Image preview - the first page of the document
>> Download t7730ca_sup3_7115 documenatation <<
Text preview - extract from the document
ORDER NO. KMS1402864SE
PROPRIETARY TELEPHONE
Model No. KX-T7730CA
-3
m ent (for Kazakhstan, Uzbekistan, Kyrgyzstan, Tajikistan
e
ppl and Turkmenistan)
Su
Please file and use this supplement manual together with the service manual for Model No. KX-T7730CA
Order No. KMS0804481CE.
TABLE OF CONTENTS
PAGE
1 CHANGES----------------------------------------------------------- 2
1.1. Subject ------------------------------------------------------ 2
1.2. Replacement Parts List ---------------------------------- 2
1.3. SCHEMATIC DIAGRAM --------------------------------- 6
1.4. PRINTED CIRCUIT BOARD (MAIN BOARD)------ 9
