Image preview - the first page of the document

>> Download sc documenatation <<

Text preview - extract from the document

STARTING & CHARGING SYSTEM

K ELECTRICAL

STARTING & CHARGING SYSTEM
SECTION SC B

E
CONTENTS
PRECAUTIONS ......................................................... 2
. VQ35DE ENGINE MODELS (AWD) ................... 18 . F
Precautions for Supplemental Restraint System VK45DE ENGINE MODELS ............................... 19 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- Disassembly and Assembly ................................... 20 .
SIONER" ................................................................. 2
. VQ35DE ENGINE MODELS (2WD) ................... 20 . G
Precautions for Power Generation Voltage Variable VQ35DE ENGINE MODELS (AWD) ................... 21 .
Control System ........................................................ 2
. VK45DE ENGINE MODELS ............................... 22 .
PREPARATION .......................................................... 3
. INSPECTION AFTER DISASSEMBLY ............... 22 .
H
Special Service Tools .............................................. 3
. CHARGING SYSTEM .............................................. 23 .
Commercial Service Tools ....................................... 3 . System Description ................................................ 23 .
BATTERY ................................................................... 4
. DESCRIPTION ................................................... 23 .
How to Handle Battery ............................................ 4 . MALFUNCTION INDICATOR ............................. 23 . I
METHODS OF PREVENTING OVER-DIS- POWER GENERATION VOLTAGE VARIABLE
CHARGE .............................................................. 4
. CONTROL SYSTEM .......................................... 24 .
CHECKING ELECTROLYTE LEVEL ................... 5 . Wiring Diagram -- CHARGE -- ............................ 25 . J
SPECIFIC GRAVITY CHECK .............................. 5 . VQ35DE ENGINE MODELS (2WD) ................... 25 .
CHARGING THE BATTERY ................................ 6 . VQ35DE ENGINE MODELS (AWD) ................... 26 .
Trouble Diagnosis with Battery/Starting/Charging VK45DE ENGINE MODELS ............................... 27 .
SC
System Tester (Battery) ........................................... 7. Trouble Diagnoses with Battery/Starting/Charging
DIAGNOSTIC RESULT ITEM CHART ................. 8 . System Tester (Charging) ...................................... 28 .
Removal and Installation ......................................... 9 . DIAGNOSTIC RESULT ITEM CHART ............... 30 .
REMOVAL ............................................................ 9
. WORK FLOW ..................................................... 31 . L
INSTALLATION .................................................... 9. PRELIMINARY INSPECTION ............................ 32 .
STARTING SYSTEM ............................................... 10 . DIAGNOSTIC PROCEDURE 1 .......................... 32 .
System Description ............................................... 10. DIAGNOSTIC PROCEDURE 2 .......................... 33 . M
Wiring Diagram -- START -- .................................11 . DIAGNOSTIC PROCEDURE 3 .......................... 33 .
VQ35DE ENGINE MODELS ...............................11 . DIAGNOSTIC PROCEDURE 4 .......................... 34 .
VK45DE ENGINE MODELS .............................. 12 . Power Generation Voltage Variable Control System
Trouble Diagnosis with Battery/Starting/Charging Operation Inspection ............................................. 35 .
System Tester (Starting) ........................................ 13 . Removal and Installation ....................................... 37 .
DIAGNOSTIC RESULT ITEM CHART ............... 13 . VQ35DE ENGINE MODELS .............................. 37 .
WORK FLOW ..................................................... 14 . VK45DE ENGINE MODELS ............................... 39 .
DIAGNOSTIC PROCEDURE 1 .......................... 15 . Disassembly and Assembly ................................... 41 .
DIAGNOSTIC PROCEDURE 2 .......................... 16 . VQ35DE ENGINE MODELS .............................. 41 .
MINIMUM SPECIFICATION OF CRANKING VK45DE ENGINE MODELS ............................... 42 .
VOLTAGE REFERENCING COOLANT TEM- SERVICE DATA AND SPECIFICATIONS (SDS) ..... 43 .
PERATURE ........................................................ 16
. Battery ................................................................... 43
.
Removal and Installation ....................................... 17 . Starter .................................................................... 43
.
VQ35DE ENGINE MODELS (2WD) ................... 17 . Alternator ............................................................... 43
.

Revision: 2006 January SC-1 2006 M35/M45
PRECAUTIONS

PRECAUTIONS PFP:00011

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" NKS003NB

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Power Generation Voltage Variable Control System NKS003NC

CAUTION:
For this model, the battery current sensor that is installed to the battery cable at the negative terminal
measures the charging/discharging current of the battery, and performs various controls. If the electri-
cal component or the ground wire is connected directly to the battery terminal, the current other than
that being measured with the battery current sensor is charging to or discharging from the battery.
This condition causes the malfunction of the control, and then the battery discharge may occur. Do
not connect the electrical component or the ground wire directly to the battery terminal.

Revision: 2006 January SC-2 2006 M35/M45
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools NKS003ND

Tool number
(Kent-Moore No.) Description B
Tool name

--
(J-44373 Model 620) C
Battery/Starting/Charging system
tester

SEL403X

Commercial Service Tools NKS003NE

G
Tool name Description

Power tool Loosening bolts, nuts and screws
H

PIIB1407E

Revision: 2006 January SC-3 2006 M35/M45
BATTERY

BATTERY PFP:00011

How to Handle Battery NKS003NF

CAUTION:
q If it becomes necessary to start the engine with a booster battery and jumper cables, use a 12-volt
booster battery.
q After connecting battery cables, ensure that they are tightly clamped to battery terminals for good
contact.
q Never add distilled water through the hole used to check specific gravity.
METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging a battery.
q The battery surface (particularly its top) should always be kept
clean and dry.
q The terminal connections should be clean and tight.
q At every routine maintenance, check the electrolyte level.
This also applies to batteries designated as "low maintenance"
and "maintenance-free".

MEL040F

q When the vehicle is not going to be used over a long period of
time, disconnect the battery cable from the negative terminal. (If
the vehicle has an extended storage switch, turn it off.)

ELA0349D

q Check the charge condition of the battery.
Periodically check the specific gravity of the electrolyte. Keep a
close check on charge condition to prevent over-discharge.

MEL042F

Revision: 2006 January SC-4 2006 M35/M45
BATTERY

CHECKING ELECTROLYTE LEVEL
WARNING: A
Never allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touch-
ing a battery, never touch or rub your eyes until you have thoroughly washed your hands. If acid con-
tacts eyes, skin or clothing, immediately flush with water for 15 minutes and seek medical attention. B
q Remove the cell plug using a suitable tool.
q Add distilled water up to the MAX level.
C

E
MEL043F

Sulphation
F
A battery will be completely discharged if it is left unattended
for a long time and the specific gravity will become less than
1.100. This may result in sulphation on the cell plates.
To determine if a battery has been "sulphated", note its voltage G
and current when charging it. As shown in the figure, less cur-
rent and higher voltage are observed in the initial stage of
charging sulphated batteries. H
A sulphated battery may sometimes be brought back into ser-
vice by means of a long, slow charge, 12 hours or more, fol-
lowed by a battery capacity test.
I
PKIA2353E

SPECIFIC GRAVITY CHECK
1. Read hydrometer and thermometer indications at eye level. J
2. Use the chart below to correct your hydrometer reading accord-
ing to electrolyte temperature.
SC

MEL042FA M

Revision: 2006 January SC-5 2006 M35/M45
BATTERY

Hydrometer Temperature Correction
Battery electrolyte temperature [
