Image preview - the first page of the document
>> Download ma documenatation <<
Text preview - extract from the document
MAINTENANCE
A
SECTION
MAINTENANCE
MA B
C
D
E
CONTENTS
SERVICE INFORMATION ........................... 2
. Checking Fuel Line .................................................22
. F
Changing Air Cleaner Filter ....................................22.
PREPARATION .................................................. 2
. Changing Engine Oil ...............................................22
.
Special Service Tool ................................................ 2
. Changing Oil Filter ..................................................23
. G
Commercial Service Tool ......................................... 2
. Changing Spark Plugs (Platinum-Tipped Type) .....24 .
Checking EVAP Vapor Line ....................................25 .
GENERAL MAINTENANCE ............................... 3
.
Explanation of General Maintenance ....................... 3
. CHASSIS AND BODY MAINTENANCE ........... 26 H
Checking Exhaust System ......................................26 .
PERIODIC MAINTENANCE ............................... 5
. Checking A/T Fluid .................................................26.
Introduction of Periodic Maintenance ....................... 5 . Changing A/T Fluid .................................................27. I
Schedule 1 ............................................................... 5
. Checking Transfer Fluid .........................................28 .
Schedule 2 ............................................................... 7
. Changing Transfer Fluid .........................................28 .
RECOMMENDED FLUIDS AND LUBRI- Checking Propeller Shaft ........................................29 . J
Checking Differential Gear Oil ................................29 .
CANTS ................................................................ 9
.
Changing Differential Gear Oil ................................29 .
Fluids and Lubricants ............................................... 9
.
Balancing Wheels (Bonding Weight Type) .............30 .
Engine Oil Recommendation ................................... 9. K
Tire Rotation ...........................................................31
.
Anti-Freeze Coolant Mixture Ratio ......................... 10 .
Checking Brake Fluid Level and Leaks ..................32 .
ENGINE MAINTENANCE (VQ35DE ENGINE) 11
.... Checking Brake Line and Cables ...........................32 .
Checking Drive Belts .............................................. 11
. Changing Brake Fluid .............................................32 . MA
Drive Belts Tension Adjustment ............................. 11 . Checking Disc Brake ..............................................32 .
Changing Engine Coolant ...................................... 12. Checking Steering Gear and Linkage .....................33 .
Checking Fuel Line ................................................ 15
. Checking Power Steering Fluid and Line ...............33 . M
Changing Air Cleaner Filter .................................... 15
. Axle and Suspension Parts ....................................34 .
Changing Engine Oil .............................................. 15
. Drive Shaft ..............................................................34
.
Changing Oil Filter ................................................. 16
. Lubricating Locks, Hinges and Hood Latch ............35 .
Checking Seat Belt, Buckles, Retractors, Anchors N
Changing Spark Plugs (Platinum-Tipped Type) ..... 17 .
Checking EVAP Vapor Line ................................... 18 . and Adjusters ..........................................................35
.
ENGINE MAINTENANCE (VK45DE ENGINE) 19
.... SERVICE DATA AND SPECIFICATIONS O
Checking Drive Belts .............................................. 19
. (SDS) ................................................................. 37
Tension Adjustment ............................................... 19
. Standard and Limit .................................................37
.
Changing Engine Coolant ...................................... 19
. P
Revision: 2007 April MA-1 2008 FX35/FX45
PREPARATION
< SERVICE INFORMATION >
SERVICE INFORMATION
PREPARATION
Special Service Tool INFOID:0000000001328891
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
KV10115801 Removing and installing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
S-NT375
Commercial Service Tool INFOID:0000000001328892
Tool name
Description
(Kent-Moore No.)
Power tool Loosening nuts and bolts
( -- )
PBIC0190E
Spark plug wrench Removing and installing spark plug
( -- )
S-NT047
Belt tension gauge Checking drive belt tension (VQ35DE)
(BT3373-F)
AMA126
Revision: 2007 April MA-2 2008 FX35/FX45
GENERAL MAINTENANCE
< SERVICE INFORMATION >
GENERAL MAINTENANCE
A
Explanation of General Maintenance INFOID:0000000001328893
General maintenance includes those items which should be checked during the normal day-to-day operation B
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE
C
The maintenance items listed here should be performed from time to time, unless otherwise specified.
Item Reference page
Tires Check the pressure with a gauge, including the spare, at least once a month
and always prior to a long distance trips. Adjust to the specified pressure if nec- -- D
essary. Check carefully for damage, cuts or excessive wear.
Wheel nuts When checking the tires, make sure no nuts are missing, and check for any
-- E
loose nuts. Tighten if necessary.
Clean the windshield on a regular basis. Check the windshield at least every six
Windshield --
months for cracks or other damage. Repair as necessary.
Tire rotation Tires should be rotated every 12,000 km (7,500 miles). MA-31 F
Transmitter compo-
nents in tire pressure Replace grommet seal, valve core and cap of the transmitter in TPMS every tire
WT-10
monitoring system replacement by reaching wear limit of tire. G
(TPMS)
Wheel alignment and If the vehicle pulls to either side while driving on a straight and level road, or if
balance you detect uneven or abnormal tire wear, there may be a need for wheel align- H
MA-30, FSU-5
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
balancing may be needed.
Windshield wiper
Check for cracks or wear if they do not wipe properly. -- I
blades
Doors and engine Check that all doors and the engine hood operate smoothly as well as the trunk
hood lid and back hatch. Also make sure that all latches lock securely. Lubricate if
necessary. Make sure that the secondary latch keeps the hood from opening J
MA-35
when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.
K
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head- --
lamp aim. Clean the headlamps on a regular basis.
MA
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,
etc.
Item Reference page M
Warning lamps and
Make sure that all warning lamps and chimes are operating properly. --
chimes
Windshield wiper and Check that the wipers and washer operate properly and that the wipers do not N
--
washer streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
--
quantity when operating the heater or air conditioner.
O
Steering wheel Check that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises. --
Free play: Less than 35 mm (1.38 in)
P
Seats Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every po-
sition. Check that the head restrains move up and down smoothly and that the --
locks (if equipped) hold securely in all latched positions. Check that the latches
lock securely for folding-down rear seatbacks.
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely. MA-35
Check the belt webbing for cuts, fraying, wear or damage.
Revision: 2007 April MA-3 2008 FX35/FX45
GENERAL MAINTENANCE
< SERVICE INFORMATION >
Item Reference page
Accelerator pedal Check the pedal for smooth operation and make sure the pedal does not catch
--
or require uneven effort. Keep the floor mats away from the pedal.
Brakes Check that the brake does not pull the vehicle to one side when applied. --
Brake pedal and Check the pedal for smooth operation and make sure it has the proper distance
booster under it when depressed fully. Check the brake booster function. Be sure to BR-5, BR-14
keep the floor mats away from the pedal.
Parking brake Check that the pedal has the proper travel and make sure that the vehicle is
PB-3
held securely on a fairly steep hill when only the parking brake is applied.
Automatic transmis- Check that the lock release button on the selector lever operates properly and
sion "Park" mecha- smoothly. On a fairly steep hill check that the vehicle is held securely with the --
nism selector lever in the P (Park) position without applying any brakes.
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. MA-12, MA-19
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, de- --
terioration or loose connections.
Brake fluid level Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the
MA-32
reservoir.
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN"
lines. Vehicles operated in high temperatures or under severe conditions re- SC-4
quire frequent checks of the battery fluid level.
Engine drive belts Make sure that no belt is frayed, worn, cracked or oily. MA-11, MA-19
Engine oil level Check the level on the oil level gauge after parking the vehicle on a level spot
MA-15, MA-22
and turning off the engine.
Power steering fluid Check the level on the dipstick with the engine off. Check the lines for improper
MA-33
level and lines attachment, leaks, cracks, etc.
Exhaust system Make sure there are no loose supports, cracks or holes. If the sound of the ex-
haust seems unusual or there is a smell of exhaust fumes, immediately locate MA-26
the trouble and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
--
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
--
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.
Revision: 2007 April MA-4 2008 FX35/FX45
PERIODIC MAINTENANCE
< SERVICE INFORMATION >
PERIODIC MAINTENANCE
A
Introduction of Periodic Maintenance INFOID:0000000001328894
Two different maintenance schedules are provided, and should be used, depending upon the conditions in B
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
Follow Periodic Maintenance Schedule 1 if the driving habits frequently include Emission Control Sys- C
one or more of the following driving conditions: tem Maintenance
