Image preview - the first page of the document
>> Download panasonic_tx-28md4_-_euro4 documenatation <<
Text preview - extract from the document
ORDER No. SM-98033
Colour Television
TX-28MD4P
TX-25MD4P
TX-21MD4P
EURO4 Chassis
SPECIFICATIONS
(Information in brackets { } refers to model TX-25MD4P) AV2 IN Video (21 pin) 1V p-p 75
(Information in brackets [ ] refers to model TX-21MD4P) Audio (21 pin) 500mV rms 10k
Power Source: 220-240V AC, 50Hz S-Video IN Y: 1V p-p 75
(21-pin) C:0.3V p-p 75
Power Consumption: 130W [115W]
AV2 OUT Video (21 pin) 1Vp-p 75
Aerial Impedance: 75 unbalanced, Coaxial Type Audio (21 pin) 500mV rms 1k
Selectable output (21 pin)
Stand-by Power AV3 IN Audio (RCAx2) 500mV rms 10k
Consumption: 1,8W Video (RCAx1) 1V p-p 75
Receiving System: PAL B/G, H, D/K, PAL-525/60
