Image preview - the first page of the document
>> Download tc_14a12p_20b12 documenatation <<
Text preview - extract from the document
Order DCS - AGO2002 - 003 - MS
Service Manual
Color Television
TC-14A12P
TC-20B12
BR2L chassis
Specifications
TELEVISION TC-14A12P TC-20B12
Power source 110/220 V AC, 60 Hz automatic switch 110/220 V AC, 60 Hz automatic switch
Consumption 55 W 69 W
Antenna input jack 75 W - VHF/UHF/Cable 75 W - VHF/UHF/Cable
Color systems NTSC/PAL-N/AUTO/PAL-M NTSC/PAL-N/AUTO/PAL-M
Tuning system F.S.T. F.S.T.
Channel capability 2 to 13 (VHF) 2 to 13 (VHF)
14 to 69 (UHF) 14 to 69 (UHF)
1 to 125 (Cable) 1 to 125 (Cable)
Picture tube (visual diagonal) 33 cm 48 cm
Audio system 3 W max (RMS) 3 W max (RMS)
Video input jack 1 (back of unit) 1 (back of unit)
Dimension (width, height, depth) 370 x 349 x 374 mm 502 x 455 x 471 mm
Weight 9,6 kg 17 kg
