Image preview - the first page of the document
>> Download ww documenatation <<
Text preview - extract from the document
WIPER, WASHER & HORN
K ELECTRICAL
A
SECTION
WIPER, WASHER & HORN
WW B
C
D
E
CONTENTS
PRECAUTION ........................................................... 3
. Removal and Installation of Front Wiper Arms, F
Precautions for Supplemental Restraint System Adjustment of Wiper Arms Stop Location .............. 21 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- REMOVAL .......................................................... 21 .
SIONER" ................................................................. 3
. INSTALLATION .................................................. 22 . G
Wiring Diagrams and Trouble Diagnosis ................. 3 . ADJUSTMENT ................................................... 22 .
FRONT WIPER AND WASHER SYSTEM ................. 4 . Removal and Installation of Front Wiper Motor and
Component Parts and Harness Connector Location 4 ..... Linkage .................................................................. 22
.
H
System Description ................................................. 4. REMOVAL .......................................................... 22 .
WIPER OPERATION ........................................... 4 . INSTALLATION .................................................. 22 .
WASHER OPERATION ........................................ 6 . Disassembly and Assembly of Front Wiper Motor
Schematic ............................................................... 7
. and Linkage ........................................................... 23
. I
Wiring Diagram -- WIPER -- ................................. 8 . DISASSEMBLY .................................................. 23 .
Terminal and Reference Values for BCM ...............11 . ASSEMBLY ........................................................ 23 .
Work Flow ..............................................................11
. Washer Nozzle Adjustment ................................... 23 . J
Preliminary Inspection ............................................11 . Washer Tube Layout ............................................. 24 .
SETTING CHANGE FUNCTIONS ......................11 . Removal and Installation of Front Washer Nozzle... 25
INSPECTION FOR POWER SUPPLY AND REMOVAL .......................................................... 25 .
WW
GROUND CIRCUIT ............................................ 12 . INSTALLATION .................................................. 25 .
CONSULT-II Function ........................................... 12 . Inspection of Washer Nozzle ................................. 25 .
CONSULT-II BASIC OPERATION PROCEDURE CHECK VALVE ................................................... 25 .
... 13 Removal and Installation of Front Wiper and Washer L
WORK SUPPORT .............................................. 13 . Switch .................................................................... 25
.
DATA MONITOR ................................................ 14 . REMOVAL .......................................................... 25 .
ACTIVE TEST .................................................... 14 . INSTALLATION .................................................. 25 . M
On Board Diagnosis .............................................. 14 . Removal and Installation of Washer Tank ............. 26 .
DIAGNOSIS ITEM FOR FRONT WIPER AND REMOVAL .......................................................... 26 .
WASHER SYSTEM ............................................ 14 . INSTALLATION .................................................. 26 .
SWITCH MONITOR ........................................... 15 . Removal and Installation of Washer Pump ............ 26 .
Intermittent Wiper Does Not Operate .................... 16 . REMOVAL .......................................................... 26 .
Intermittent Time of Wiper Cannot be Adjusted .... 18 . INSTALLATION .................................................. 26 .
Wiper and Washer Activate Individually But Not in CIGARETTE LIGHTER ............................................ 27 .
Combination .......................................................... 18
. Wiring Diagram -- CIGAR -- ................................ 27 .
Intermittent Wiper Operates, But There is No Removal and Installation ....................................... 28 .
Change in Intermittent Time Between When Vehicle REMOVAL .......................................................... 28 .
is Stopped and Moving .......................................... 19 . INSTALLATION .................................................. 28 .
Wiper and Washer Activate Individually But Inter- POWER SOCKET .................................................... 29 .
mittent Wiper and Washer Combination Does Not Wiring Diagram -- CIGAR -- ................................ 29 .
Operate ................................................................. 20
. Removal and Installation ....................................... 30 .
Wiper and Washer Switch Circuit Check ............... 21 . REMOVAL .......................................................... 30 .
INSPECTION OF SWITCH CIRCUIT ................ 21 . INSTALLTION ..................................................... 30 .
Revision: 2004 October WW-1 2004 M45
HORN ....................................................................... 31
. Wiring Diagram -- HORN -- .................................31 .
Removal and Installation ........................................32
.
REMOVAL ...........................................................32
.
INSTALLATION ...................................................32
.
Revision: 2004 October WW-2 2004 M45
PRECAUTION
PRECAUTION PFP:00011
A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" AKS004VC
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING: D
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer. E
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section. F
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
G
Wiring Diagrams and Trouble Diagnosis AKS002L7
When you read wiring diagrams, refer to the following:
H
q Refer to GI-14, "How to Read Wiring Diagrams" .
q Refer to PG-2, "POWER SUPPLY ROUTING" for power distribution circuit.
When you perform trouble diagnosis, refer to the following: I
q Refer to GI-10, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES" .
q Refer to GI-26, "How to Perform Efficient Diagnosis for an Electrical Incident" .
J
WW
L
M
Revision: 2004 October WW-3 2004 M45
FRONT WIPER AND WASHER SYSTEM
FRONT WIPER AND WASHER SYSTEM PFP:28810
Component Parts and Harness Connector Location AKS002L9
PKIA6947E
System Description AKS002L8
Through the adoption of vehicle speed detect-type intermittent wiper, Front Wiper System changes wiper's
intermittent time when the engine is stopped and while driving.
Vehicle speed signal is send from the combination meter to BCM. BCM controls intermittent activation time
and coupled activation of washer and wiper.
WIPER OPERATION
Description
The wiper switch is controlled by a lever built in the combination switch.
There are three wiper switch positions
q LO speed
q HI speed
q INT (intermittent)
Power is supplied at all times
q through 10A fuse [No.3, located in fuse block (J/B) No.1]
q to BCM terminal 105
With the ignition switch in the ON position, power is supplied
q through 10A fuse [No. 1, located in fuse block (J/B) No.1]
q to BCM terminal 68
q through 20A fuse [No. 34, located in fuse block (J/B) No.2]
q to front wiper motor terminal 4
Revision: 2004 October WW-4 2004 M45
FRONT WIPER AND WASHER SYSTEM
q to front wiper relay terminal 1
q to front washer motor terminal 1. A
Ground is supplied
q to front wiper switch terminals 17 and 20
B
q through grounds M25 and M115.
Low (MIST) and High Speed Wiper Operation
When the wiper switch is placed in the LO or MIST position, ground is supplied C
q through front wiper switch terminal 14
q to front wiper motor terminal 6.
With power and ground supplied, the front wiper motor operates at low speed. D
When the front wiper switch is placed in the HI position, ground is supplied
q through front wiper switch terminal 16
E
q to front wiper motor terminal 5.
With power and ground supplied, the front wiper motor operates at high speed.
Auto Stop Operation F
When the front wiper switch is placed in the OFF position, the front wiper motor will continue to operate until
the wiper arms reach the base of the windshield (Auto stop). When the front wiper switch is placed in the OFF
position, ground is supplied G
q from front wiper switch terminal 14
q to front wiper motor terminal 6, in order to continue front wiper motor operation at low speed.
Ground is also supplied until the wiper arms reaches the base of the windshield H
q through front wiper switch terminal 13
q to front wiper relay terminal 3
q through front wiper relay terminal 4 I
q to front wiper motor terminal 3
q through front wiper motor terminal 1, and
J
q through grounds E24, E42 and E62.
When the wiper arms reach the base of the windshield, the switch in the front wiper motor moves to the
"STOP" position. The ground path is interrupted and the front wiper motor stops. WW
Intermittent Operation
Intermittent operation is controlled by the BCM. When the front wiper switch is placed in the INT position,
ground is supplied L
q to BCM terminal 9
q through front wiper switch terminal 15
q to grounds M25 and M115 M
q through front wiper switch terminal 17.
The desired interval time is input
q to BCM terminal 48
q through front wiper switch terminal 19
q to BCM terminal 49
q through combination meter terminal 38 (vehicle speed pulse).
The desired interval time is input
q to front wiper relay terminal 2
q through BCM terminal 128.
With power and ground supplied, the front wiper relay is activated. When activated, an intermittent ground is
supplied
q to front wiper motor terminal 6
q through front wiper switch terminal 14
q to front wiper switch terminal 13
Revision: 2004 October WW-5 2004 M45
FRONT WIPER AND WASHER SYSTEM
q through front wiper relay terminal 3
q to front wiper relay terminal 5
q through grounds E24, E42 and E62.
Front wiper motor operates at desired interval with BCM terminal 9 grounded. Intermittent operation can be
adjusted from: Approx. 0.9 - 45 sec.: (when vehicle is stopped), Approx. 0.4 - 30 sec.: (when vehicle is mov-
ing). Judgement on vehicle stopped or moving: Stopped, Moving: More than 5 km/h (3 MPH) Moving, Stopped:
Less than 2 km/h (1 MPH)
WASHER OPERATION
With the ignition switch in the ON position, power is supplied
q through 20A fuse [No. 34, located in fuse block (J/B) No.2]
q to front washer motor terminal 1.
When the lever is pulled to the WASH position, ground is supplied
q to front washer motor terminal 2, and
q to BCM terminal 4
q from front wiper switch terminal 18
q through front wiper switch, terminal 17, and
q through grounds M25 and M115.
With power and ground supplied, the front washer motor operates. The front wiper motor operates at low
speed for about 3 seconds. This feature is controlled by the BCM in the same manner as the intermittent oper-
ation.
Revision: 2004 October WW-6 2004 M45
FRONT WIPER AND WASHER SYSTEM
Schematic AKS002LA
A
B
C
D
E
F
G
H
I
J
WW
L
M
TKWA0626E
Revision: 2004 October WW-7 2004 M45
FRONT WIPER AND WASHER SYSTEM
Wiring Diagram -- WIPER -- AKS002LB
TKWA0627E
Revision: 2004 October WW-8 2004 M45
FRONT WIPER AND WASHER SYSTEM
A
B
C
D
E
F
G
H
I
J
WW
L
M
TKWA0628E
Revision: 2004 October WW-9 2004 M45
FRONT WIPER AND WASHER SYSTEM
TKWA0629E
Revision: 2004 October WW-10 2004 M45
FRONT WIPER AND WASHER SYSTEM
Terminal and Reference Values for BCM AKS002LC
A
Terminal Wire Measuring condition
Item Reference value
No. color Ignition switch Operation or condition
WASH Approx. 0 V B
4 P Washer switch signal ON Wiper switch
OFF Battery voltage
INT Approx. 0 V
9 OR Wiper switch INT signal ON Wiper switch C
OFF Approx. 8 V
Intermittent wiper Wiper intermittent Long Approx. 3.6 V
48 R/G ON
volume signal interval Short Approx. 0 V D
E
Vehicle speed signal Vehicle speed approx. 40 km/h
49 PU/W ON
(2-pulse) (25 MPH)
F
ELF1080D
56 B Ground ON - Approx. 0 V
68 W/B Ignition on signal ON - Battery voltage G
105 Y/L Battery power supply OFF - Battery voltage
113 B Ground ON - Approx. 0 V
H
Wiper auto Wiper is moving. Approx. 0 V
124 SB ON
stop signal Wiper is stopped. Battery voltage
I
Wiper motor
128 R/Y ON Wiper switch: INT position J
operation signal
SKIA3507E
WW
Work Flow AKS002LD
1. Confirm the symptom or customer complaint.
L
2. Understand the system description. Refer to WW-4, "System Description" .
3. Perform preliminary inspection. Refer to WW-11, "Preliminary Inspection" .
4. According to the trouble diagnosis chart, repair or replace the cause of the malfunction.
M
5. Does wiper function operate normally? If it operates normally, GO TO 6. If not, GO TO 4.
6. INSPECTION END
Preliminary Inspection AKS002LE
SETTING CHANGE FUNCTIONS
q With CONSULT-II, each function can be changed in setting. Refer to WW-13, "WORK SUPPORT" .
CAUTION:
After the setting was changed, the new setting will be maintained even if the battery was discon-
nected.
Setting change mode CONSULT-ll (WORK SUPPORT) Description
ON Activated
Wiper intermittent speed control by vehicle speed
OFF Disactivated
Revision: 2004 October WW-11 2004 M45
FRONT WIPER AND WASHER SYSTEM
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
Inspection procedure
1. CHECK FUSE
q Make sure wiper and washer fuse is blown.
Unit Power source Fuse No.
Front wiper motor, Front washer motor, Front wiper relay Ignition ON or START position 34
CAUTION:
For fuse number, refer to WW-4, "Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
2, "POWER SUPPLY ROUTING" .
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect front wiper motor, front washer motor and front wiper relay connector.
2. Check voltage between the following connector terminals and ground.
Terminals (wire color)
Unit (Connector) Ignition switch condition Voltage
(+) (-)
Front wiper motor (E75) 4 (LG)
Front washer motor (E48) 1 (LG) Ground ON Battery voltage
Front wiper relay (E2-2) 1 (LG)
OK or NG
OK >> GO TO 3.
NG >> Replace harness of wiper and washer power supply circuit.
3. CHECK GROUND CIRCUIT (BCM)
Check for continuity between the following BCM connector terminals and ground.
Unit (Connector) Terminals (wire color) Ignition switch condition Continuity
56 (B)
BCM (M4) Ground OFF Yes
113 (B)
OK or NG
OK >> INSPECTION END
NG >> Replace harness BCM ground circuit.
CONSULT-II Function AKS002LF
q CONSULT-II executes the following functions by combining data received and command transmitted via
the communication line from the BCM. IVMS communication inspection, work support by part, self-diagno-
sis, data monitor, and active test display.
IVMS Check item and
Description
diagnosis part diagnosis mode
WORK SUPPORT Changes the setting for each function.
WIPER DATA MONITOR Displays data relative to BCM input signals and various control related data for each system.
ACTIVE TEST Gives a drive signal to a load to check the operation.
BCM PART NUMBER Displays BCM part No.
Revision: 2004 October WW-12 2004 M45
FRONT WIPER AND WASHER SYSTEM
CONSULT-II BASIC OPERATION PROCEDURE
1. With ignition switch OFF, connect CONSULT-II and CONSULT-II A
CONVERTER to data link connector, then turn ignition switch
ON.
B
C
PKIA5840E
D
2. Touch "START (NISSAN BASED VHCL)".
E
F
G
SKIA3098E
H
3. Touch "IVMS" on "SELECT SYSTEM" screen. If "IVMS" is not
indicated, refer to GI-38, "CONSULT-II Data Link Connector
(DLC) Circuit" .
I
J
WW
SKIA3783E
4. Check the model specification, touch either "WITH SUNROOF"
or "WITHOUT SUNROOF". L
5. Touch "OK". If the selection is wrong, touch "CANCEL".
6. Select the desired part to be diagnosed on
"SELECT TEST ITEM" screen. M
PIIA0184E
WORK SUPPORT
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "WORK SUPPORT" on "SELECT DIAG MODE" screen.
3. Touch "WIP INT VHCL SPD ADJ"on "SELECT WORK ITEM" screen.
4. Touch "START".
q Wiper intermittent speed control by vehicle speed can be canceled or resumed.
5. Touch "CURRENT SETTING" for changing "CURRENT SETTING".
For no changing "CURRENT SETTING", touch "END".
Revision: 2004 October WW-13 2004 M45
FRONT WIPER AND WASHER SYSTEM
"CURRENT SETTING" Wiper intermittent speed control
"ON" Activated
"OFF" Disactivated
6. Touch "END" after customizing is completed.
DATA MONITOR
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU" on "DATA MONITOR" screen.
4. Touch "START".
Date Monitor Item
Monitored item Description
IGN ON SW Indicates "IGN [ON] / ACC or OFF [OFF]" condition of ignition switch signal.
INT SW Indicates " INT Position [ON] / Others [OFF]" condition of wiper switch signal.
WASH SW Indicates "WASH Position [ON] / Others [OFF]" condition of wiper switch signal.
VHCL SPEED SE Indicates "Vehicle is moving [RUN] / Vehicle Stopped [STOP]" condition of vehicle speed signal.
WIPR AUTO STP Indicates "INT or OFF Position [IGN] / LO or HI Position [OFF]" condition of wiper switch signal.
INTRESIST Indicates " Intermittent Resistance Value [approx. 0 to 1]" condition wiper switch signal.
ACTIVE TEST
Operation Procedure
1. Touch "WIPER" on "SELECT TEST ITEM" screen.
2. Touch "ACTIVE TEST" on "SELECT DIAG MODE" screen.
3. Touch the item to be tested, and check the operation.
Test item "WIPER AMP" Wiper motor operation
"ON" Operate
"OFF" Stop
4. During the operation check, touching "OFF" deactivates the operation.
On Board Diagnosis AKS002LG
q IVMS can check communication diagnosis, switch monitor, and power door lock system self-diagnosis
using on board diagnosis.
q Map lamps and step lamps (all seats) act as the indicators for the on board diagnosis.
DIAGNOSIS ITEM FOR FRONT WIPER AND WASHER SYSTEM
Diagnosis item Description
Switch monitor It can check wiper and washer switch.
Revision: 2004 October WW-14 2004 M45
FRONT WIPER AND WASHER SYSTEM
SWITCH MONITOR
How to Perform Switch Monitor A
B
C
D
E
F
PKIA7882E G
Diagnosis Result Display
q Detects the status change (switch ON/OFF operation) of the switch to be checked, and turns on/off the
indicator lamps (the map lamp and step lamp). Also sounds the buzzer for 0.5 seconds. H
q If a malfunction is detected, no indicator lamp and buzzer react.
I
J
WW
SEL960V
L
Cancel of Switch Monitor
q Turn ignition switch OFF.
q Drive the vehicle at more than 7 km/h (4 MPH). M
Revision: 2004 October WW-15 2004 M45
FRONT WIPER AND WASHER SYSTEM
Intermittent Wiper Does Not Operate AKS002LH
1. CHECK INTERMITTENT WIPER SWITCH INPUT SIGNAL
With CONSULT-II
See "INT SW" in "DATA MONITOR" mode.
When wiper switch is in INT position: ON
When wiper switch is in OFF position: OFF
NOTE:
When "DATA MONITOR" is operating, intermittent wiper does not
operate.
Without CONSULT-II
Check wiper switch (INT) in switch monitor mode. Refer to WW-15,
"SWITCH MONITOR" .
OK or NG SEL503W
OK >> GO TO 2
NG >> Check the following.
q Front wiper switch
q Harness for open or short between BCM and wiper switch
q Front wiper switch ground circuit
2. CHECK WIPER AUTO STOP SIGNAL
With CONSULT-II
See "WIP AUTO STOP" in "DATA MONITOR" mode, and turn wiper
switch to LO or HI position.
When wiper switch is in INT or OFF position: IGN
When wiper switch is in LO or HI: GND
SEL504W
Without CONSULT-II
1. Turn ignition switch ON.
2. Turn wiper switch to LO or HI position.
3. Check voltage between BCM harness connector E204 terminal
124 (SB) and ground.
Terminals
(+) Voltage
(-) Condition
Connector Terminal (Wire color)
PKIA5980E
Moving Approx. 0V
E204 124 (SB) Ground
Stopped Battery voltage
OK or NG
OK >> GO TO 3
NG >> Check the following.
q Wiper motor
q Wiper motor ground circuit
q Harness for open or short between BCM and wiper motor
Revision: 2004 October WW-16 2004 M45
FRONT WIPER AND WASHER SYSTEM
3. CHECK IGNITION SWITCH ON SIGNAL A
With CONSULT-II
See "IGN ON SW" in DATA MONITOR mode.
When ignition switch is ON: ON B
When ignition switch is ACC or OFF: OFF
C
D
PKIA0311E
Without CONSULT-II E
Check voltage between BCM harness connector M4 terminal 68 (W/
B) and ground.
F
Terminals
(+)
Voltage
Terminal (-) Condition G
Connector
(Wire color)
Battery
Ignition switch ON or START
M4 68 (W/B) Ground voltage H
PKIA5981E
Ignition switch ACC or ON Approx. 0V
OK or NG
OK >> GO TO 4 I
NG >> Check the following.
q 10A fuse [No. 1, located in fuse block (J/B) No.1]
q Harness for open or short between fuse and BCM
J
4. CHECK WIPER OPERATION
WW
With CONSULT-II
See "WIPER AMP" in ACTIVE TEST mode. Perform operation
shown on display.
L
Wiper motor should operate.
NOTE:
If CONSULT-II is not available, skip this procedure and refer to WW- M
20, "Wiper and Washer Activate Individually But Intermittent Wiper
and Washer Combination Does Not Operate" .
OK or NG
OK >> Replace BCM. SEL494W
NG >> GO TO WW-20, "Wiper and Washer Activate Individu-
ally But Intermittent Wiper and Washer Combination Does Not Operate" .
Revision: 2004 October WW-17 2004 M45
FRONT WIPER AND WASHER SYSTEM
Intermittent Time of Wiper Cannot be Adjusted AKS002LI
1. CHECK INTERMITTENT WIPER VOLUME INPUT SIGNAL
With CONSULT-II
See "INT RESIST" in "DATA MONITOR" mode while turning intermit-
tent wiper volume.
Short interval : Approx. 0 kohm
Long interval : Approx. 1 kohm
SEL506W
Without CONSULT-II
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Measure resistance between BCM harness connector M4 termi-
nal 48 (R/G) and ground while turning intermittent wiper volume.
Terminals
Resistance
Connector Terminal (Wire color) Condition
Short interval Approx. 0
M4 48 (R/G) Ground
PKIA5982E
Long interval Approx. 1k
OK or NG
OK >> Replace BCM.
NG >> GO TO 2
2. CHECK FRONT WIPER SWITCH
Check front wiper switch. Refer to WW-21, "Wiper and Washer Switch Circuit Check" .
OK or NG
OK >> Check the following.
q Harness for open or short between BCM and front wiper switch
q Front wiper switch ground circuit
NG >> Replace front wiper switch.
Wiper and Washer Activate Individually But Not in Combination AKS002LJ
1. CHECK WASHER SWITCH INPUT SIGNAL
With CONSULT-II
See "WASH SW" in "DATA MONITOR" mode.
When washer switch is ON: ON
When washer switch is OFF: OFF
Without CONSULT-II
Check wiper switch (WASH) in switch monitor mode. Refer to WW-
15, "SWITCH MONITOR" .
OK or NG
OK >> Replace BCM.
NG >> Check the following.
SEL507W
q Harness for open or short between BCM and front
wiper switch
Revision: 2004 October WW-18 2004 M45
FRONT WIPER AND WASHER SYSTEM
Intermittent Wiper Operates, But There is No Change in Intermittent Time
Between When Vehicle is Stopped and Moving AKS002LK
A
1. CHECK THE SYMPTOM
Check that the speedometer in the combination meter operates normally. B
OK or NG?
OK >> GO TO 2
NG >> Check vehicle speed signal. Refer to "Work Flow" in DI section. C
2. CHECK VEHICLE SPEED SENSOR PULL UP VOLTAGE
D
With CONSULT-II
q With "VHCL SPEED SE" on "DATAMONITOR", check the vehi-
cle speed signal. Refer to SE-44, "DATA MONITOR" . E
Without CONSULT-II
q GO TO 3
OK or NG F
OK >> System is OK.
NG >> GO TO 3.
G
PKIA6073E
3. VEHICLE SPEED INPUT/OUTPUT INSPECTION H
1. Start engine.
2. Check voltage between BCM harness connector M4 terminal 49
(PU/W) and body ground, using an oscilloscope. I
49 (PU/W) - Ground : Voltage waveform
(When vehicle speed is approx.
40 km/h (25 MPH)) J
OK or NG?
OK >> Replace BCM. WW
NG >> GO TO 4.
L
M
PKIA5983E
Revision: 2004 October WW-19 2004 M45
FRONT WIPER AND WASHER SYSTEM
4. HARNESS CONTINUITY INSPECTION
1. Turn ignition switch OFF.
2. Disconnect BCM and combination meter.
3. Check continuity between BCM harness connector M4 terminal
49 (PU/W) and combination meter M41 terminal 38 (PU/W), and
between BCM harness connector M4 terminal 49 (PU/W) and
ground.
Terminals
Terminal Terminal Continuity
Connector Connector
(Wire color) (Wire color)
PKIA5984E
49 (PU/W) M41 38 (PU/W) Yes
M4
49 (PU/W) Ground No
OK or NG?
OK >> Replace meter control unit.
NG >> Repair or replace harness.
Wiper and Washer Activate Individually But Intermittent Wiper and Washer
Combination Does Not Operate AKS002LL
1. CHECK POWER SUPPLY CIRCUIT FOR FRONT WIPER RELAY
1. Turn ignition switch OFF.
2. Remove front wiper relay.
3. Turn ignition switch ON.
4. Check voltage between front wiper relay harness connector E2-
2 terminal 1 (LG) and ground.
1 (LG) - Ground : Battery voltage should exist.
OK or NG
OK >> GO TO 2
NG >> Check the following. PKIA5174E
q 20A fuse [No. 34, located in fuse block (J/B) No.2]
q Harness for open or short between front wiper relay and fuse
2. CHECK GROUND CIRCUIT FOR FRONT WIPER RELAY
1. Turn ignition switch OFF.
2. Check continuity between front wiper relay harness connector
E2-2 terminal 5 (B) and ground.
5 (B) - Ground : Continuity should exist.
OK or NG
OK >> GO TO 3
NG >> Repair harness.
PKIA5175E
Revision: 2004 October WW-20 2004 M45
FRONT WIPER AND WASHER SYSTEM
3. CHECK FRONT WIPER RELAY A
Apply battery voltage between front wiper relay terminal 1and 2, and
check continuity between terminal 3 and 5.
3-5 : Continuity should exist. B
OK or NG
OK >> GO TO 4
C
NG >> Replace front wiper relay.
D
PKIA6829E
4. CHECK BCM OUTPUT SIGNAL E
1. Connect front wiper relay.
2. Turn ignition switch ON.
F
3. Check voltage between BCM harness connector E204 terminal
128 (R/Y) and ground.
Terminals G
(+)
Voltage
Terminal (-) Condition
Connector H
(Wire color)
Wash Approx. 0V (for 0.7 sec.) PKIA5176E
E204 128 (R/Y) Ground
OFF Battery voltage
I
OK or NG
OK >> Repair harness between BCM and front wiper relay.
NG >> Replace BCM. J
Wiper and Washer Switch Circuit Check AKS004YS
INSPECTION OF SWITCH CIRCUIT
Check continuity between each terminal when wiper washer switch WW
is operating using a circuit tester.
Operation interval L
Resistance value
(intermittent wiper with vehicle speed detection function)
1, interval (Max.) Approx. 1.0 k
2, Approx. 0.6 k M
3, Approx. 0.3 k
4, interval (Min.) Approx. 0 k
PKIA5184E
Removal and Installation of Front Wiper Arms, Adjustment of Wiper Arms Stop
Location AKS003WD
REMOVAL
1. Operate wiper motor, and stop it at the auto stop position.
2. Remove wiper arm mounting nuts and wiper arm from vehicle.
Revision: 2004 October WW-21 2004 M45
FRONT WIPER AND WASHER SYSTEM
INSTALLATION
1. Clean up the pivot area as illustrated. This will reduce possibility
of wiper arm looseness.
SEL024J
2. Prior to wiper arm installation, turn on wiper switch to operate
wiper motor and then turn it "OFF" (auto stop).
3. Push wiper arm onto pivot shaft, paying attention to blind spline.
4. Lift the blade up and then set it down onto glass surface to set
the blade center to clearance "L1" & "L2" immediately before
tightening nut.
5. Eject washer fluid. Turn on wiper switch to operate wiper motor
and then turn it "OFF".
6. Ensure that wiper blades stop within clearance "L1" & "L2".
Clearance "L1" : 44.1 - 59.1 mm (1.736 - 2.327 in) PKIA7843E
Clearance "L2" : 30.9 - 45.9 mm (1.217 - 1.807 in)
q Tighten wiper arm nuts to the specified torque.
Front wiper arm mounting nuts : 23.6 N◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
