Image preview - the first page of the document



>> Download TQB0E2160 documenatation <<

Text preview - extract from the document

                                                                          Model No.
                                                                      TX-P42ST31B
                                                                      TX-P50ST31B




Operating Instructions
Plasma Television




Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this
product and retain them for future reference.
The images shown in this manual are for illustrative purposes only.


  English    UK and Ireland model                                       TQB0E2160
    Features
    3D technology -
     Viewing 3D images on the Full HD panel
     You can enjoy viewing 3D images on this TV by wearing the 3D Eyewear.
    RealD 3D
     This TV and 3D Eyewear use the 3D technology of RealD. RealD is one of the inventors in 3D
     technology.
    DVB-T tuner built-in
     Receives DVB (Digital Video Broadcasting) digital terrestrial broadcasts.
    DVB-T2 tuner built-in
     DVB-T2 is an advanced digital terrestrial system for more efficient transmission.
     Available DVB-T2 broadcasts will be tuned automatically when you perform DVB Auto Setup.
    GUIDE Plus+ (p. 22)
     This TV supports the TV Guide services sent from the GUIDE Plus+ system.
    Sharp pictures and clear sound with HDMI connection (p. 91)
     Enjoy high definition digital picture and high quality sound by using an HDMI cable.
    Using USB devices
     Enjoy the photo, video and music in the USB Flash Memory on Media Player. (p. 59)
     Wireless LAN Adaptor for the network connection. (p. 6, 12, 14)
     USB keyboard, gamepad, etc. are available. (p. 92)
    Timer Programming (p. 23, 51)
     Timer Programming enables you to use functions such as programme reminder and programme
     recording to the external recorder.
    SDXC Card
     This TV supports SDXC Card. SDXC is the latest standard of SD Card and a higher storage capacity
     card.
    VIERA Connect - Enjoy great web entertainment (p. 17, 75)
     VIERA Connect allows you to access some specific websites supported by Panasonic, and enjoy
     internet contents such as photos, videos, games, etc. from VIERA Connect home screen.
    Link up and control the connected equipment with "Q-Link" and "VIERA Link" (p. 76)
     Q-Link and VIERA Link provide easy recording and playback, creation of a home theatre without
     complicated settings, etc.
    VIERA TOOLS - Display special feature icons for easy accessibility (p. 34)
     Special features (such as VIERA Link and Media Player) can be accessed easily by using the VIERA
     TOOLS button.
    Dolby Digital Plus / Dolby Pulse decoders
     It is possible to decode Dolby Digital Plus / Dolby Pulse multi-channel audio tracks and output as Dolby
     Digital Bitstream (multi-channel sound signal) from DIGITAL AUDIO OUT / HDMI2 (ARC function) terminals.
    Owner ID (p. 56)
     Owner ID is an anti-theft function. Entering the PIN number and owner's personal information will help
     the Police to determine the owner in the case of theft.
    Supports Audio Description signal (p. 19, 38)
     Audio Description (when broadcast) adds an additional soundtrack to describe events on screen
     (narration) and aids understanding and enjoyment, particularly for visually-impaired viewers.
    Digital Switchover for Terrestrial broadcasts
     Starting in late 2007 and ending in 2012, TV services in the UK will go completely digital, TV region by
     TV region.
     If you have any questions, please call Digital UK on 08456 50 50 50 or visit www.digitaluk.co.uk
     Digital Switchover will cover a period of several weeks. When it starts you will lose all Analogue TV
     channels and some Digital TV channels will be missing.
     You will need to retune your TV each time this happens to recover your digital channels. Analogue
     channels are permanently turned off, it will not be possible to recover them.
