTB TXNPB1RPTB
GL TXNGL1RHTB TXNGL1RHTB --- --- --- --- --- --- ---
11
4. Block Diagram
12
4.Block Diagram Signal Processing Circuit (1) TH-42PZ800
GS A D
SD Slot IC7702 IC8620 IC1100 Cable DET
IC9003
Buffer
CI Slot CI MaX
Digital IC8001
TV IC8301
Tuner Analog OSD LVDS
IC4200 SU
Video in
IC9300 SC Panel SS
Comp in IC9400 SD
IC3007
Analog
HC SUB
IC4001
C1 C2
PC Analog Video Data
MIAN
G IC5100 IC2604 Discharge Control
for SC
Video in
Discharge Control
GH IC9500 for SS
HDMI 4 IC3801
HDMI 3 IC4510
IC4503
HDMI 2
HDMI 1
IC3801 (GH Board) IC8001 (A Board) IC9300 / IC9400 (D Board)
: HDMI EQ : Peaks Pro : PD2M (Left / Right)
IC4503(A Board) (Digital Video Processor) LVDS Receiver,
: HDMI EQ ,SW IC4001 (A Board) Sub Field Processor,
IC4510 (A Board) : GS3FS (A/D Converter) Data Driver Processor
: HDMI Processor IC5100 (A Board) IC9500 (D Board)
A/D Converter : GC6 (Video Processor) : FPGA (Discharge Control)
IC3007 (A Board) IC2604 (A Board) IC9003 (D Board)
: Video Switch : FRC-H : Micom
IC8301 (A Board) (Frame Rate Converter)
: Digital Demodulator IC4200 (A Board)
IC7702(GS Board) : MIHO
: SD-SUB Converter (LVDS Transmitter)
IC8620 (A Board) IC1100 (A Board)
: USB HOST : Micom
13
4.Block Diagram Signal Processing Circuit (2) TH-42PZ85
GH A D
HDMI 3 IC3801 Cable DET
IC4510 IC9003
HDMI 2
HDMI 1
G
Video in SU
IC2604
LVDS IC9300 SC Panel SS
Video in IC4200 IC9400
Analog SD
Comp in
IC8001
OSD
IC3001 C1 C2
PC
Video Data
Analog
TV Discharge Control
Tuner Digital for SC
IC8301
Discharge Control
IC8404,05 IC9500 for SS
CI Slot
IC8408,09
GS IC1100
SD Slot
IC3801 (GH Board) IC8001 (A Board) IC9300 / IC9400 (D Board)
: HDMI EQ : Peaks Lite2p : PD2M (Left / Right)
IC3001 (A Board) (Digital Video Processor) LVDS Receiver,
: Video Switch IC2604 (A Board) Sub Field Processor,
IC4510 (A Board) : FRC Data Driver Processor
: HDMI Processor (Frame Rate Converter) IC9500 (D Board)
A/D Converter IC4200 (A Board) : FPGA (Discharge Control)
IC8301 (A Board) : FPGA IC9003 (D Board)
: Digital Demodulator Video Processor IC (Format Converter) : Micom
IC8404,05 (A Board) LVDS Transmitter
: Buffer IC1100 (A Board)
IC8408,09 (A Board) : Micom
: Buffer
14
4.Block Diagram Signal Processing Circuit (3) TH-42PZ80
GH A D
HDMI 3 IC3801 Cable DET
IC4510 IC9003
HDMI 2
HDMI 1
G
Video in SU
LVDS IC9300 SC Panel SS
Video in IC4200 IC9400
Analog SD
Comp in
IC8001
OSD
IC3001 C1 C2
PC
Video Data
Analog
TV Discharge Control
Tuner Digital for SC
IC8301
Discharge Control
IC8404,05 IC9500 for SS
CI Slot
IC8408,09
GS IC1100
SD Slot
IC3801 (GH Board) IC8001 (A Board) IC9300 / IC9400 (D Board)
: HDMI EQ : Peaks Lite2p : PD2M (Left / Right)
IC3001 (A Board) (Digital Video Processor) LVDS Receiver,
: Video Switch IC4200 (A Board) Sub Field Processor,
IC4510 (A Board) : FPGA Data Driver Processor
: HDMI Processor Video Processor IC (Format Converter) IC9500 (D Board)
A/D Converter LVDS Transmitter : FPGA (Discharge Control)
IC8301 (A Board) IC1100 (A Board) IC9003 (D Board)
: Digital Demodulator : Micom : Micom
IC8404,05 (A Board)
: Buffer
IC8408,09 (A Board)
: Buffer
15
4.Block Diagram Signal Processing Circuit (4) TH-42PZ8
A D
HDMI 2 Cable DET
IC4510 IC9003
HDMI 1
G
Video in
SU
LVDS IC9300 SC Panel SS
Video in IC4200 IC9400
Analog SD
IC3001 IC8001 OSD
Comp in
C1 C2
Video Data
Analog
TV
Discharge Control
Tuner Digital for SC
IC8301
Discharge Control
IC8404,05 IC9500 for SS
CI Slot
IC8408,09
GS IC1100
SD Slot
IC3001 (A Board) IC8001 (A Board) IC9300 / IC9400 (D Board)
: Video Switch : Peaks Lite2p : PD2M (Left / Right)
IC4510 (A Board) (Digital Video Processor) LVDS Receiver,
: HDMI Processor IC4200 (A Board) Sub Field Processor,
A/D Converter : FPGA Data Driver Processor
IC8301 (A Board) Video Processor IC (Format Converter) IC9500 (D Board)
: Digital Demodulator LVDS Transmitter : FPGA (Discharge Control)
IC8404,05 (A Board) IC1100 (A Board) IC9003 (D Board)
: Buffer : Micom : Micom
IC8408,09 (A Board)
: Buffer
16
5. Troubleshooting
17
5. Troubleshooting Picture Problem (1)
Abnormal Picture (All over the screen)
No Picture Noise Picture Noise Picture A, D Board
1. Disconnect A5 connector
2. Enter to the Test pattern
Noise Picture Irregular Color
Vertical Line (OSD also NG) (OSD also NG)
No After disconnect A5 connector No
Can you see the
then Power ON. D Board
OSD on the screen?
Can you see the white pattern (*1)?
Irregular Color Yes Yes
Horizontal Line Horizontal Line (OSD also NG)
A Board
Enter to the test pattern. No
Can you see the D Board
pattern (*1) normally?
Yes
(*1)
A Board White Pattern and Test Pattern are generated by IC9300/IC9400 of D Board.
(Original Picture)
When these patterns are normally displayed on the screen, It can be seem
good processing circuit between the D board and panel drive circuit.
Notice:
Regarding information for test pattern in detail,
Please refer to Page 22, 23.
18
5. Troubleshooting Picture Problem (2-1)
Abnormal Picture, Vertical Line ( Some part of the screen)
D, C Board, Plasma Panel
Is a few thin vertical line No D Board
displayed on the screen? (C Board)
(*1)
Yes
(*1)
Regarding idea of diagnosis for vertical line problem,
Panel please refer to Page 20 and the following idea.
(Single Scan Drive e.g. 50 / 46 inch) (Single Scan Drive e.g. 42 inch)
Panel Panel
Full vertical line Thin vertical line Full vertical line Thin vertical line
D Board D Board
(C Board) (C Board)
Vertical lines at Vertical lines at
left or right or center left or right half
Abnormal picture at Abnormal picture at
left or right or center left or right half
19
5. Troubleshooting Picture Problem (2-2)
Model No:TH-50PZ800, TH-46PZ85, TH-50/46PZ80, TH-46PZ8
Panel Type: 1080p resolution panel Scan System: Single Scan Drive
D
Cable DET
IC9003 SU
SS
SC Panel
IC9300
IC9400
D5 SD
Test
Pattern
SS2
C1 C2 C3
Discharge Control
IC9500 for SC
Video Data
Discharge Control
for SS
Model No: TH-42PZ800, TH-42PZ85, TH-42PZ80, TH-42PZ8
Panel Type: 1080p resolution panel Scan System: Single Scan Drive
D
Cable DET
IC9003 SU
SC Panel SS
IC9300
IC9400
D5 SD
Test
Pattern
C1 C2
Discharge Control
IC9500 for SC
Video Data
Discharge Control
for SS
20
6. Appendix
21
6. Appendix Diagnosis by Test Pattern (1)
In case of PDP, the picture problem at all over the screen (Picture Noise, Full Vertical Line) is mainly caused
by D or A board defective. This Test Pattern is able to diagnose D or A board. Because, D board had Test
Pattern. So, we can judge by using Test Pattern which is defective. Regarding diagnosis for these board,
please confirm as follows.
Full HD Models 1 : R/G/B/W 2 : Black 3 : White 4 : White 5 : Red
(PZ800,PZ85,PZ80,PZ8 series) (by A Board) (by A Board) (by A Board) (by D Board)
TEMP
TIME
0
000
Picture Noise, Full Vertical Line
9 : Ramp White 8 : ON/OFF Aging 7 : Blue 6 : Green
Pattern Defective Board
Abnormal D Board 10 : Ramp Red 11 : Ramp Green 12 : Ramp Bule 13 : 1% window
Normal A Board (or D Board)
17 : White Frame 16 : Scroll 15 : A and B zone 14 : Color bar
1. While pressing "VOLUME ( - ) " button of the TV set,
press " 0 " button of the remote control three
times within 2 seconds.
2. Push button "1" of Remote Controller several times,
and select "Aging" setting,then "Test pattern" will appear.
3. Press "3" button for next picture in forward direction
and test patterns are shown repeatedly.
Press "4" button for previous picture in reverse direction Example Picture
and test patterns are shown repeatedly.
(or Push "GREEN" button in forward direction and
test pattern are not shown repeatedly)
(or Press "RED" button in reverse direction and
test pattern are not shown repeatedly)
22
6. Appendix Diagnosis by Test Pattern (2)
In case of No picture problem (Sound OK), the defective board is mainly A or D board. But in this case,
Test Pattern isn't useful for diagnosis. Because, this symptom can not display OSD and not enter to the
Service Mode. This method is possible to judge the defective board in this symptom.
Full HD Models
(A5 Connector)
(PZ800,PZ85,PZ80,PZ8 series)
No picture (Sound OK)
Power ON after removing A5 Connector
Pattern Defective Board
White Picture A Board (D Board)
No Picture D Board (SC or SS)
1. This white pattern is generated by IC9300,IC9400 on D board.
2. When Power ON after removing A5 connector, white picture is provided to panel drive circuit.
Then, white picture automatically appears in normal situation.
A D
IC1100
IC9300 VIDEO DATA
MICRO IC9400 PICTURE DATA
PROCESSOR PLASMA AI S.F. PROCESSOR
OUTPUT DRIVER
To C Board
IC8001 IC4200 LVDS
LVDS LVDS
A D
Peaks Lite2p TRANS RECEIVER White Picture
MITTER 5 5
23
R
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
