Image preview - the first page of the document
>> Download Seagate Barracuda 5400.1 ST340015A, ST340015ACE Installation Guide documenatation <<
Text preview - extract from the document
Jumper settings for this drive are shown below
Drive is master
or single drive
Drive is slave
Barracuda 5400.1 Installation Guide Use cable select
ST340015A and ST340015ACE Drive is master with non-
ATA Interface Disc Drives ATA-compatible slave
Master/slave jumpers (see table for key to jumper settings)
Publication Number: 100264272, Rev. C, November 2003
The easiest way to install your drive 2. Mount the drive and attach cables
a. Slide the drive into a 3.5-inch drive bay. You can mount the drive in any
DiscWizardTM, available exclusively from Seagate, provides you with cus-
orientation, but we recommend mounting with the circuit board down.
tomized installation instructions for your hard drive. You can download Dis-
Note. To mount the drive in a 5.25-inch drive bay, you must purchase
cWizard for free from the Seagate web site at www.seagate.com/support
mounting brackets, available from your computer dealer.
or run the program directly from your web browser. In either case, you
should run DiscWizard before you install your drive. b. Secure the drive using four 6-32 UNC mounting screws in either the
side-mounting or bottom-mounting holes. Insert the screws no more
If you cannot run DiscWizard, follow the instructions on this installation
than 0.20 inches (5.08 mm) into the bottom-mounting holes and no
sheet to install and configure your drive.
more than 0.14 inches (3.55 mm) into the side-mounting holes.
What you need Caution. Do not overtighten the
