Image preview - the first page of the document



>> Download operating instr documenatation <<

Text preview - extract from the document

                                                                                 Model No.
                                                                             TX-P42X50B
                                                                             TX-P50X50B




Operating Instructions
Plasma Television




Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.



  English      UK and Ireland model
                                                                             TQB0E2200
    Features
    DVB-T tuner built-in                                          VIERA TOOLS - Display special feature icons for
     Receives DVB (Digital Video Broadcasting) digital            easy accessibility (p. 27)
     terrestrial broadcasts.                                       Special features (such as VIERA Link and Media
    DVB-T2 tuner built-in                                          Player) can be accessed easily by using the VIERA
     DVB-T2 is an advanced digital terrestrial system for          TOOLS button.
     more efficient transmission.                                 Dolby Digital Plus decoders
     Available DVB-T2 broadcasts will be tuned                     It is possible to decode Dolby Digital Plus audio track
     automatically when you perform DVB Auto Setup.                (multi-channel sound) and output as a Dolby Digital
    Using USB devices                                              multi-channel sound signal from the DIGITAL AUDIO
     Enjoy the photo, video and music in the USB Flash             OUT / HDMI2 (ARC function) terminal.
     Memory on Media Player. (p. 51)                              Owner ID (p. 48)
    Timer Programming (p. 20, 42)                                  Owner ID is an anti-theft function. Entering the PIN
     Timer Programming enables you to use functions such           number and owner's personal information will help the
     as programme reminder and programme recording to              Police to determine the owner in the case of theft.
     the external recorder.                                       Supports Audio Description signal (p. 17, 32)
    SDXC Card
     This TV supports SDXC Card. SDXC is the latest                 Audio Description (when broadcast) adds an additional
     standard of SD Card and a higher storage capacity              soundtrack to describe events on screen (narration)
     card.                                                          and aids understanding and enjoyment, particularly for
    Link up and control the connected equipment with                visually-impaired users.
    "Q-Link" and "VIERA Link" (p. 59)
     Q-Link and VIERA Link provide easy recording
     and playback, creation of a home theatre without
     complicated settings, etc.




    Digital Switchover for Terrestrial broadcasts
    Starting in late 2007 and ending in 2012, TV services in the UK will go completely digital, TV region by TV region.
    If you have any questions, please call Digital UK on 08456 50 50 50 or visit www.digitaluk.co.uk
    Digital Switchover will cover a period of several weeks. When it starts you will lose all Analogue TV channels and
    some Digital TV channels will be missing.
    You will need to retune your TV each time this happens to recover your digital channels. Analogue channels are
    permanently turned off, it will not be possible to recover them.
     To retune your TV [Auto Setup] in [DVB Tuning Menu]-DVB mode (p. 38)
    Users of cable or satellite boxes should still retune the TV to continue to receive Freeview channels via their aerial.
    (Your Analogue channel for viewing Cable or Satellite services will change to a new position.)
     Due to the digital reception technologies involved, quality of the digital signals may be relatively low in some cases,
       despite good reception of analogue channels.


    Notice for DVB / Data broadcasting
    This TV is designed to meet the standards (as of August, 2010) of digital services.
     Not all the features are available depending on the country, area, broadcaster, network environment and service
     provider.
     The compatibility with future services is not guaranteed.
     Check the latest information on the available services at the following website.
     http://panasonic.jp/support/global/cs/tv/
2
Do not display any still part of the image for
a long period
                                                                 Contents
In such cases the still part of the image remains dimly on the
plasma screen ("image retention"). This is not considered a      Be Sure to Read
malfunction and is not covered by the warranty.
Typical still image parts:                                       Safety Precautions
