                                                                                 ORDER No. PCZ1203032BE




                Service Hint
Plasma Display Television
Models: TX-P50GT30B, TX-P50GT30J, TX-P50GT30E, TX-P50GT30Y, TX-PR50GT30
         TX-P50ST30B, TX-P50ST30J, TX-P50ST30E, TX-PF50ST30, TX-PR50ST30,
         TX-P50ST31B, TX-P50ST33J, TX-P50ST33E, TX-P50ST32Y

Subject: Compatibility of Spare Parts PDP panels
         Supplied PDP panel Order No. MD50F14C9Z, MD50F14C4Z




 Information: If the underside chassis (placed on C-Board) is different to defective panel's one,
                 please remove it from defective panel, then use it to new panel.




       Bottom side of panel.




                                                                    CONTACT METAL BOTTOM
                                                                    Part No. TUX3DJ080, TUX3DJ090
