Image preview - the first page of the document
>> Download na_127vb4_print0616ym documenatation <<
Text preview - extract from the document
Order No. VES1204001CE
Drum Type Washing Machine
Model No. NA-127VB4
Model No. NA-128VB4
Model No. NA-147VB4
Model No. NA-148VB4
Product Color : White
Destination : Germany, Spain, France, Italy, Belgium,
, Norway
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 7.1. Autotest----------------------------------------------------- 12
2 Specifications ----------------------------------------------------- 4 8 Service Mode ----------------------------------------------------- 14
2.1. Product Specifications------------------------------------ 4 8.1. Service Autotest ------------------------------------------ 14
2.2. Name Plate-------------------------------------------------- 4 8.2. Failure Codes --------------------------------------------- 15
3 Technical Descriptions ----------------------------------------- 5 9 Troubleshooting Guide --------------------------------------- 16
3.1. Twinjet Information ---------------------------------------- 5 10 Disassembly and Assembly Instructions--------------- 17
4 Location of Controls and Components ------------------- 6 10.1. Torque Values--------------------------------------------- 17
5 Installation Instructions ---------------------------------------- 7 10.2. Top Plate --------------------------------------------------- 18
5.1. Moving and Installing ------------------------------------- 7 10.3. Door --------------------------------------------------------- 18
5.2. Detergent Box Group ------------------------------------- 8 10.4. Spring Wire ------------------------------------------------ 20
6 Operating Instructions------------------------------------------ 9 10.5. Detergent Drawer ---------------------------------------- 20
6.1. LCD Screen, Function Buttons & Knobs ------------ 9 10.6. Control Panel---------------------------------------------- 21
6.2. Program List ------------------------------------------------ 9 10.7. Kick Plate -------------------------------------------------- 22
6.3. Program Details-------------------------------------------10 10.8. Front Panel ------------------------------------------------ 22
6.4. Program Details with Half Load Defection --------- 11 10.9. Upper Support Bracket --------------------------------- 24
6.5. Child Lock -------------------------------------------------- 11 10.10. Detergent Drawer Housing ---------------------------- 24
7 Test Mode ----------------------------------------------------------12 10.11. Power Cable Group and Parasite Filter ------------ 25
