Image preview - the first page of the document
>> Download rax documenatation <<
Text preview - extract from the document
REAR AXLE
D DRIVELINE/AXLE
A
SECTION RAX REAR AXLE
B
C
RAX
E
CONTENTS
PRECAUTIONS ......................................................... 2 . INSTALLATION .................................................... 7 . F
Caution .................................................................... 2
. Disassembly and Assembly ..................................... 7 .
PREPARATION .......................................................... 3. DISASSEMBLY .................................................... 7 .
Special Service Tools .............................................. 3 . INSPECTION AFTER DISASSEMBLY ................. 8 . G
Commercial Service Tools ....................................... 4 . ASSEMBLY .......................................................... 8
.
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER ASSEMBLY ....................... 9 .
TROUBLESHOOTING ............................................... 5 . REAR DRIVE SHAFT .............................................. 10 .
H
NVH Troubleshooting Chart .................................... 5 . Removal and Installation ....................................... 10 .
WHEEL HUB ............................................................. 6
. REMOVAL .......................................................... 10
.
On-Vehicle Inspection and Service ......................... 6 . INSPECTION AFTER REMOVAL ...................... 10 .
WHEEL BEARING INSPECTION ........................ 6 . INSTALLATION .................................................. 10 . I
Removal and Installation ......................................... 6 . Disassembly and Assembly ................................... 11 .
REMOVAL ............................................................ 6
. DISASSEMBLY .................................................. 11 .
INSPECTION AFTER REMOVAL ........................ 7 . INSPECTION AFTER DISASSEMBLY ............... 12 . J
ASSEMBLY ........................................................ 13.
SERVICE DATA ....................................................... 16.
Wheel Bearing ....................................................... 16
.
K
Drive Shaft ............................................................. 16
.
Z100D90F TYPE ................................................ 16 .
L
M
Revision: 2004 October RAX-1 2004 M45
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution ADS0006G
Observe the following precautions when disassembling and servicing drive shaft.
q Perform work in a location which is as dust-free as possible.
q Before disassembling and servicing, clean the outside of parts.
q Disassembly and service location must be taken to prevent the entry of foreign objects.
q Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.
q Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
ing to parts.
q Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.
Revision: 2004 October RAX-2 2004 M45
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools ADS0006H
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
C
KV401 04100
( -- ) Removing wheel hub RAX
Attachment
ZZC0947D
E
ST3623 0000 F
(J 25840-A) Removing wheel hub
Sliding hammer
G
ZZA0803D
ST33061000 H
(J 8107-2)
Removing wheel bearing outer side inner
Drift
race
a: 28.5 mm (1.12 in) dia.
b: 38.0 mm (1.50 in) dia. I
ZZA0969D
J
ST3527 1000
(J 26091)
Drift Removing wheel bearing
a: 72 mm (2.83 in) dia. K
b: 63 mm (2.48 in) dia.
ZZA0837D
L
KV401 05310
( -- )
Drift Removing wheel bearing M
a: 75 mm (2.95 in) dia.
b: 62 mm (2.44 in) dia.
ZZA0832D
ST3072 0000
(J 25405)
Drift Installing wheel bearing
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.
ZZA0837D
Revision: 2004 October RAX-3 2004 M45
PREPARATION
Tool number
(Kent-Moore No.) Description
Tool name
KV401 05220
( -- )
Drift Installing wheel hub
a: 75 mm (2.95 in) dia.
b: 62 mm (2.44 in) dia.
ZZA0832D
KV381 00500
( -- )
Drift Installing drive shaft plug
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.
ZZA0701D
KV381 02200
( -- )
Drift Installing drive shaft plug
a: 90 mm (3.54 in) dia.
b: 31 mm (1.22 in) dia.
ZZA0920D
Commercial Service Tools ADS00089
Tool name Description
q Removing wheel nuts
q Removing hub lock nut
q Removing brake caliper assembly
Power tool q Removing radius rod
q Removing front lower link
q Removing shock absorber lower bolt
PBIC0190E
q Removing drive shaft
Revision: 2004 October RAX-4 2004 M45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart ADS0006I
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
Refer to DRIVE SHAFT in this chart.
Refer to REAR AXLE in this chart.
NVH in FAX and FSU sections.
C
RAX-12
RAX-6
NVH in RFD section.
NVH in WT section.
NVH in WT section.
NVH in PR section.
NVH in BR section.
--
--
--
NVH in PS section.
Reference page
RAX
E
FRONT AXLE AND FRONT SUSPENSION
F
Improper installation, looseness
Joint sliding resistance G
Possible cause and SUSPECTED PARTS
PROPELLER SHAFT
Excessive joint angle
H
Parts interference
DIFFERENTIAL
ROAD WHEEL
DRIVE SHAFT
REAR AXLE
STEERING
Imbalance
BRAKES
I
TIRES
