Image preview - the first page of the document
>> Download ma documenatation <<
Text preview - extract from the document
MAINTENANCE
A
SECTION
MAINTENANCE
MA B
C
D
E
CONTENTS
PREPARATION ........................................... 3
. ENGINE OIL : Refilling ...........................................17
. F
PREPARATION .................................................. 3
. OIL FILTER ...............................................................17
.
Special Service Tool ................................................ 3
. OIL FILTER : Removal and Installation ..................17 .
G
Commercial Service Tool ......................................... 3
. OIL FILTER : Inspection .........................................18 .
ON-VEHICLE MAINTENANCE .................... 4
. SPARK PLUG ...........................................................18
.
SPARK PLUG : Removal and Installation ..............18 . H
GENERAL MAINTENANCE ............................... 4
. SPARK PLUG : Inspection .....................................19 .
Explanation of General Maintenance ....................... 4
.
EVAP VAPOR LINES ...............................................19
.
PERIODIC MAINTENANCE ............................... 6
. EVAP VAPOR LINES : Inspection ..........................19 . I
Introduction of Periodic Maintenance ....................... 6 .
CHASSIS MAINTENANCE ............................... 20
Schedule 1 ............................................................... 6
.
Schedule 2 ............................................................... 8
. EXHAUST SYSTEM ..................................................20
. J
EXHAUST SYSTEM : Inspection ...........................20 .
RECOMMENDED FLUIDS AND LUBRI-
CANTS ...............................................................10
. A/T FLUID .................................................................20
. K
Fluids and Lubricants ............................................. 10
. A/T FLUID : Inspection ...........................................20 .
Engine Oil Recommendation ................................. 10 . A/T FLUID : Changing ............................................21 .
Anti-Freeze Coolant Mixture Ratio ......................... 11 .
M/T OIL .....................................................................22
. L
ENGINE MAINTENANCE ..................................12
. M/T OIL : Inspection ...............................................22 .
M/T OIL : Draining ..................................................22 .
DRIVE BELTS .......................................................... 12
. M/T OIL : Refilling ...................................................22
. M
DRIVE BELTS : Exploded View ............................. 12 .
DRIVE BELTS : Checking ...................................... 12 . CLUTCH FLUID ........................................................23
.
DRIVE BELTS : Tension Adjustment .................... 12 . CLUTCH FLUID : Inspection ..................................23 .
N
ENGINE COOLANT .................................................. 12
. REAR PROPELLER SHAFT: 3S80A .......................23
.
ENGINE COOLANT : Draining ............................... 12. REAR PROPELLER SHAFT: 3S80A : Inspection....23
ENGINE COOLANT : Refilling ............................... 13
.
REAR PROPELLER SHAFT: 3S80A-R ...................23 . O
ENGINE COOLANT : Flushing .............................. 15 .
REAR PROPELLER SHAFT: 3S80A-R : Inspec-
FUEL LINES ............................................................. 15
. tion ..........................................................................23
.
FUEL LINES : Inspection ....................................... 16 . MA
REAR DIFFERENTIAL GEAR OIL: R200 ................24 .
AIR CLEANER FILTER ............................................ 16
. REAR DIFFERENTIAL GEAR OIL: R200 : Inspec-
AIR CLEANER FILTER : Removal and Installation tion ..........................................................................24
.
.... 16 REAR DIFFERENTIAL GEAR OIL: R200 : Drain-
ing ...........................................................................24
.
ENGINE OIL ............................................................. 16
. REAR DIFFERENTIAL GEAR OIL: R200 : Refill-
ENGINE OIL : Draining .......................................... 16. ing ...........................................................................25
.
Revision: 2007 June MA-1 G37 Coupe
REAR DIFFERENTIAL GEAR OIL: R200V ............. 25 . BODY MAINTENANCE .................................... 33
.
REAR DIFFERENTIAL GEAR OIL: R200V : In-
spection ................................................................. 25
. LOCKS, HINGES AND HOOD LATCH .................... 33 .
REAR DIFFERENTIAL GEAR OIL: R200V : LOCKS, HINGES AND HOOD LATCH : Lubricat-
Draining ................................................................. 25
. ing .......................................................................... 33
.
REAR DIFFERENTIAL GEAR OIL: R200V : Refill-
SEAT BELT, BUCKLES, RETRACTORS, AN-
ing .......................................................................... 26
.
CHORS AND ADJUSTERS ..................................... 33
.
WHEELS (BONDING WEIGHT TYPE) .................... 26 . SEAT BELT, BUCKLES, RETRACTORS, AN-
WHEELS (BONDING WEIGHT TYPE) : Adjust- CHORS AND ADJUSTERS : Inspection ................ 33 .
ment ....................................................................... 26
.
SERVICE DATA AND SPECIFICATIONS
BRAKE FLUID LEVEL AND LEAKS ....................... 29
. (SDS) .......................................................... 34
BRAKE FLUID LEVEL AND LEAKS : Inspection ... 29
SERVICE DATA AND SPECIFICATIONS
BRAKE LINES AND CABLES ................................. 29
. (SDS) ................................................................ 34
.
BRAKE LINES AND CABLES : Inspection ............ 29 .
DRIVE BELTS .......................................................... 34
.
BRAKE FLUID ......................................................... 29
. DRIVE BELTS : Drive Belt ..................................... 34 .
BRAKE FLUID : Changing ..................................... 29 .
ENGINE COOLANT ................................................. 34
.
DISC BRAKE ........................................................... 29
. ENGINE COOLANT :
DISC BRAKE : Inspection ..................................... 30 . Periodical Maintenance Specification ................... 34 .
DISC BRAKE : Front Disc Brake ........................... 30 .
DISC BRAKE : Rear Disc Brake ............................ 30 . ENGINE OIL ............................................................. 34
.
ENGINE OIL :
STEERING GEAR AND LINKAGE .......................... 31
. Periodical Maintenance Specification ................... 34 .
STEERING GEAR AND LINKAGE : Inspection ..... 31 .
SPARK PLUG .......................................................... 34
.
POWER STEERING FLUID AND LINES ................. 31 . SPARK PLUG : Spark Plug ................................... 34 .
POWER STEERING FLUID AND LINES : Inspec-
tion ......................................................................... 31
. ROAD WHEEL ......................................................... 34
.
ROAD WHEEL : Road Wheel ................................ 34 .
AXLE AND SUSPENSION PARTS .......................... 32
.
AXLE AND SUSPENSION PARTS : Inspection .... 32 .
Revision: 2007 June MA-2 G37 Coupe
PREPARATION
< PREPARATION >
PREPARATION A
PREPARATION
Special Service Tool INFOID:0000000001679211
B
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description C
Tool name
KV10115801 Removing and installing oil filter
(J38956) a: 64.3 mm (2.531 in) D
Oil filter wrench
E
S-NT375
F
Commercial Service Tool INFOID:0000000001679212
Tool name
G
Description
(Kent-Moore No.)
Power tool Loosening nuts and bolts
( -- ) H
I
PBIC0190E
J
Spark plug wrench Removing and installing spark plug
( -- ) a : 14 mm (0.55 in)
K
L
JPBIA0399ZZ
M
N
O
MA
Revision: 2007 June MA-3 G37 Coupe
GENERAL MAINTENANCE
< ON-VEHICLE MAINTENANCE >
ON-VEHICLE MAINTENANCE
GENERAL MAINTENANCE
Explanation of General Maintenance INFOID:0000000001679213
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
Item Reference page
Tires Check the pressure with a gauge often and always prior to long distance trips.
Adjust the pressure in all tires, including the spare, to the pressure specified. --
Check carefully for damage, cuts or excessive wear.
Wheel nuts When checking the tires, make sure no nuts are missing, and check for any
--
loose nuts. Tighten if necessary.
Clean the windshield on a regular basis. Check the windshield at least every six
Windshield --
months for cracks or other damage. Repair as necessary.
Tire rotation Tires should be rotated every 7,500 miles (12,000 km). If the vehicle is equipped
MA-26
with different sized tires in the front and rear, tires cannot be rotated.
Tire Pressure Moni-
toring System (TPMS) Replace grommet seal, valve core and cap of the transmitter in vehicles
WT-7
transmitter compo- equipped with TPMS at tire replacement when reaching the wear limit of tires.
nents
Wheel alignment and If the vehicle pulls to either side while driving on a straight and level road, or if
FSU-7
balance you detect uneven or abnormal tire wear, there may be a need for wheel align-
RSU-6
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
MA-26
balancing may be needed.
Windshield wiper
Check for cracks or wear if they do not wipe properly. --
blades
Doors and engine Check that all doors and the engine hood operate properly. Also make sure that
hood all latches lock securely. Lubricate if necessary. Make sure that the secondary
latch keeps the hood from opening when the primary latch is released. MA-33
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check head- --
lamp aim. Clean the headlamps on a regular basis.
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,
etc.
Item Reference page
Warning lamps and
Make sure that all warning lamps and chimes are operating properly. --
chimes
Windshield wiper and Check that the wipers and washer operate properly and that the wipers do not
--
washer streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
--
quantity when operating the heater or air conditioner.
Steering wheel Check that it has the specified play. Be sure to check for changes in the steering
condition, such as excessive play, hard steering or strange noises. --
Free play: Less than 35 mm (1.38 in)
Seats Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every po-
sition. Check that the head restrains move up and down smoothly and that the --
locks (if equipped) hold securely in all latched positions. Check that the latches
lock securely for folding-down rear seatbacks.
Revision: 2007 June MA-4 G37 Coupe
GENERAL MAINTENANCE
< ON-VEHICLE MAINTENANCE >
Item Reference page
A
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely. MA-33
Check the belt webbing for cuts, fraying, wear or damage.
Accelerator pedal Check the pedal for smooth operation and make sure the pedal does not catch B
--
or require uneven effort. Keep the floor mats away from the pedal.
Brakes Check that the brake does not pull the vehicle to one side when applied. --
Brake pedal and Check the pedal for smooth operation and make sure it has the proper distance C
BR-7
booster under it when depressed fully. Check the brake booster function. Be sure to
BR-14
keep the floor mats away from the pedal.
Clutch pedal Make sure the pedal operates smoothly and check that it has the proper free D
CL-5
play.
Parking brake Check that the pedal has the proper travel and make sure that the vehicle is PB-3 (PEDAL TYPE)
held securely on a fairly steep hill when only the parking brake is applied. PB-4 (LEVER TYPE) E
Automatic transmis- Check that the lock release button on the selector lever operates properly and
sion "Park" mecha- smoothly. On a fairly steep hill check that the vehicle is held securely with the --
nism selector lever in the P (Park) position without applying any brakes.
F
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page G
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. CO-8 H
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, de- --
terioration or loose connections. I
Brake and clutch fluid Make sure that the brake and clutch fluid levels are between the "MAX" and MA-29
level "MIN" lines on the reservoir. MA-23
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN" J
lines. Vehicles operated in high temperatures or under severe conditions re- PG-3
quire frequent checks of the battery fluid level.
Engine drive belts Make sure that no belt is frayed, worn, cracked or oily. MA-12 K
Engine oil level Check the level on the oil level gauge after parking the vehicle on a level spot
LU-6
and turning off the engine.
Power steering fluid Check the level on the dipstick with the engine off. Check the lines for improper L
MA-31
level and lines attachment, leaks, cracks, etc.
Exhaust system Make sure there are no loose supports, cracks or holes. If the sound of the ex-
haust seems unusual or there is a smell of exhaust fumes, immediately locate MA-20 M
the trouble and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
N
--
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate. O
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
--
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately. MA
Revision: 2007 June MA-5 G37 Coupe
PERIODIC MAINTENANCE
< ON-VEHICLE MAINTENANCE >
PERIODIC MAINTENANCE
Introduction of Periodic Maintenance INFOID:0000000001679214
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
Follow Periodic Maintenance Schedule 1 if the driving habits frequently include Emission Control Sys-
one or more of the following driving conditions: tem Maintenance
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
